Owner's Manual
Product May Vary Slightly From Pictured.
CAUTION:
Weight on this product should not exceed 350 lbs.
This Product is Distributed Exclusively by
2040 N. Alliance, Springfield, MO 65803
www.staminaproducts.com
Customer Care
1 (800) 375-7520
WARNING
!
Exercise can present a
h e a l t h r i s k . C o n s u l t a
physician before beginning
any exercise program with
this equipment. If you feel
faint or dizzy, immediately
d i s c o n t i n u e u s e o f t h i s
equipment. Serious bodily
i n j u r y c a n o c c u r i f t h i s
equipment is not assembled
and used correctly. Serious
bodily injury can also occur
if all instructions are not
followed. Keep others and
pets away from equipment
when in use. Always make
sure all bolts and nuts are
securely tightened prior to
each use. Follow all safety
instructions in this manual.
When calling for parts or
service, please specify
the following numbers :
Model#: 55-5610
S/N: _____________
United States and/or
International patents apply
and/or are pending. See
www.staminaproducts.com
for details.
STAMINA PRODUCTS
MADE IN CHINA
© 2018 Stamina Products, Inc.
2018, 03

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Precision Series Reformer 610 and is the answer not in the manual?

Questions and answers

Related Manuals for AeroPilates Precision Series Reformer 610

Summary of Contents for AeroPilates Precision Series Reformer 610

  • Page 1 Owner's Manual WARNING Exercise can present a h e a l t h r i s k . C o n s u l t a physician before beginning any exercise program with this equipment. If you feel faint or dizzy, immediately d i s c o n t i n u e u s e o f t h i s equipment.

  • Page 3: Table Of Contents

    17. The AeroPilates® Precision Series Reformer 610 should be used by only one person at a time. 18. The AeroPilates® Precision Series Reformer 610 is for consumer use only. It is not for use in public or semipublic facilities.
  • Page 4 ONLINE TELEPHONE MAIL customer.care@staminaproducts.com 1 (800) 375-7520 (417) 889-8064 Stamina Products, Inc. www.staminaproducts.com ATTN: Customer Care P.O. Box 1071 Springfield, MO 65801-1071 CUSTOMER CARE HOURS: facebook.com/StaminaProducts Monday-Thursday, 7:30 AM-5:00 PM, Central Time facebook.com/AeroPilates Friday, 8:00 AM-3:00 PM, Central Time...

  • Page 5: Before You Begin

    BEFORE YOU BEGIN Thank you for choosing the AeroPilates® calling for assistance. Precision Series Reformer 610. We take great Read this manual carefully before using the pride in producing this quality product and hope it AeroPilates® Precision Series Reformer 610.

  • Page 6: Equipment Warning, Caution & Notice Labels

    EQUIPMENT WARNING, CAUTION & NOTICE LABELS This chart is provided to help identify the warning, caution, and notice labels on the AeroPilates® Precision Series Reformer 610. Please take a moment to familiarize yourself with all of the warning, caution, and notice labels.

  • Page 7: Hardware Identification Chart

    HARDWARE IDENTIFICATION CHART This chart is provided to help identify the hardware used in the assembly process. Place the washers or the ends of the bolts or screws on the circles to check for the correct diameter. Use the small scale to check the length of the bolts and screws.

  • Page 8: Assembly Instructions

    Time) Monday through Thursday and 8:00 A.M. to 3:00 P.M. (Central Time) on Friday. STEP 1 Remove your AeroPilates® Precision Series Reformer 610 from its packaging, placing the product on its side. Unfold the MAIN FRAME ASSEMBLY half way as shown in the illustration.
  • Page 9 BRACE ASSEMBLY(4) away from the REAR BRACE ASSEMBLY(5) in a counterclockwise position until fully extended. Lower the AeroPilates® Precision Series Reformer 610 so all six legs are flat on the floor. Refer to illustration A. Bolt FRONT RIGHT RAIL(7) and REAR RIGHT RAIL(9) together with BUTTON HEAD BOLTS(M5x0.8x15mm)(71) and WASHERS(M5)(84).
  • Page 10 ASSEMBLY INSTRUCTIONS STEP 6 Insert the PULLEY RISERS(16) into the mounting holes in the REAR WOODEN PLATFORM(29) and REAR BRACE(5). Insert the PULLEY RISERS(16) all the way to the bottom. Align the holes in the PULLEY RISERS(16) with the holes in the REAR BRACE(5) and secure with the LOCKING KNOBS(41). STEP 7 Insert the FOAM PAD ASSEMBLIES(27) into the holes located on the CARRIAGE CUSHION(23).
  • Page 11 ASSEMBLY INSTRUCTIONS STEP 8 Make sure that the holes in the FOOTBAR(32) are facing toward the end of the AeroPilates® Precision Series Reformer 610 as shown in the illustration. Insert the FOOTBAR(32) into the mounting holes located in the FRONT WOODEN PLATFORM(28) and FRONT BRACE(4). Insert the FOOTBAR(32) all the way to the bottom and lock it in place with the LOCKING KNOBS(41).

  • Page 12: Operational Instructions

    OPERATIONAL INSTRUCTIONS LOAD ADJUSTMENT The AeroPilates® Precision Series Reformer 610 has four springs: two HIGH TENSION SPRINGS(55) identified with yellow bands and two LOW TENSION SPRINGS(56) identified with blue bands. The resistance of the CARRIAGE(17) can be adjusted by attaching the springs to the EYEHOOKS(45). Springs are easily changed between exercises for an uninterrupted workout.
  • Page 13 OPERATIONAL INSTRUCTIONS ROPE LENGTH ADJUSTMENT The ROPE(62) feeds through the PULLEY SET(51), Loop A and Loop B, then hook its ball end on the hook on the Loop A underside of the top edge of the CARRIAGE(17). You can adjust the length between the PULLEY SET(51) and the HAND/FOOT STRAP(61).
  • Page 14 OPERATIONAL INSTRUCTIONS CUSTOMIZING HAND/FOOT STRAP LENGTH Ideal hand/foot strap length will vary depending on your height and limb length. To determine your ideal hand/foot strap length, begin by placing the hand/foot straps over the shoulder rests as shown below. Adjust the hand/foot straps so they are taut.
  • Page 15 OPERATIONAL INSTRUCTIONS PULLEY HEIGHT ADJUSTMENT Standard Setting- the top setting The standard height setting for the reformer pulleys is the top setting. At the top setting, the pull of the ropes provides the most support and feedback for the body. Place your pulleys at the top setting to most easily achieve proper form and to engage the core muscles.

  • Page 16: Storage

    STORAGE 1. To store the AeroPilates® Precision Series Reformer 610, simply keep it in a clean dry place. 2. It is recommended that two people be available to move the AeroPilates® Precision Series Reformer 610. 3. To move the AeroPilates® Precision Series Reformer 610: First, attach one of the TENSION SPRINGS to the EYEHOOK(45) to prevent the CARRIAGE(17) from moving.

  • Page 17: Conditioning Guidelines

    CONDITIONING GUIDELINES How you begin your exercise program depends on your physical condition. If you have been inactive for several years or are severely overweight, start slowly and increase your workout time gradually. Increase your workout intensity gradually by monitoring your heart rate while you exercise. Remember to follow these essentials: Have your doctor review your training and diet programs.

  • Page 18: Warm-Up And Cool-Down

    WARM-UP and COOL-DOWN Warm-Up The purpose of warming up is to prepare your body for exercise and to minimize injuries. Warm up for two to five minutes before strength training or aerobic exercising. Perform activities that raise your heart rate and warm the working muscles. Activities may include brisk walking, jogging, jumping jacks, jump rope, and running in place.

  • Page 19: Warranty

    LIMITED WARRANTY MODEL 55-5610 WARRANTY Stamina Products, Inc. (“Stamina”) warrants to the original purchaser that this product will be free from defects in materials and workmanship that arise under normal use, service, proper assembly and proper operation in accordance with product warnings/instructions for a period of 90 days on the parts and five years on the frame from the date of the original purchase from an authorized retailer.

  • Page 20: Product Parts Drawing

    PRODUCT PARTS DRAWING BACK FRONT...

  • Page 21: Parts List

    PARTS LIST PART# PART NAME Front Leg Middle Leg Rear Leg Front Brace Rear Brace Front Left Rail Front Right Rail Rear Left Rail Rear Right Rail Middle Brace Left Hinge Right Hinge End Support Plate Front Middle Support Plate Rear Middle Support Plate Pulley Riser Carriage...
  • Page 22 PARTS LIST PART# PART NAME Connector Bolt (M5 x 0.8 x 22.2mm) Connector Shaft Pulley Pulley Bracket Cover Pulley Spacer Large Washer (Ø32 x Ø8.7 x 2mm) High Tension Spring, Yellow Marked Low Tension Spring, Blue Marked Caution Label Serial Decal Rear Spring Strap Front Spring Strap Hand Strap...

  • Page 23: Fax/Mail Ordering Form

    TO CONTACT CUSTOMER SERVICE TO CONTACT CUSTOMER CARE For your convenience, Stamina’s customer care representatives can be reached by email at customer.care@staminaproducts. com or by phone at 1-800-375-7520 (in the U.S.). Our customer care representatives are available Monday through Thursday from 7:30 a.m.
