Summary of Contents for Cardinal PS-4
- Page 1 MODEL PS-4 DIGITAL PORTION SCALE OWNER’S MANUAL CARDINAL SCALE MFG. CO. 8528-M317-O1 Rev A PO BOX 151 WEBB CITY, MO 64870 07/05 PH (417) 673-4631 FAX (417) 673-5001 Web Site - http://www.detectoscale.com...
-
Page 3: Table Of Contents
INTRODUCTION TABLE OF CONTENTS Thank you for purchasing our Detecto Model Installation …………………..………………. 1 PS-4 Digital Portion Scale. The PS-4 is Unpacking ……………………..………… 1 equipped with a Stainless Steel platform that is Power Supply …………………..………. 1 easily removed for cleaning. With the included Batteries ………………………..……….. -
Page 4: Installation
INSTALLATION UNPACKING Before beginning installation of your scale, make certain the instrument has been received in good condition. When removing the scale from its packing, inspect it for signs of damage, such as exterior dents and scratches. Keep the carton and packing material for return shipment if it should become necessary. -
Page 5: Display Annunciators
DISPLAY ANNUNCIATORS The annunciators are turned on to indicate that the scale display is in the mode corresponding to the annunciator label or that the status indicated by the label is active. The O annunciator is turned on when the weight display is stable. lb oz Both the lb and oz annunciators are turned on to indicate that the displayed weight is in pounds and ounces. -
Page 6: Operation
OPERATION TURN THE SCALE ON Press the ON/OFF key to turn the scale on. The scale will display then change to the selected weighing units. SELECT THE WEIGHING UNIT Press the UNIT key to alternate between the selected weighing units. . WEIGH Place the item to be weighed on the scale tray. -
Page 7: Display Messages
(+10%) CARE AND MAINTENANCE The heart of the PS-4 Digital Portion Scale is a precision load cell located in the center of the scale base. It will provide accurate operation indefinitely if protected against overload of scale capacity, dropping items on scale, or other extreme shock.
