  • Page 1 Product Guide 162 cm 62cm 103 cm 137.1 cm Now with MAPS Mimaki Advanced Pass System The information in this document is subject to change without notice 24-04-2014 Mimaki Europe B.V. Sign Graphics Products V1.2EU...

  • Page 2: Terms Of Use

    Mimaki Europe B.V. • Contents and technical explanations in this presentation are based on the test results achieved at Mimaki at the time of testing and are not a guarantee for performance. Substrates should be tested beforehand. •...
  • Page 3 Newly developed Achieve high quality reduced production time Continuous (overnight) printing Print Head Automatic change of double ink cartridge Automatic media clamp function (Positions: off/low/middle/high) Cutter head Tool holder Automatic Intelligent heater take-up device Mimaki Europe B.V. Sign Graphics Products...
  • Page 4 • max speed 17.5 m²/h, standard mode 11.9 m²/h • Cutting speed up to 30 cm/s • MAPS, Mimaki Advanced Pass System, included • Printing with higher quality at higher speeds • Available from firmware version 3.20 and higher Mimaki Europe B.V.
  • Page 5 • Continuous Crop Mark detection • for accurate contour cutting and increases the productivity • Cuts the image directly after printing • using fast-drying SS21 solvent ink Mimaki Europe B.V. Sign Graphics Products...
  • Page 6 Space savings up to 40% in relation to purchasing a separate printer and cutter. • Bundled RIP, cutting and creation software • Rasterlink Pro5 SG, FineCut, Simple Studio, • Plug-ins for Adobe Illustrator and Corel Draw Mimaki Europe B.V. Sign Graphics Products...
  • Page 7 Target markets – CJV30-60 / CJV30-100 Unique in its size, new markets/users and affordable Target users Applications The CJV30-60/100 are unique in its sizes Car/van fleet hire Vehicle graphics and target different markets than the Companies with large Vehicle graphics CJV30-130 and CJV30-160.
  • Page 8 162 cm many characteristics of the award winning JV33 series, making it a very Max. Print/Cut Width Max. Print/Cut Width strong printer/cutter. 1361mm (53.6”) 1610 mm (63.4”) Media Width 1371mm (54.0’’) Media Width 1620mm (63.4’’) Mimaki Europe B.V. Sign Graphics Products...
  • Page 9 Thanks to the combination of the high speed print head and the SS21 ink, CJV30 series prints with excellent performance • Also the design of ink color arrangement contributes to high speed and high quality printing Mimaki Europe B.V. Sign Graphics Products...
  • Page 10 CJV30-130(4C) 16,7 540x720,4P,Bi,Hi 13,3 11,4 540x1080,6P,Bi,Hi MAPS OFF MAPS (目安値) Optimum value 720x1080,6P,Bi,Hi m²/h When printing in the lowest pass of each resolution with high speed scan, MAPS can be set only to minus Mimaki Europe B.V. Sign Graphics Products...
  • Page 11 MAPS. CJV30-130/160→Ver3.20 or later The effect of MAPS varies depending on print mode, print data, and media. MAPS does not guarantee the improvements of the whole image quality. Mimaki Europe B.V. Sign Graphics Products...
  • Page 12 MAPS, ink drops are fired sparsely at the boundaries of passes. • This reduces banding which tends to appear when printing in high production (Low pass) mode MAPS: OFF (Normal) MAPS: ON Feed direction Scan direction Ejects ink in bands Ejects ink sparsely Mimaki Europe B.V. Sign Graphics Products...
  • Page 13 MAPS Off vs MAPS Optimum • Print mode: 540x720, 4P, Bi, Hi • Machine: CJV30-160(4C) • Media: GPVC • Ink: SS21 MAPS OFF: 17.5㎡/h MAPS ON (-20%): 14㎡/h C100Y100 C100Y100 Banding appears Banding is reduced Mimaki Europe B.V. Sign Graphics Products...
  • Page 14 MAPS: Off vs MAPS +50% CJV30-160(4C) 540x1080,12P,Bi,Hi MAPS OFF 720x1080,12P,Bi,Hi MAPS (+50%) 720x1440,16P,Bi,Hi ㎡/h CJV30-130(4C) 540x1080,12P,Bi,Hi MAPS OFF 720x1080,12P,Bi,Hi MAPS (+50%) 720x1440,16P,Bi,Hi ㎡/h Except for the minimum passes, MAPS can be set in plus. Mimaki Europe B.V. Sign Graphics Products...
  • Page 15 MAPS Off vs MAPS +50 • Print mode: 540x1080, 12P, Bi, Hi • Machine: CJV30-160(4C) • Media: GPVC • Ink：SS21 MAPS OFF: 6.1㎡/h MAPS ON (+50%): 9.1㎡/h No bleeding, and no banding Bleeds a little, but no banding Mimaki Europe B.V. Sign Graphics Products...
  • Page 16 When printing in the lowest pass of each resolution with high speed scan, MAPS does not work when the value is set to 0% or more (plus). The set value of MAPS above is just examples. The value can be changed according to customer’s situation. Mimaki Europe B.V. Sign Graphics Products...
  • Page 17 For wider models (100, 130, clamp lifting levels (low/middle/high), depending on 160) a third clamp in the middle is down. the thickness of the media. The clamps which are not needed are automatically lifted. Mimaki Europe B.V. Sign Graphics Products...
  • Page 18 Automatic Media Clamp function • Automatic switching from printing to cutting with the automatic Media Clamp function is handy and saves time. The fast drying SS21 ink and Automatic Media Clamp Function win every time. Mimaki Europe B.V. Sign Graphics Products...
  • Page 19 Y axis direction can be cut aligning each image automatically. Correction part Even when lamination is done after printing, the machine can automatically cut contours using this automatic correction function. High accuracy, no matter how many copies. Mimaki Europe B.V. Sign Graphics Products...
  • Page 20 Half-Cut function • A proprietary technology of Mimaki All Mimaki cutters include Mimaki’s original Half-Cut function. This function produces a series of half- and die-cuts leaving a few connection points that keep the image in place. When the job is done the sticker/ image can be taken out easily or the complete sheet or roll can be sent to the customer.
  • Page 21 It saves time printing simultaneously white and other colors, especially with lengthy prints. (6 color + white mode) 6 colour print 6 colour print + white mode Mimaki Europe B.V. Sign Graphics Products...
  • Page 22 Fast drying, less bleeding, immediate cutting after printing* Weak Odor Strong Odor ES3 Ink Less odor, can be used in an office Slow drying Depending on media, cutting immediately after printing may cause shrinking Mimaki Europe B.V. Sign Graphics Products...
  • Page 23 Lc C K M C Lc K Y C M Lm • 6 colour setting + white to widen your business opportunities M C Y K Lc Lm W W Lm K Lc Mimaki Europe B.V. Sign Graphics Products...
  • Page 24 • Long uninterrupted printing (880cc per color) in 4-color mode is possible with the UISS function, which is a successful feature of the Mimaki printers. When one of the two ink One roll of 50 meter media can be cartridges is empty, the ink...
  • Page 25 Automatic take-up device • The automatic take-up device enables fast and steady winding of the media. • Media plate • The media plate prevents Media Plate media from lifting and jamming. It assures stable printing. Mimaki Europe B.V. Sign Graphics Products...

  • Page 26: Easy Operation

    Roll holder (compatible with which can hold media with 2 inch and 3 inch core media) a 2 inch and 3 inch core. • The roll stopper helps to set the media easily. Roll stopper Mimaki Europe B.V. Sign Graphics Products...

  • Page 27: Easy Maintenance

    • The maintenance cleaning fluid is set on the rear of the Cleaning Cartridge machine and is for pump cleaning automatically sent to the capping area. Mimaki Europe B.V. Sign Graphics Products...
  • Page 28 RIP in the same way for Illustrator® and CorelDraw®. can be created. It is easy to create FineCut outputs to a plotter. stickers with a high quality design. Mimaki Europe B.V. Sign Graphics Products...

  • Page 29: Specifications

    (W x D x H) (60" x 29.1" x 56.0") (76.1" x 29.1" x 56.0") (90.1" x 29.1" x 56.0") (99.9" x 29.1" x 56.0") 110kg 130kg 145kg 160kg Weight (242 lbs.) (286 lbs.) (319 lbs.) (352 lbs.) Mimaki Europe B.V. Sign Graphics Products...

  • Page 30: Options And Supplies

    Standard blade for vinyl (3 pcs) SPB-0030 Blade for vinyl and paper (3 pcs) SPB-0001 Blade for small character (3 pcs) SPB-0003 Blade for reflective sheet (2 pcs) SPB-0006 Blade for fluorescent type vinyl (3 pcs) SPB-0007 Mimaki Europe B.V. Sign Graphics Products...

This manual is also suitable for:

Cjv30-100Cjv30-130Cjv30-160
