Summary of Contents for MIMAKI JV 300 Series
-
Page 1: User Manual
COLOR INKJET PRINTER Firmware (FW) Version Updater User Manual MIMAKI ENGINEERING CO., LTD. URL: http://mimaki.com/ D203259-10 Original instructions... - Page 2 Check the current FW version of the printer. Download the [Installer downloader of FW VersionUpdater for JVCJV300/150 series download tool from Mimaki website. Download the [Installer downloader of FW VersionUpdater for JVCJV300/150 series] installer. Install the [Installer downloader of FW VersionUpdater for JVCJV300/150 series.
- Page 3 Follow Step 4 onward. ● When downloading from the Web site Step 2. Download the [Installer downloader of FW VersionUpdater for JVCJV300/150 series] download tool from Mimaki website. Download the [Installer downloader of FW VersionUpdater for JVCJV300/150 series] download tool from the link below: Japanese: http://japan.mimaki.com/product/inkjet/i-roll/jv300-series/...
- Page 4 Step 4. Install the [Installer downloader of FW VersionUpdater for JVCJV300/150 series]. Double-click [FW_VersionUpdater_for_(C)JV300_ 150[2.20]series_Installer.exe] and execute the installation. FW_VersionUpdater_for_ (C)JV300_150[2.20]series_ Installer.exe [Microsoft Visual C++2008 Redistributable setup] may be appeared. If the message is displayed, follow the instructions in the wizard to install it. Follow the instructions in the wizard.
- Page 5 Follow the instructions in the wizard. Read carefully about SOFTWARE LICENSE AGREEMENT and select [I accept the terms in the license agreement] and click [Next]. Specify the folder to which you want to install and click [Next].
- Page 6 Click the [Install] button. The program installation begins automatically. Click the [Finish] button. After the installation is finished, restart the computer.
- Page 7 Step 5. Update the FW version of the printer with [Installer downloader of FW VersionUpdater for JVCJV300/150 series]. Double-click the [Installer downloader of FW VersionUpdater for JVCJV300/150 series] icon on the desktop to run the software. Click [Next] and start the FW version update. ...
- Page 8 Wait for 5 seconds until the power is turned off completely. Click [Next] on the FW updater. Connect one Mimaki printer to the computer with USB2.0 cable. After connecting, click [Next] on the FW updater. If you are connecting 2 or more printers to the computer, an error message will appear and the FW version cannot be updated.
- Page 9 By following the instructions on the screen, set a media ① on the printer and press ② [ ＜ ] key on the printer. Press ③ [FUNC3]key and make the printer REMOTE mode. Click [Next] on the FW updater. Printer information is automatically loaded into the computer. After printer information acquisition, setting data is automatically loaded into the computer.
- Page 10 Press ① [END/POWER] key on the printer and then follow the message, and press ② [ENTER] key to turn off the printer. Click [Next] on the FW updater. Turn OFF the main power switch ① [INLET1] of the printer. Wait for 5 seconds until the power is turned off completely. Click [Next] on the FW updater.
- Page 11 Select the "A" pattern on the display of the printer. Click [Next] on the FW updater. When the "B" pattern is selected, it failed to startup with the FW update mode. Please retry from Step.5-(17) to restart the printer and follow the instruction on the screen.
- Page 12 Select "A" or "B" on the display of the printer. Click [Next] on the FW updater. A: Go to Step.5-(30), and carry out until Step.5-(37). B: Go to Step.5-(38). ● When you selected the "A" pattern. Press ①[END/POWER] key on the printer to turn off the printer.
- Page 13 Press ①[END/POWER] key on the printer to turn on the power. Click [Next] on the FW updater. Go to Step.5-(40) ● When you selected the "B" pattern. Press ① [ENTER] key on the printer. Click [Next] on the FW updater. The FW version upgrade is started.
- Page 14 If either of the left screens* is displayed, the FW upgrade is finished. Press [finish] on the FW updater. *There are two different displays, ① and ② , depending on the printer setting. ① ② Confirm whether the printer FW has been upgraded properly. Check the printer FW version by the same procedure as Step1.
-
Page 15: Warning List
Warning List During Downloading the FW Version Updater Check the Internet connection and try the download again. During Download the FW Version Updater Save in the different place. While Running the FW Version Updater[W001] Select the [Remote] mode and retry the current step. -
Page 16: Error List
FW Version Update Error[E001] Confirm the state of the printer and retry the current step. Retry from Step5-1. Call your local dealer or Mimaki subsidiary. FW Version Update Error[E003] Confirm the state of the printer and retry the current step. - Page 17 FW Version Update Error[E006] Confirm the state of the printer and retry the current step. Retry from Step5-1. Call your local dealer or Mimaki subsidiary. FW Version Update Error[E007] Confirm the state of the printer and retry the current step.
- Page 18 FW Version Update Error[E010] Confirm the state of the printer and retry the current step. Retry from Step5-1. Call your local dealer or Mimaki subsidiary. FW Version Update Error[E011] Confirm the state of the printer and retry the current step.
- Page 20 Firmware (FW) Version Updater User Manual December, 2017 MIMAKI ENGINEERING CO.,LTD. 2182-3 Shigeno-otsu, Tomi-shi, Nagano 389-0512 JAPAN D203259-10-08122017...
