Replacing Batteries - Pro-Ject Audio Systems Pro-Ject MaiA DS Instructions For Use Manual

Note: Learning other remote control commands via Box Control App is not possible with MaiA DS.
This feature is only available with Remote Box S.

Replacing batteries

Proceed as follows:
 Unlock and slide open the battery case cover
 Replace the battery.
Make sure the battery is the right way round !

Close the battery case cover
Battery type: 1 x CR2032 / 3V or 1 x CR2025 / 3V
Do not dispose the batteries as ordinary domestic refuse. Please dispose your exhausted batteries at
the appropriate collection sites - usually located at supermarkets and drugstores.
Technical specifications Pro-Ject MaiA DS
Power output :
Frequency response :
Channel separation :
Noise floor :
THD :
Gain :
Line level inputs :
Line input sensitivity :
Line input impedance :
Phono input :
Phono input impedance MM/MC :
Phono input gain MM :
S/PDIF coaxial input :
S/PDIF optical input :
USB input :
USB data transfer :
Digital to Analogue converter :
Variable line level output :
Fixed line level output :
Subwoofer output :
Bluetooth version:
Bluetooth music receiver codec :
Bluetooth range :
Speakers connectors:
Headphone output :
Trigger sockets:
Outboard power supply :
Power consumption :
Replacement battery remote control :
Dimensions W x H x D (D with sockets) : 206 x 72 x 150 (165)mm
Weight :
2x 40W/55W at 8 ohms/4 ohms (both channels driven)
20Hz - 20kHz (-0,3dB, -2,5dB)
> 65dB at 20kHz
> -90dB (A weighted)
< 0,07% at 15W
34dB (measured via line level input)
3 pair RCA
350mV
50kohms
1 pair RCA
47kohms/100ohms
44dB
up to 24bit and 192kHz
up to 24bit and 96kHz
USB Audio Class 2 requires USB 2.0 or higher on computer
Asynchronous with DSD DoP 64/128/256 support
PCM1796 24bit/192kHz Multi-bit Delta Sigma type
1 pair RCA
1 pair RCA
1x RCA
2.1 +EDR
aptX, A2DP profile, SPP for an app remote control
10 meters in direct visibility between source and receiver
4mm banana plugs, spades connectors or naked wire
6,3mm jack (16 – 600ohms)
2,5mm 2-pole
24V/5A DC, suitable for your country's mains supply
max. 5A DC, <1W in standby
1 x CR2032 / 3V or 1 x CR2025 / 3V
1550 g without power supply
© Pro-Ject Audio Systems · Pro-Ject MaiA DS · Revision 2016.2.1
7
