Pairing with Apple devices

Tap on Settings, tap on Bluetooth, turn on Bluetooth, your device will automatically start searching for
available devices. Tap on "MaiA" and confirm by pressing power button on MaiA once the blue LED of the
input 9 is fast blinking.
MaiA can store up to 8 Bluetooth devices. If the memory is full then it is not possible to pair another
device. For erasing the memory turn off the unit > disconnect power supply > press and hold power
button > connect power supply > hold power button for 5 seconds > release power button. The blue
!
LED above the power button will blink for few seconds. Once the LED stops blinking, memory is
erased and you can turn on the unit.

Replacing batteries

Proceed as follows:

Unlock and slide open the battery case cover

Replace the battery.
Make sure the battery is the right way round !

Close the battery case cover
Battery type: 1 x CR2032 / 3V or 1 x CR2025 / 3V
Do not dispose the batteries as ordinary domestic refuse. Please dispose your exhausted batteries at
the appropriate collection sites - usually located at supermarkets and drugstores.

Technical specifications Pro-Ject MaiA

Power output :
Frequency response :
Channel separation :
Noise floor :
THD :
Gain :
Line level inputs :
Line input sensitivity :
Line input impedance :
Phono input :
Phono input sensitivity :
Phono input impedance :
Phono input gain :
S/PDIF coaxial input :
S/PDIF optical input :
USB input :
USB data transfer :
Digital to Analogue converter :
Variable line level output :
Bluetooth music receiver codec :
Bluetooth range :
Speakers connectors:
Outboard power supply :
Power consumption :
Replacement battery remote control :
Dimensions W x H x D (D with sockets) : 206 x 36 x 150 (165)mm
Weight :
2x 25W/37W at 8 ohms/4 ohms (both channels driven)
20Hz - 20kHz (-0,3dB, -2,5dB)
> 65dB at 20kHz
> -90dB (A weighted)
< 0,07% at 15W
31dB (measured via line level input)
2 pair RCA + 1 jack 3.5mm
350mV
50kohms
1 pair RCA
suitable for MM, MI or high output MC cartridges
47kohms
40dB
up to 24bit and 192kHz
up to 24bit and 96kHz
USB Audio Class 2 requires USB 2.0 or higher on computer
Asynchronous
Cirrus Logic CS4344 24bit/192kHz Multi-bit Delta Sigma type
jack 3.5mm
aptX, A2DP profile
10 meters in direct visibility between source and receiver
4mm banana plugs, spades connectors or naked wire
20V/3A DC, suitable for your country's mains supply
max. 3A DC, <0.5W in standby
1 x CR2032 / 3V or 1 x CR2025 / 3V
1250 g without power supply
© Project Audio Systems · Pro-Ject MaiA · Revision 2014.7.8
5
