- Page 1 SH/VH/VB Series LCD Display TV Tuner Box and Remote Control Installation and Operation Guide...
- Page 2 This guide is written for the SH, VH and VB series LCD displays. The descriptions of functions are common to all these series displays unless indicated by (SH series), (VH series) or (VB series) in this guide, which means that the function or term is only available on the specific series...
-
Page 3: Table Of Contents
Power on, off and standby ..........8 Turning the display on ............8 Putting the display to standby ..........8 Turning the display off (SH series) ........8 Switching inputs ............... 8 Viewing traditional (analog) or digital TV ..... 9 Adjusting sound settings ..........9 Adjusting the volume ............9... - Page 4 Picture menu (VB series) ..........20 Adjusting the contrast ............21 Adjusting the brightness ............22 Setting up Personal Picture mode ........22 Senseye menu (SH series) ..........23 Senseye menu (VB series) ..........24 Feature menu (VH series) ..........25 Window menu (SH/VH series) ........26 TV menu ................27...
-
Page 5: Package Contents
Package contents Check the package to see if all the following items are included. If any item is missing or damaged, contact your place of purchase immediately and notify them of the discrepancy. Screw × 1 TV tuner box × 1 Installation and operation guide ×... - Page 6 2. Remove the screw that secures the metal box in the TV tuner box slot using a suitable screwdriver. 3. Use the screwdriver to remove the metal box from the slot and keep it in a safe place (for example, places inaccessible to small children).
- Page 7 6. Use the supplied screw and a suitable screwdriver to secure the TV tuner box on the display. 7. Connect the cable TV or aerial antenna cable to the TV cable connector on the TV tuner box. Follow the instructions of "Searching and storing TV channels"...
-
Page 8: Activate The Remote Control
Activate the remote control Installing batteries 1. Turn the remote control to reveal its back side, and open the lid of the battery compartment. 2. Insert the batteries (supplied) ensuring that the positive and negative marked battery terminals match the (+) and (-) marks in the battery compartment. -
Page 9: Getting To Know The Remote Control
See "Adjusting backlight" on page Senseye Press this button to display the Senseye menu. See "Senseye menu (SH series)" on page 23 "Senseye menu (VB series)" on page 9. 影像模式 (Picture Mode) Press this button to select a desired preset picture mode. - Page 10 12. 音場效果 (EQ Mode) Press this button to select from preset EQ modes. See "Selecting a preset EQ mode" on page 13. Channel selection Press these buttons to select the channel you wish to view. See "Selecting a channel directly" on page 14.
- Page 11 21. Red button In DTV mode, press this button to execute the function as indicated by the red color in the menu (A separate DTV tuner is required to use this function). 22. Green button In DTV mode, press this button to execute the function as indicated by the green color in the menu (A separate DTV tuner is required to use this function).
-
Page 12: Using The Remote Control
The display still consumes about 1W (VH series)/1.5W (SH/VB series) of power in standby mode. Turning the display off (SH series) You can turn the display power off by flipping the main power switch on the display to the off (O) position. The power indicator will be off. -
Page 13: Viewing Traditional (Analog) Or Digital Tv
• These options will only appear when corresponding signals are connected to the display. DTV will only appear when the optional DTV tuner is installed. • If both Composite Video (AV) and S-Video signals are connected to the AV input at the same time, only S-Video input will be displayed. -
Page 14: Changing Channels
Changing channels Selecting a channel directly • To select a single- or double-digit channel, press the corresponding channel selection buttons on the remote control. For example, to select channel 8, press on the remote control. • To select a triple-digit channel, press 100+ on the remote control followed by the rest of the digits. -
Page 15: Using The Pip (Picture-In-Picture) Function (Sh/Vh Series)
The table below shows the availability of the PIP function under different Video and Graphic signal input combinations for the Main and Sub pictures. Main picture input HDMI1, HDMI ATV DTV AV1, AV2 (AV3-S)/AV4 HDMI2 (VH series) (AV4-S) (SH series) － － － － ○ ○ － － －... -
Page 16: Adjusting Aspect Ratio
Adjusting aspect ratio The display can resize and reshape an image to suit your requirements. The visual result will depend upon the setting your have chosen, and the original 畫面比例 (Aspect) aspect ratio of the input image. Press on the remote control to cycle through the aspect ratios. -
Page 17: Using The Sleep Timer
Using the sleep timer The sleep timer is useful if you want the display to automatically to go into standby mode after a set period of time. 1. Press 定時關機 (Sleep Timer) on the remote control to activate the sleep timer function. -
Page 18: On-Screen Display (Osd) Menu
On-Screen Display (OSD) menu OSD structure Input signal type HDMI AV1 (VB AV2/AV2-S (VB/VH series) (VB series) series) (Video AV3/AV3-S HDMI1/ AV1, AV2 mode) mode) or AV4/ HDMI2 (SH/VH AV4-S (SH/ series) VH series) series) • Volume • Balance • Sound Type Audio •... - Page 19 Digital Channels • Language • Backlight Setup • Sleep Timer (SH/VH • ECO • HDMI/DVI Input (SH series)/DVI Input (VH series) series) • Blue Screen (SH series) • Reset All Settings • Language • Sleep Timer Setup • ECO • HDMI/DVI Input series) •...
-
Page 20: Navigating The Osd Menu
You can use the On-Screen Display (OSD) menu to adjust the settings on your display. To display the OSD menu, press 目錄 (Menu) on the remote control (the main OSD menu of the SH series display is shown below): Audio Picture Senseye... -
Page 21: Audio Menu
Audio Volume Audio menu Balance Sound Type Stereo The available menu items are Steady Sound dependent on the input source Surround being selected. The illustration is for reference only. Speaker Out Advanced Audio Settings > 回上頁 Item Function Operation Range Adjusts the volume level of Press to increase or... -
Page 22: Setting Up Personal Eq Mode
• Rock • JAZZ To restore a factory preset or Press to change EQ Mode • Classic selection. user customized EQ Mode. • POP • Personal Adjusts treble tones for the Treble Personal EQ Mode. Adjusts mid-treble tones for Mid Treble Personal EQ Mode. -
Page 23: Picture Menu (Sh/Vh Series)
Picture Picture Mode Personal Picture menu (SH/VH Contrast series) Brightness Color The available menu items are Sharpness dependent on the input source Color TEMP. Normal being selected. The illustration is NTSC Tint for reference only. NTSC Setup 7.5 IRE 回上頁 Item Function Operation... -
Page 24: Picture Menu (Vb Series)
Adjusts color tint in NTSC video. Press for redder NTSC Tint tones, for greener 0 to 64 This option is only available for tones. NTSC video sources. Sets up the NTSC video display format to match that of the input NTSC video input from other •... -
Page 25: Adjusting The Contrast
Adjusts image white level so that Press for brighter whites do not wash out Contrast whites, for darker surrounding colors. See "Adjusting whites. the contrast" on page Adjusts image black level, so that Press for brighter detail in the dark areas of an image 0 to 64 Brightness blacks,... -
Page 26: Adjusting The Brightness
Adjusting the brightness 1. Set the brightness to the lowest level. 2. Gradually increase the brightness level until you reach the point where the details in the dark areas of the image can be seen clearly. Do not further increase the brightness level to avoid the black areas from looking grayish. Setting up Personal Picture mode You can adjust the settings in the Picture... -
Page 27: Senseye Menu (Sh Series)
Senseye menu (SH series) Color Style Color 1 Gamma Style Gamma 1 The available menu items are dependent on the input source Noise Reduction being selected. The illustration is for reference only. 回上頁 Item Function Operation Range • Color 1 •... -
Page 28: Senseye Menu (Vb Series)
Senseye menu (VB series) Black Extension The available menu items are Noise Reduction dependent on the input source being selected. The illustration is for reference only. 回上頁 Item Function Operation Range Enhances the contrast among details when viewing dark • Low images. -
Page 29: Feature Menu (Vh Series)
Feature Feature menu (VH series) Black Extension The available menu items are Noise Reduction dependent on the input source Aspect Ratio 16:9 being selected. The illustration is for reference only. 回上頁 Item Function Operation Range Enhances the contrast among details when viewing dark •... -
Page 30: Window Menu (Sh/Vh Series)
Window Window menu (SH/VH series) Main Input The available menu items are Sub Input dependent on the input source PIP Audio Main being selected. The illustration is for reference only. 回上頁 Item Function Operation Range • Off Display Video and Graphic Full screen images simultaneously in Picture-In-Picture (PIP) mode. -
Page 31: Tv Menu
TV menu TV/CATV Channel +/- Added The available menu items are dependent on the input source Favorite Channels being selected. The illustration is Auto Program for reference only. 回上頁 Item Function Operation Range • TV Select TV or cable TV/CATV system mode. -
Page 32: Setup Menu (Sh/Vh Series)
10 minutes. Select the DVI input mode according to HDMI/DVI Input the device connected. Select if a PC is (SH series) • PC connected. If a video device (for example, DVI Input (VH • Video a digital Set Top Box) is connected, select... -
Page 33: Setup Menu (Vb Series)
Setup Setup menu (VB Language English series) Sleep Timer The available menu items are HDMI/DVI Input dependent on the input source Blue Screen being selected. The illustration is Reset All Settings for reference only. 回上頁 Item Function Operation Range • English Select your desired language for the OSD Language menu. - Page 34 <Memo> On-Screen Display (OSD) menu...
