- Page 1 Installation, Operation, & Maintenance Model: ECCO-AP, Electric Full Size Convection Oven Lang Manufacturing Company 6500 Merrill Creek Parkway Everett, WA 98203 Rev. C Phone: 425-349-2400 Fax: 425-349-2733 Part # 60800-32 WWW.LANGWORLD.COM © Copyright 2001...
- Page 2 Model #: Purchased From: Serial #: Location: Date Purchased: Date Installed: Purchase Order #: For Service, Call: Lang Manufacturing Company 6500 Merrill Creek Parkway Everett, WA 98203 Rev. C Phone: 425-349-2400 Fax: 425-349-2733 Part # 60800-32 WWW.LANGWORLD.COM © Copyright 2001...
-
Page 3: Table Of Contents
TABLE OF CONTENTS CHAPTER PAGE TABLE OF CONTENTS ..................3 READ FIRST ......................4 EQUIPMENT DESCRIPTION ................6 UNPACKING ....................... 7 INSTALLATION ....................8 INITIAL START-UP .................... 11 OPERATION ......................12 MAINTENANCE & CLEANING PROCEDURES ..........15 TROUBLE SHOOTING ..................16 PARTS LIST ...................... -
Page 4: Read First
Never leave a chlorine sanitizer in contact with stainless steel surfaces NOTICE longer than 10 minutes. Longer contact can cause corrosion. Service on this, or any other, LANG appliance must be performed by NOTICE qualified personnel only. Consult your authorized service station directory or call the factory at 1-800-224-LANG (5264), or WWW.LANGWORLD.COM... - Page 5 BEFORE REPLACING ANY PARTS, DISCONNECT THE UNIT FROM THE ELECTRIC POWER SUPPLY. USE OF ANY REPLACEMENT PARTS OTHER THAN THOSE SUPPLIED BY CAUTION LANG OR THEIR AUTHORIZED DISTRIBUTORS CAN CAUSE BODILY INJURY TO THE OPERATOR AND DAMAGE TO THE EQUIPMENT AND WILL VOID ALL WARRANTIES.
-
Page 6: Equipment Description
(53.38 cm) Deep. The interior of the oven is constructed of porcelainized stainless steel. Operation The ECCO-AP oven is a forced air convection oven with a vented oven cavity. The air is driven by a 1/3 HP fan motor. Controls Easy to use manual control knobs. -
Page 7: Unpacking
15 days of delivery. All packing material should be kept for inspection. Do not return damaged merchandise to Lang Manufacturing Company. File your claim with the carrier. -
Page 8: Installation
INSTALLATION DANGER THIS APPLIANCE MUST BE GROUNDED AT THE TERMINAL PROVIDED. FAILURE TO GROUND THE APPLIANCE COULD RESULT IN ELECTROCUTION AND DEATH. WARNING INSTALLATION OF THE UNIT MUST BE DONE BY PERSONNEL QUALIFIED TO WORK WITH ELECTRICITY AND PLUMBING. IMPROPER INSTALLATION CAN CAUSE INJURY TO PERSONNEL AND/OR DAMAGE TO EQUIPMENT. - Page 9 INSTALLATION CONT’D Leg Pad Adapter Identify the front and rear leg adapters (the front adapters have two threaded inserts, the rear has four). Leg to Adapter Installation: Install the leg’s threaded stud through the hole in the adapter labeled “C” with the bent flange of the adapter facing away from the leg.
-
Page 10: Electrical Connection
INSTALLATION CONT’D Ventilation and Clearances Standard minimum clearance from combustible construction is as follows. 4” from side 4” from back 6” from floor These ovens may be set directly, without legs, on a curbed base or non-combustible floor. If the oven is set without legs on a non-combustible floor or a curbed base, maintain a 4-inch back clearance. -
Page 11: Initial Start-Up
INITIAL START UP Pre-Power On After the oven is installed and connected to power, prior to turning on, verify the following: • The doors open and close freely. • All racks are in the oven correctly. • All packing materials have been removed from the inside of the oven. Power On Once oven has been turned on verify that the blower wheel is spinning freely in a clockwise position and that the elements are heating properly. -
Page 12: Operation
OPERATION Control Panel Vent Knob. Power switch. Light switch. Inspection light only. LIGHT Push toggle switch to the up position to inspect product. Switch will automatically return to the off position. Pulse fan switch. Pulse fan PULSE FAN HI-SPEED setting will only turn the fan Dual speed switch. - Page 13 OPERATION CONT’D Hints & Suggestions Convection ovens constantly circulate air over and around the product. This strips away the thin layer of moisture and cool air from around the product allowing heat to penetrate more quickly. Cooking times can be shortened and cooking temperatures can be reduced. To convert standard deck oven recipes, reduce the temperature 50 degrees and the time by 25%.
- Page 14 OPERATION CONT’D Loading When loading and unloading the oven, stage products and racks so the oven doors are opened for the least amount of time. Be sure that racks are level within the oven. Bent or warped pans can greatly affect the evenness of the cook or bake. If using baker’s parchment, be sure the parchment does not blow over the product.
-
Page 15: Maintenance & Cleaning Procedures
Care should be taken to prevent caustic cleaning compounds from coming in contact with the blower wheel. • The oven racks, rack slides, and interior may be cleaned using Lang Mfg. Foam Deluxe (72804-36) oven cleaner. • Discoloration or heat tint may be removed using Lang Mfg. Carbon Release (72804-32) oven cleaner. -
Page 16: Troubleshooting
TROUBLESHOOTING Symptoms What follows is a chart of Symptoms and Possible Causes to aid in diagnosing faults with the oven. Refer to the Symptoms column to locate the type of failure then to the Possible Cause for the items to be checked. To test for a possible causes refer to the TEST section and locate the Possible Cause then refer to test to identify test procedures. - Page 17 If an item on the list is followed by an asterisk (*), the work should be done by a factory authorized service representative. Service on this, or any other, LANG appliance must be performed by NOTICE qualified personnel only. Consult your authorized service station directory or call the factory at 1-800-224-LANG (5264), or WWW.LANGWORLD.COM...
-
Page 18: Parts List
PARTS LIST DESCRIPTION PART NO. Element ECCO Oven 208/240 Volt 11000 Watts 11090-16 Element ECCO Oven 480 Volt 11000 11090-18 Motor 1/3 HP 480 Volt 2 Speed 30200-16 Motor 1/3 HP 208/240 Volt 2 Speed 30200-17 Micro Switch, Oven Door 30301-02 Switch, Toggle, On-Off 30303-06... -
Page 19: Wiring Diagram
WIRING DIAGRAM 208/240... - Page 20 WIRING DIAGRAM 220/380 & 240/415...
-
Page 21: Warranty
WIRING DIAGRAM 480...
