ASSEMBLY & OPERATING INSTRUCTIONS
Important: Read these instructions for use carefully so as to familiarize yourself with the
appliance before connecting it to its gas container. Keep these instructions for future
LPGSASA Permit Number (1185/16/RSA-08/A)
Manufactured in China · Distributed by Mega Group · PO Box 15, Woodlands, 0072, South Africa · Tel: +27 (0) 12 802 1515
This grill is not intended to be
installed in or on recreational
vehicles and/or boats.
www.megamaster.co.za
WARNING
To reduce the risk of fire, burn hazard or other injury,
read the manual carefully and completely before
using your grill.
WARNING
300
400
500
600
2 0 0
100
700
80 0
reference
WARNING
FOR OUTDOOR USE ONLY.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Blaze-300 and is the answer not in the manual?

Questions and answers

Related Manuals for Megamaster Blaze-300

Summary of Contents for Megamaster Blaze-300

  • Page 1 Keep these instructions for future reference LPGSASA Permit Number (1185/16/RSA-08/A) www.megamaster.co.za Manufactured in China · Distributed by Mega Group · PO Box 15, Woodlands, 0072, South Africa · Tel: +27 (0) 12 802 1515 WARNING...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Safety Information ......................3 Package Contents List ...................... 7 Preparation ........................8 Assembly Instructions ....................... 9 Installation Instructions...................... 16 Operating Instructions ....................... 19 Care and Maintenance...................... 22 Troubleshooting ........................ 23 Warranty ........................... 25 Replacement Parts List..................... 27 Recipe List…………………………………………………………………………………………29 DANGER WARNING...

  • Page 3: Safety Information

    SAFETY INFORMATION WARNING Do not try lighting this appliance without first reading WARNING the “LIGHTING INSTRUCTIONS” section of this manual. WARNING – Hazards or unsafe practices which COULD result in severe personal injury or death. CAUTION CAUTION – Hazards or unsafe practices which COULD result in minor personal injury.
  • Page 4 WARNING WARNING Spiders and insects can nest inside the burners Do not leave the grill unattended while cooking. of the grill and disrupt gas flow. Inspect the grill at least twice a year. WARNING Failure to properly place the burner over the orifice could cause a fire to occur behind and beneath the valve panel, thereby damaging the grill and making CAUTION...
  • Page 5 Do not use indoors. WARNING Do not try lighting this appliance without first reading the “LIGHTING INSTRUCTIONS” section of this manual. SAFETY PRACTICES TO AVOID INJURY When properly cared for, your grill will provide safe, reliable service for many years. However, extreme care must be used as the grill produces intense heat that can increase accident potential.
  • Page 6 Exercise caution when cleaning grill. To avoid steam burns, do not use a wet sponge or cloth to clean the grill while it is hot. Some cleaners produce noxious fumes or can ignite if applied to a hot surface. Never use a dented or rusty propane cylinder. Turn off all control knobs and make certain the grill is cool before using any type of aerosol cleaner on or around it.

  • Page 7: Package Contents List

    PACKAGE CONTENTS LIST A. Firebox Assembly -------- B. Bottom Panel--------1pc. C. Wheel-------------------2pcs. 1pc. 3 0 0 4 0 0 5 0 0 2 0 0 6 0 0 1 0 0 8 0 0 7 0 0 D. Side Burner Shelf & Control E.

  • Page 8: Preparation

    V. 1.5 Volt “AA” Size Alkaline W. Grease Box ----------1pc. Battery----------1pc. HARDWARE CONTENTS - Pre-installed as noted in instructions that follow. REF# Description 5/32-in. x 10-mm Truss Head Screw 32pcs. 1/4-in. x 15-mm Truss Head Screw with washer 18pcs. 1/4-in. Flat Washer 16pcs.

  • Page 9: Assembly Instructions

    ASSEMBLY INSTRUCTIONS Fig. 1 1. Cart Assembly a) Place the Cart Caster Inset (K) into the Cart Leg, Front Left (F) and Cart Leg, Back Left (G). As shown in Fig. 1. Fig. 2 b) Loosen, but do not remove the screws that are pre-assembled on the Cart Leg, Front Left (F) and Cart Leg, Back Left (G).
  • Page 10 Fig. 4 Tank Bolt 2. Bottom Panel Assembly a) Loosen, but do not remove the screws that are pre-assembled on the side of the Bottom Panel (B), align the holes on the Cart Leg, Front Left (F) and Cart Leg, Back Left (G), then place the Cart Legs onto the screws that were loosened in the Bottom Panel (B).
  • Page 11 Fig. 7 5. Wheel Assembly a) Remove the nuts and washers which are pre-assembled on the short axle, place the wheels (C) on the Axle attached to Cart Leg, Front Right (I) and Cart Leg, Back Right (J). As show in Fig. 7. b) Place washers closest to the wheel and then place and tighten the nuts on the axle that were removed in step 5a.
  • Page 12 c) Remove the Firebox Assembly (A) from the Fig. 10. A carton and carefully place onto the grill cart. Lid handle will face front and be above front panel. As shown in Fig. 9. d) Once the firebox is in place, secure the Firebox Assembly (A) to Cart Leg Back Right (J) and Cart Leg Back Left (G) using the screws removed in step 8a.
  • Page 13 Fig. 11 8. Side Burner Shelf Assembly Loosen but do not remove the screw which is pre-assembled on the cart leg. Remove the two screws that are attached to the Side 4 0 0 3 0 0 5 0 0 2 0 0 6 0 0 1 0 0...
  • Page 14 Fig. 14 b) Insert Side Burner Control Knob (M) onto the valve stem and tighten it. As shown in Fig. 14. Fig. 15 11. Side Burner Installation a) From underneath the side burner remove two screws which are assembled on the bottom of the side burner shelf (D).
  • Page 15 Fig. 17 12. Electronic Igniter Battery Installation Unscrew the electronic igniter button 3 0 0 4 0 0 5 0 0 2 0 0 6 0 0 1 0 0 7 0 0 8 0 0 and place the battery (V) into the housing with the positive terminal (+) facing outward.
  • Page 16 Fig. 20 15. Liquid Propane Tank Installation Tank Bolt From rear of grill place the LP gas cylinder into the Bottom Panel (B) hole As shown in Fig. 20. 3 0 0 4 0 0 5 0 0 2 0 0 6 0 0 1 0 0 7 0 0...

  • Page 17: Installation Instructions

    INSTALLATION INSTRUCTIONS GAS HOOK-UP Only the pressure regulator and hose assembly supplied with the grill should be used. Any replacement pressure regulator and hose assembly must be specified by the grill manufacturer. This grill is configured for LP gas. Do not use a Natural Gas supply. Total gas consumption (per hour) with all burners set on “HI”: Main burners 40,500 BTU/Hr.
  • Page 18 DISCONNECTING THE LIQUID PROPANE CYLINDER 1. Turn the grill burner valves “OFF” and make sure the grill is cool. 2. Turn the LP gas cylinder valve “OFF” by turning clockwise until it stops. 3. Detach the regulator assembly from the cylinder valve by turning the wheel nut clockwise. 4.
  • Page 19 WARNING 1. Do not store spare LP gas cylinders under or near this appliance. 2. Never fill the cylinder beyond 80 percent capacity. 3. If the information above is not followed exactly, a fire, possibly causing serious injury or death, may occur.

  • Page 20: Operating Instructions

    OPERATING INSTRUCTIONS General Use of the Grill Each main burner is rated at 13,500 BTU/Hr. The main grill burners encompass the entire cooking area and are side ported to minimize blockage from falling grease and debris. Above the burners are flame tamers.
  • Page 21 TO LIGHT THE SIDE BURNER 1. Push and turn Side Burner control knob to IGNITE/HI, at the same time, press and hold electronic ignition button to light the burner. 2. Once the burner is lit, release the electronic ignition button and knob. 3.

  • Page 22: Care And Maintenance

    Fig. 23 IGNITE / HIGH CARE AND MAINTENANCE Stainless Steel There are many stainless steel cleaners available. Always use the mildest cleaning process first, scrubbing in the direction of the grain. Do not use steel wool as it will scratch the surface. To touch up noticeable scratches in the stainless steel, sand very lightly with dry 100 grit sand paper in the direction of the grain.
  • Page 23 Fig. 24 To clean the grill burners: 1. Clean the exterior of the burner with a wire brush. Use a metal scraper for stubborn stains or debris. 2. Clear clogged ports with a straightened paper clip. Never use a wooden toothpick as it may break off and clog the port.

  • Page 24: Troubleshooting

    TROUBLESHOOTING Problems Possible Solutions Grill will not light. 1. Push and turn the knob and check for sparks. 2. If there is a spark, check to make sure gas is supplied to the burner. a. Purge the line of any trapped air. b.
  • Page 25 Problems Possible Solutions Burner blows out. 1. Check for any burner defects. 2. Check for proper burner installation. 3. Make certain the fuel mixture is not too lean. 4. Make sure the gas supply is sufficient. 5. See if the LP tank is empty. Low heat, LP gas.

  • Page 26: Warranty

    Warranty This grill has a one (1) year limited warranty. The warranty period is valid from the date of purchase. This is subject to correct assembly, use, storage and regular maintenance of the product. Please refer to page 10 of this manual for list of replacement parts. Please Note: the main burner has a warranty of three (3) years.

  • Page 27: Replacement Parts List

    REPLACEMENT PARTS LIST WARRANTY WARRANTY REF# DESCRIPTION QTY REF# DESCRIPTION COVERAGE COVERAGE Main Lid Cart Leg Front, Left Hood Buffer B 2pcs 30 Cart Leg Rear, Left Main Lid Screw 2pcs 31 Lighting Rod Main Lid Screw Cover 2pcs 32 Cart Caster Insert 2pcs Temperature Gauge...
  • Page 28 40 0 20 0 80 0...

  • Page 29: Recipe List

    RECIPE LIST Food Weight or Temperature Time Special instructions and tips thickness Vegetables Medium 8 to 20 Slice or chop vegetables and dot with minutes butter or margarine. Wrap tightly in heavy duty foil. Turn occasionally Potatoes Whole Medium 40 to 60 Wrap individually in heavy duty foil.
  • Page 30 This appliance complies with the requirements of SANS 1539 www.megamaster.co.za Manufactured in China· Distributed by Mega Group · PO Box 15, Woodlands, 0027, South Africa· Tel: +27(0)12 802 1515...

This manual is also suitable for:
