Setup Guide
WARNING:
Drum key can be pinched when adjusting clamps with drum key. Operate carefully.
Be careful around pipe ends, inside the pipe and screw ends. Metal shavings, etc. May injure your fingers.
1
Check the include items
CYMBAL PADS BOX
Cymbal Pad for Hi-Hat Cymbal Pad for Crash1
(with Choke)
DRUM PADS BOX
1~3
ACCESSORIES BOX
Hi-Hat Holder
Drum Key
Handscrews X 2
Hexagon Key
Setup Guide
Owner's Manual
STAND AND CYMBAL HOLDER BOX
Pillar (L1)
Pillar (R1)
Cymbal Pad for Ride
Pad Mount X 5
Connection Cable X 11
Pillar (L2)
Pillar (R2)
Cymbal Holder(L)
EXTENDED PADS BOX
HI-HAT PEDAL BOX
Cymbal Pad for Crash2
(with Choke)
DRUM MODULE BOX
4
KICK PEDAL BOX
Drumsticks
AC Adaptor
Center Pipe (1)
Center Pipe (2)
Side Arm (R)
Side Arm (L1)
Side Arm (L2)
Cymbal Holder (R) X 2
Advertisement
Table of Contents
Related Manuals for Medeli DD514
Summary of Contents for Medeli DD514
-
Page 1: Setup Guide
Setup Guide WARNING: Drum key can be pinched when adjusting clamps with drum key. Operate carefully. Be careful around pipe ends, inside the pipe and screw ends. Metal shavings, etc. May injure your fingers. Check the include items CYMBAL PADS BOX EXTENDED PADS BOX HI-HAT PEDAL BOX Cymbal Pad for Hi-Hat Cymbal Pad for Crash1... - Page 2 Set Up the Stand Side Arm (L1) Center Pipe (1) Pillar (L1) Pillar (R1) Center Pipe (2) Pillar (L2) Side Arm Pillar (R2) Side Arm (L2) 1. Attach the Center Pipe (1) to the clamp on the Pillar (L1). 2. Attach the Center Pipe (2) to the clamp on the Pillar (L1). 3.
- Page 3 Attach the Parts Attach the Pads Tom 1 Tom 2 1. Loosen the wing nuts on the drum pads. Wing Nut 2. Attach the drum pads to the pad mounts, and firmly tighten the wing nuts on the Tom 3 drum pads.
- Page 4 Connect the Pads to the Drum Module Attach the Drum Module 1. Connect the cable to the drum module as shown with handscrews. 2. Attach the drum module to the mount holders on Side Arm (L1), and firmly tighten the relevant wing nut. Note: Adjust the drum module position by moving the mount holders as needed, and firmly tighten the relevant wing...
