    UCS1003-2 Evaluation Board User’s Guide  2016 Microchip Technology Inc. DS50002430A...
  • Page 2 WiperLock, Wireless DNA, and ZENA are trademarks of Microchip Technology Incorporated in the U.S.A. and other countries. SQTP is a service mark of Microchip Technology Incorporated in the U.S.A. Microchip received ISO/TS-16949:2009 certification for its worldwide Silicon Storage Technology is a registered trademark of headquarters, design and wafer fabrication facilities in Chandler and Tempe, Arizona;...
  • Page 3 Object of Declaration: UCS1003-2 Evaluation Board  2016 Microchip Technology Inc. DS50002430A-page 3...
  • Page 4 NOTES:  2016 Microchip Technology Inc. DS50002430A-page 4...
  • Page 5: Table Of Contents

    Document Revision History ................... 9 Chapter 1. Product Overview 1.1 Introduction ....................11 1.2 Evaluation System Features ................ 11 1.3 What the UCS1003-2 Evaluation Board Kit Contains ........12 Chapter 2. Installation and Operation 2.1 Getting Started ..................... 13 2.1.1 System Requirements ................13 2.1.2 Evaluation Board Jumper Configuration ............
  • Page 6 UCS1003-2 Evaluation Board User’s Guide Appendix A. Schematics and Layouts A.1 Introduction ....................21 A.2 Board – Schematic ..................22 A.3 Board – Top Silk ..................23 A.4 Board – Top Silk and Copper ............... 23 A.5 Board – Top Copper ..................24 A.6 Board –...
  • Page 7: Preface

    The Microchip Web Site • Customer Support • Document Revision History DOCUMENT LAYOUT This document describes how to use the UCS1003-2 Evaluation Board. The manual layout is as follows: • Chapter 1. “Product Overview” – Important information about the UCS1003-2 Evaluation Board.
  • Page 8: Conventions Used In This Guide

    UCS1003-2 Evaluation Board User’s Guide CONVENTIONS USED IN THIS GUIDE This manual uses the following documentation conventions: DOCUMENTATION CONVENTIONS Description Represents Examples Arial font: ® Italic characters Referenced books MPLAB IDE User’s Guide Emphasized text ...is the only compiler... Initial caps...
  • Page 9: Recommended Reading

    Preface RECOMMENDED READING This user’s guide describes how to use the UCS1003-2 Evaluation Board. Other useful documents are listed below. The following Microchip documents are available and recommended as supplemental reference resources. • UCS1003-1/2/3 Data Sheet – “USB Port Power Controller with Charger Emulation”...
  • Page 10 UCS1003-2 Evaluation Board User’s Guide NOTES:  2016 Microchip Technology Inc. DS50002430A-page 10...
  • Page 11: Chapter 1. Product Overview

    Chapter 1. Product Overview INTRODUCTION The UCS1003-2 device is a Universal Serial Bus (USB) port power switch with charger emulation. All of the functions of the UCS1003-2 device can be tested and observed with the UCS1003-2 Evaluation Board. A block diagram of this evaluation board test...
  • Page 12: What The Ucs1003-2 Evaluation Board Kit Contains

    UCS1003-2 Evaluation Board User’s Guide WHAT THE UCS1003-2 EVALUATION BOARD KIT CONTAINS This UCS1003-2 Evaluation Board Kit includes: • UCS1003-2 Evaluation Board (ADM00669) • Provided 5V Wall Power Adapter • Important Information Sheet  2016 Microchip Technology Inc. DS50002430A-page 12...
  • Page 13: Chapter 2. Installation And Operation

    Jumper Open = Logic High: S0 = 1, Detect mode Note 1: Each of the J7, J12 and J13 headers must be populated with one jumper for the UCS1003-2 Evaluation Board to be functional. The headers that select the power supply source (J5 and J8) must always have 2 jumpers populated on them in total.
  • Page 14 Bench Power Supply Auxiliary Power Connector to AC-DC 5V Power Supply USB Standard-B USB Standard-A Receptacle to Receptacle to Portable USB Host/USB Power Device DP and DM Test Points ALERT and CHRG LEDs FIGURE 2-1: UCS1003-2 Evaluation Board Test Setup.
  • Page 15: Configuration For Dedicated Charger Emulation (Dce) Mode

    1. Configure the jumper settings as shown in Table 2-2. 2. Apply 5V. The UCS1003-2 is set to the Detect state and awaits a downstream device attachment. 3. Connect a tablet or a cell phone to the USB port J10.
  • Page 16: Configuration For Bc1.2 Charging Downstream Port (Cdp) Mode

    2. Connect a cable from USB port J9 (USB-B) to an upstream PC USB port. 3. Apply 5V. The UCS1003-2 is set to the Active state and awaits a downstream device to provide handshake stimulus on the DP pin upon attachment.
  • Page 17: Configuration For Bc1.2 Dedicated Charging Port (Dcp) Mode

    1. Configure the jumper settings as shown in Table 2-4. 2. Apply 5V. The UCS1003-2 is set to the Active state and awaits a downstream device to handshake upon attachment. 3. Connect a tablet or a cell phone to the USB port J10.
  • Page 18: Configuration For Bc1.2 Sdp Mode

    2-5. 2. Connect a cable from USB port J9 (USB-B) to an upstream PC USB port. 3. Apply 5V. The UCS1003-2 is set to the Active state and awaits a downstream device to enumerate the USB upon attachment. TABLE 2-5:...
  • Page 19: Chapter 3. Hardware Overview

    V Note 1: Simple setup that can be made with the AC-DC adapter from the UCS1003-2 Evaluation Board Kit. This setup can be used to evaluate the charging process at different supply voltages (up to 5.5 V) and to have an indication of the charging current from the bench power supply.
  • Page 20: Stand-Alone Functionality

    3.2.1 Charger Emulation Mode Configurations The Charger Emulation mode of the UCS1003-2 is controlled by the pin states: M1, M2 and EM_EN. These are the jumpers located on the J11 header. 3.2.2 Attach Detection and Power States The UCS1003-2 can use the attach detection functionality or force the Active mode power state.
  • Page 21: Appendix A. Schematics And Layouts

    UCS1003-2 EVALUATION BOARD USER’S GUIDE Appendix A. Schematics and Layouts INTRODUCTION This appendix contains the following schematics and layouts for the UCS1003-2 Evaluation Board: • Board – Schematic • Board – Top Silk • Board – Top Silk and Copper •...
  • Page 22: Board - Schematic

    SOD-882 LATCH LATCH 0603 0603 0603 0603 0603 GREEN SHIELD SHIELD 0603 0603 ILIM ILIM SHIELD UCS1003-2 TP LOOP Yellow TP LOOP White HDR-2.54 Male 2x4 0603 0603 HDR-2.54 Male 1x3 0603 0603 0.57A 1.00A 100k 1.13A 1.35A 120k 1.68A HDR-2.54 Male 2x2...
  • Page 23: Board - Top Silk

    Schematics and Layouts BOARD – TOP SILK BOARD – TOP SILK AND COPPER  2016 Microchip Technology Inc. DS50002430A-page 23...
  • Page 24: Board - Top Copper

    UCS1003-2 Evaluation Board User’s Guide BOARD – TOP COPPER BOARD – BOTTOM COPPER  2016 Microchip Technology Inc. DS50002430A-page 24...
  • Page 25: Board - Bottom Silk And Copper

    Schematics and Layouts BOARD – BOTTOM SILK AND COPPER BOARD – BOTTOM SILK  2016 Microchip Technology Inc. DS50002430A-page 25...
  • Page 26: Microchip Technology Inc. Ds50002430A

    UCS1003-2 Evaluation Board User’s Guide NOTES:  2016 Microchip Technology Inc. DS50002430A-page 26...
  • Page 27: Appendix B. Bill Of Materials (Bom)

    Resistor TKF, 0R, 1/10W, SMD, 0603 NIC Components NRC06Z0TRF R3, R4 Corp. Note: The components listed in this Bill of Materials are representative of the PCB assembly. The released BOM used in manufacturing uses all RoHS-compliant components.  2016 Microchip Technology Inc. DS50002430A-page 27...
  • Page 28 UCS1003-2 Evaluation Board User’s Guide TABLE B-1: BILL OF MATERIALS (BOM) (CONTINUED) Qty. Designator Description Manufacturer Part Number ® R5, R6, R7, Resistor TKF, 10k, 5%, 1/10W, SMD, 0603 Panasonic - ECG ERJ-3GEYJ103V R8, R16, R9, R10 Resistor TKF, 1M, 5%, 1/10W, SMD, 0603...
  • Page 29 Bill of Materials (BOM) NOTES:  2016 Microchip Technology Inc. DS50002430A-page 29...
  • Page 30: Worldwide Sales And Service
