Manual Boost
Switches on full power to the immersion heater for the period of time selected. Note
that electricity is drawn from the grid if the excess generation is too low.
1.
Press any button on the Solar iBoost+ to switch on the backlight.
2.
Each press of the Boost button adds 15 minutes to the boost time up to
maximum of 2 hours. The amount of time remaining is shown on the display.
3.
To cancel the boost simply press the Boost button repeatedly until 'Manual
Boost OFF' is shown.
First Boost button press
Boost
Manual Boost ON
for 15 mins
Manual Boost ON
for 60 mins
Manual Boost ON
for 105 mins
The Boost function can be activated remotely within the home using
the optional iBoost+ Buddy home energy monitor.
Manual Boost ON
for 30 mins
Manual Boost ON
for 75 mins
Manual Boost ON
for 120 mins
17
Manual Boost ON
for 45 mins
Manual Boost ON
for 90 mins
Manual Boost
OFF
Final press
