Display Cycle
The display cycle allows the user to view the recorded energy saving. Each press of the
Display button will move through the following sequence
Saved Today
03.66 kWh
Saved Yesterday
10.56 kWh
Saved Last 7
days 03.66 kWh
Saved Last 28
days 65.53 kWh
Saved Amount
390.20 kWh
Time
10:15 01/07/15
In Winter Boost
Toggle Press A
Final press
Switching the timed programme function between Winter/Summer/OFF can be
activated remotely within the home using the optional iBoost+ Buddy home
energy monitor.
Present days energy diverted into the immersion heater
Previous days energy diverted into the immersion heater
Total energy diverted into the immersion heater in the
past 7 days
Total energy diverted into the immersion heater in the
past 28 days
Total value of energy diverted into the immersion heater
since Solar iBoost+ was installed
Current time and date in 24hr format
A
Press
In Summer Boost
Toggle Press A
Timed Boosts Off
Toggle Press A
:
Boost Season selection.
Hot water boosts can be
programmed for different seasons
(see programming section).
The boost season can be changed
here by pressing the A button when
required.
Each press of the A button will
change the setting between Summer,
Winter and Boost OFF selections.
14
