User Operation
Flashes when
energy is being
diverted to the
immersion heater.
Symbol is permanently
lit when any boost
function is on
Indicates a
problem with
the unit when lit (see
Trouble Shooting)
Display
Each press
moves through
the Display Cycle
(see Display
Cycle)
Normal Operation
During normal operation the unit will show one of the following displays:
Heating by Solar
01.45 kW
Water Tank
HOT
Water Heating
OFF
These messages will be overridden when other functions such as timed or manual boost
are active.
A
Enables
programming
mode (see
Programming)
Solar iBoost+ is diverting energy to the hot water tank.
The instant value of energy being diverted is shown
together with an indication of the immersion heater
Htr1
currently being supplied (if two heaters are connected
will switch between Heater 1 and 2).
When energy is diverted the blue symbol flashes:
Shown when the unit is attempting to divert energy to
the immersion heater but tank has reached maximum
temperature and switched off.
There is no excess generation for the Solar iBoost+ to
divert to the hot water tank.
B
Enables the
sender pairing
process (see
Pairing the
Sender)
13
Boost
Provides a Boost
of Hot Water (see
Manual Boost)
