ITech IT7300 Series User Manual page 30

CONFIG
Volt-Min
Volt-Max
Freq-Min
Freq-Max
Irms-Protect
BNC-Set
Config
Ipeak-Prote
ct
Dimmer
List-Set
3ø-Setup
User Manual
RS232(Def)
GPIB
USB
LAN
Config menu
Voltage lower limit
Volt-Min=0.0V
Voltage upper limit
Volt-Max=300.0V
Frequency lower limit
Freq-Min=45.0Hz
Frequency upper limit
Freq-Max=500.0Hz
Current RMS protect point
Irms-Protect=12.000A
BNC PORT SETUP
I-Trigger
I-Ri
O-Sync
O-On
Current peak protect point
Ipeak-Protect=12.000A
DIMMER
LeadingEdge
TrailingEdge
Off
LIST START MODE
On/off
Trigger
A-Phase/ B-Phase
C-Phase
RS232
Address
4800,8,N,1
9600,8,N,1
19200,8,N,1
38400,8,N,1
57600,8,N,1
Select USB interface
LAN
Gateway=192.168.0.1
IP=192.168.0.125
Mask=255.255.255.0
Socket Port=30000
Set Min. voltage
Set Max, voltage
Set frequency upper limit
Set current RMS protect point
Delay
Immediate
Input interface for external trigger
Input interface for on/off control
Output interface for AC phase synchronization
signal
Output interface for on/off state interface
Set Current peak protect point
Phase dimmer
LeadingEdge Phase dimmer function
TrailingEdge Phase dimmer function
Disable Phase dimmer function
LIST mode is used to simulate the power line
disturbance.
Enable List function
Press Shift+Enter(Trigger)to give a trigger signal
Configure phase line of each unit.(IT7321 do
/
not support this function.)
30
IT7300User Manual
Select RS232
interface
Available range from
0-31
Set Baud rate,data
bit,odd-even
check,stop bit and
address
Select LAN interface
Set gateway, IP
address, mask
address and port.
Irms protection will be
triggered in 1s
Protection will be
triggered immediately.
