Product Speci cations

See product speci cation sheets for complete speci cation
listings.
Control 12C-VA
Components: 76 mm (3 in) full-range driver
1
Frequency Range : 68 Hz - 17 kHz
Power Capacity (low-Z): 40 W Cont. Program
20 W Cont. Pink Noise
2
Sensitivity : 84 dB
3
Coverage : 130˚
Max. SPL: 97 dB @ 1m ave., 103 dB peak
Nominal Impedance: 8 ohms (in direct/bypass 8 setting)
Transformer Taps: 15W, 7.5W, 3.8W @ 70V & 100V;
plus 1.9W @ 70V
Control 14C-VA
Components: 100 mm (4 in) LF driver
19 mm (3/4 in) HF driver
1
Frequency Range : 74 Hz - 20 kHz
Power Capacity (low-Z): 60 W Cont. Program
30 W Cont. Pink Noise
2
Sensitivity : 87 dB
3
Coverage : 120˚
Max. SPL: 102 dB @ 1m ave., 108 dB peak
Nominal Impedance: 8 ohms (in direct/bypass 8 setting)
Transformer Taps: 25W, 12.5W, 6.3W @ 70V & 100V;
plus 3.2W @ 70V
Control 16C-VA
Components: 165 mm (6.5 in) LF driver;
19 mm (3/4 in) HF driver
1
Frequency Range : 62 Hz - 20 kHz
Power Capacity (low-Z): 100 W Cont. Program
50 W Cont. Pink Noise
2
Sensitivity : 91 dB
3
Coverage : 110˚
Max. SPL: 108 dB @ 1m ave., 116 dB peak
Nominal Impedance: 8 ohms (in direct/bypass 8 setting)
Transformer Taps: 30W, 15W, 7.5W @ 70V & 100V;
plus 3.8W @ 70V
1
Half-space (flush mounted in ceiling)
2
Continuous Pink Noise Rating is IEC-shaped pink noise with a 6 dB crest
factor for 100 hours continuously. Continuous Program Power is a
conservative expression of the system's ability tohandle normal speech and
music program material, and is defined as 3 dB above the Continuous Pink
Noise Rating.
3
Half-space (in ceiling) average 1 kHz to 16 kHz.
JBL Professional
8500 Balboa Blvd, P.O. Box 2200
Northridge, CA 91329 U.S.A.
Contribution of Each One-
Frequency Band when Speaker is Driven
at Full Volume, measured at 4 meter dis-
tance (req' d in this manual by EN54-24)
Control 12C-VA
Freq (Hz) Value
1000
1250
1600
2000
2500
3150
4000
Control 14C-VA
Freq (Hz) Value
1000
1250
1600
2000
2500
3150
4000
Control 16C-VA
Freq (Hz) Value
1000
1250
1600
2000
2500
3150
4000
9
ird Octave
500 57.4
630 57.2
800 57.4
57.8
57.4
59.9
58.9
54.7
57.3
59.2
500 58.8
630 58.0
800 58.4
58.1
57.7
59.1
59.0
58.6
60.8
62.8
500 62.5
630 62.3
800 63.7
65.6
62.2
62.9
63.8
64.4
63.7
65.4
