Table Of Contents; Product Description; Product Feature Identi Cation - JBL Control 12C-VA Owner's Manual & Installation Manual

Table of Contents

Product Description .................................................... 2
Product Feature Identi cation ................................... 2
Installation Preparations ............................................. 3
Step-By-Step Installation and Wiring ....................... 3
Painting the Speaker .................................................... 7
Safety Agency Compliance ......................................... 8
Maintenance ................................................................. 8
Replacement Parts ....................................................... 8
Contacting JBL ............................................................. 8
Product Speci cations ................................................. 9
ank you for purchasing JBL Control Contractor ceiling
loudspeakers. Read through this manual to familiarize
yourself with the features, applications and precautions
before you use these products.
Product Descriptions
e JBL Control Contractor Control 10C-VA Series
of EN54-24 certi ed ceiling loudspeakers utilize
innovative design and materials to provide premium level
performance from compact in-ceiling speakers.
CONTROL 12C-VA - A 3" (75 mm) full-range driver to
provide high- delity full-range sound over an extremely
wide coverage area.
CONTROL 14C-VA - A wide bandwidth ceiling speaker
containing a co-axially mounted 4" (100 mm) woofer and
¾" (19 mm) so -dome tweeter.
CONTROL 16C-VA - A wide bandwidth, high sensitivity,
extended bass ceiling speaker containing a co-axially
mounted 6.5" (165 mm) woofer and ¾" (19 mm) so -
dome tweeter.

Product Feature Identi cation

Loudspeaker
Driver
Gland Nut
Seismic Tab
(secondary
support point)
Perforated
Press-In Grille
2
(Control 14C-VA Shown)
Zinc-Plated
Steel Backcan
Tap Selector for
direct and OFF
Attachment
Screws
Terminal Cover
Plate
(Ceramic
Terminal Block
Inside)
Rotating
Mounting Tabs
(dog-ears)
