Summary of Contents for Cannondale Jekyll 27.5

  • Page 1 1 3 0 7 2 9...

  • Page 2: About This Supplement

    If you need a manual or supplement, or have a MAIntenAnCe ..........24 question about your bike, please contact your Cannondale Dealer immediately, or call us at one of the telephone numbers listed on the inside cover of this supplement.

  • Page 3: Safety Information

    Your bike (frame and components) is made from composite materials also known as “carbon Inspect frame carefully for damage (See PART II, fiber.” Section D. Inspect For Safety in your Cannondale Bicycle Owner’s Manual. ) All riders must understand a fundamental reality of composites. Composite materials constructed...

  • Page 4: Specifications

    10 Nm (88.5 InLbs) The service tool KP169/ (shown below) is available to properly service the various links, bearings, and pivot axles. The tool is available through your Cannondale Dealer. The kit is supplied with instructions and an FD ADAPTER overview of its use is shown in this supplement.
  • Page 5 Both frame types feature integrated Si bearing cups. In alloy frames, the cups are machined within the head tube. In carbon models, cups are bonded within the head tube. Cannondale Headshok System Integration bearings are accepted directly into both type. For 1.5” and 1 1/8” adapter headsets, see Replacement Parts.
  • Page 6 130729.PDF Main Pivot Dropout KP169/ tool usage BEARINGS SEATSTAYS PRELOAD BEARINGS PIVOT AXLE SHIM SCREW (large end) (small end) FD ADAPTER Loctite 242 (blue) 4 Nm (35 InLbs) pivot axle removal tool PIVOT SPACERS M5X20 included in KP169/ Loctite 242 (blue) 5 Nm, (44 inLbs) PIVOT AXLE DROPOUT...
  • Page 7 130729.PDF Shock Link Identification Shock Link Seatstay Axle DT Link Axle Main Shim Link Tool (inc. KP169/) M6X30 Bearing Bearing removal (61802-2RS, 15X24X5) Seat Stay M5X16 Pinch bolts Shock Mounting Bolt 10. Rear Brake Line bearing inner race large end small end M6X30 Bearing installation...

  • Page 8: Cable Routing

    130729.PDF Cable Routing KP312/ KP331/ KP329/ (carbon) KP183/ (alloy) KP290/ 3 mm Loctite 242 (blue) Check for sufficient housing cable loop. Its about 35mm as shown above. Inadequate loop can result in ghost shifting or housing ends 3 Nm (26.5.5 InLbs) pulling out of down tube when the bike is at full travel.

  • Page 9: Bottom Bracket

    Doing so can result in serious damage and possibly a 73mm ruined bike frame. ADAPTERS - Use only adapters/tool recommended by Cannondale. Other available adapters /tools may cause damage. See Replacement Parts. An adapter isn’t a “repair” part, so the BB shell must be in KT011/ KF366/ good condition.

  • Page 10: Rear Shock

    You can compensate by adding the loss to the table values. Use onLY HIgH-pRessURe AIR pUMp – CAnnondALe – 1Mp01/sLV to set oR ReAd pRessURe. Use of an incompatible pump (one not designed for the high pressure range of the shock) , can result serious personal injury or result in an improper pressure setting...

  • Page 11: Setting Rebound

    130729.PDF SETTING REBOuND SETTING TRAvEL Rebound controls the rate at which your rear wheel returns after it has been compressed. The proper rebound The DYAD RT2 has two travel modes, activated by the remote handlebar-mounted lever. Switching between setting is of personal preference, and varies with rider weight, riding style and conditions. A basic rule of the modes changes the bike’s sag and BB height, offering a higher BB and steeper angles for climbing, or thumb is to set rebound to be as quick as possible, without kicking back and pushing you off the saddle.
  • Page 12 130729.PDF REMOTE CABLE INSTALLATION 8. Install the DYAD RT2 back into the bicycle frame. Clean the mounting bolt threads, apply Loctite 242 Attach remote cable with shock unmounted from frame. (blue) and tighten to 8.0 Nm, 71 InLbs. 1. Place bike in a work stand with the rear wheel 9.

  • Page 13: Replacement Parts

    Frame serial number location (7-character barcode label) Use this serial number for KP330/ KP330/ 5 Nm (44 InLbs) 5 Nm (44 InLbs) 1MP01/SLV 1MP01/SLV warranty registration and theft recovery. See your Cannondale Bicycle Owner’s Manual for more information on warranty registration. Code desCRIptIon ALLoY Code desCRIptIon...

  • Page 14: Maintenance

    The following table lists only supplemental maintenance items. Please consult your Cannondale Bicycle Owner’s Manual for more information on basic bike maintenance. Consult with your Cannondale Dealer to create a complete maintenance program for your riding style, components, and conditions of use. Follow the maintenance recommendations given by the component manufacturers for the various non-Cannondale parts of your bike.
  • Page 15 n e r ’s m a n u a a le b ic y c le o w o u r c a n n o n d r e f e r e n c e . le m e n t a n d y t h f o r f u t u r e a d t h is s u p p t io n .
