- Page 1 OWNER’S MANUAL SUPPLEMENT WARNING 2012 RZ ONE TWENTY, LEXI READ THIS SUPPLEMENT AND YOUR CANNONDALE BICYCLE OWNER’S MANUAL. Both contain important safety information. Keep both for future reference. 126694.PDF (10/10)
- Page 2 In this supplement, particularly important information is presented in the following ways: Indicates a hazardous situation which, if not WARNING avoided, could result in death or serious injury. Indicates special precautions that must be taken to NOTICE avoid damage. A TIP provides helpful information. This manual meets EN standards 14764, 14766, and 14781.
-
Page 3: Safety Information
MINIMUM INSERT line marked on the seat post. Industry usage Conditions 1 - 5 are generalized and evolving. Consult your Cannondale Dealer about how you intend to use your Since your carbon seat post can also be damaged by clamping bike. -
Page 4: Maximum Fork Length
CPSC recommends. The measurement MUST be taken from the bottom of the head ASK YOUR CANNONDALE DEALER FOR THE RIGHT TIRES tube!! FOR YOUR BIKE AND ITS PARTICULAR COMPONENTS! - Page 5 126694.PDF The X-Large size code “XL” can be found etched into the bottom MINIMUM SEAT POST INSERT DEPTH bracket shell in the area shown below. The seat post of X-Large size RZ One Twenty frames must be inserted a minimum of 110 mm . 110 mm WARNING MAKE SURE AT LEAST 110 mm OF THE SEAT POST IS...
-
Page 6: Bottom Bracket
BOTTOM BRACKET The bottom bracket shell is compatible with the BB30 Standard. See http://www.bb30standard.com/ . The SI bottom bracket adapter enables the use of standard English/68mm bottom bracket cranksets. See page 6. Groove CIRCLIPS BEARINGS QC616/ KB6180/ BEARING MAINTENANCE Inspect bearing condition annually (at a minimum) and anytime the crankset assembly is disassembled or serviced. With the crankset removed, rotate the inner bearing race of both bearings;... -
Page 7: Bearing Installation
Install the other circlip the same way. KT010/ 4. With a headset press, and Cannondale tool KT010/ install BEARING INSTALLATION TOOL the bearings into the shell as shown. Press the bearing until it is seated against the circlip. - Page 8 68mm ADAPTER INSTALLATION The following procedure should only be completed by a professional bike mechanic. The adapter IS NOT a repair part and will only work in undamaged frames in good condition. 1. Remove the BB30 bearings and circlips from the bottom bracket shell. 2.
- Page 9 Make sure the Reciever part of the tool is centered on the drive side bottom bracket shell while pressing. We strongly recommend that your have this procedure performed by an Authorized Cannondale Dealer. Damage caused by improper removal is not covered under your warranty.
-
Page 10: Geometry /Specification
Bottom Bracket Height (cm/in) 33.0/13.0 * 33.0/13.0 Fork Rake (cm/in) 4.5/1.8 4.5/1.8 Trail (cm/in) 7.8/3.1 8.2/3.2 7.8/3.1 7.8/3.1 Please note that the specifications and information in this manual are subject to change for product improvement. For the latest product information, go to http://www.cannondale.com/tech_center/... -
Page 11: Specification
126694.PDF SPECIFICATION Rear Travel (cm/in) 12.0/4.7 Intended Use Condition 4, All-Mountain Maximum Weight Limit (Lbs/Kg) RIDER - 300/136 LUGGAGE - 5/2.3 (Seat bag only) TOTAL- 305/138 Maximum Tire Width 26 X 2.35 in Maximum Fork Length 520 mm Minimum Seat Post Insert Size XL 110 mm Frame Material Alloy... -
Page 12: Shock Link / Seat Stay Bearings
SHOCK LINK / SEAT STAY BEARINGS BEARING SHOCK LINK (RZ ONE20 shown) SEATSTAY KP073/ - BEARINGS, QTY 6 KP074/ - LOCTITE 638, 10 ML Bottle BEARING SHIELDS MAINTENANCE REMOVAL Bearings are a sealed cartridge type and do not require The bearings are a slip fit within the bearing bore of both periodic lubrication. -
Page 13: Installation
126694.PDF INSTALLATION The following procedure should only be completed by a professional bike mechanic. For Loctite instructions : http://tds.loctite.com/tds5/docs/638- EN.PDF 1. Remove old Loctite from the bearing bore and wipe the bearing bore clean with alcohol. 2. Use a swab to apply a generous film of Loctite™ 638 to the entire surface of the bearing bore. -
Page 14: Rear Shock
REAR SHOCK SHOCK LINK PIVOT SHOCK LINK PIVOT AXLE BOLT REAR SHOCK SHOCK BOLT O-RING 12 Nm, 106 In Lbs Loctite™ 242 (blue) WIPER SEAL SAG (mm) SHOCK BOLT 12 Nm, 106 In Lbs Loctite™ 242 (blue) 22.2 ± 0.05 mm FRONT SHOCK BUSHING WIDTH REAR SHOCK BUSHING WIDTH 22.2 ±... - Page 15 126694.PDF ORIENTATION ALL PETITE AND SMALL FRAMES SIZES - MOUNT THE SHOCK WITH THE ADJUSTMENT FEATURES OF THE SHOCK FACING REARWARD AND UP (TOP RIGHT). All Medium, Large, and X-Large frame sizes - mount the shock with the adjustment features facing forward and down (bottom right).
-
Page 16: Replacement Parts
REPLACEMENT PARTS The following replacement part kits are available through a Cannondale Dealer: NOTICE Do not machine, cut, or use surfacing tools in the head tube. 12 mm 68 mm FRAME NO. (QTY) DESCRIPTION NO. (QTY) DESCRIPTION KP170/BLK KIT,SEATBINDER,MTN QR,34.9,BLK... - Page 17 126694.PDF SHOCK LINK PIVOT A’ SHOCK MOUNTING BOLTS B’ 30 mm 30 mm PIVOT AXLE PIVOT AXLE SWINGARM PIVOT BEARING SHIELD AXLE NUT (smooth side face in) SWINGARM PIVOT AXLE Secure with 3 mm zip tie. SWINGARM / SEAT STAY / SHOCK LINK NO.
-
Page 18: Maintenance
ANY PART OF A POORLY MAINTAINED BIKE CAN BREAK OR MALFUNCTION LEADING TO AN ACCIDENT WHERE YOU CAN BE KILLED, SEVERELY INJURED OR PARALYZED. Please ask your Cannondale Dealer to help you develop a complete maintenance program, a program which includes a list of the parts on your bike for YOU to check regularly. Frequent checks... - Page 20 CANNONDALE USA CANNONDALE EUROPE CANNONDALE UK Cycling Sports Group, Inc. Cycling Sports Group Europe, B.V. Cycling Sports Group 172 Friendship Road, mail: Postbus 5100 Vantage Way, The Fulcrum, Bedford, Pennsylvania, 15522-6600, USA visits: Hanzepoort 27 Poole, Dorset, BH12 4NU (Voice): 1-800-BIKE-USA...
