Step #3 – Press the learn button
Learn
on the Receiver Latch until the
Button
yellow LED lights to insure that
the Latch is in the open position
Step #4 – Remove release paper
from the back of the strike plate
Release Paper
Step #5 – Close door firmly and open it
again. The strike plate will become
affixed to the door in the proper
mounting position. Remove and discard
red installation tool
Step #7 – Check the fit after any bumpers are installed. Door should
latch into the Receiver Latch and still have a little free play. Adjust
Receiver Latch forward on oval holes as required.
Finish by installing the remaining
screws at the front of the Receiver Latch
StealthLock
Step #6 - Screw the strike plate in
place using 2 of the #6 x ½" screws
supplied. If attaching to material
less than ¾" thick, alternate
fasteners may be required.
®
, Keyless Invisible Security 7
Installation Instructions – Transmitter Pad
The Transmitter Pad has a functional range of 15 feet from the Receiver Latch and can be
mounted virtually anywhere on any non-metallic panel. To mount, simply remove the
release paper from the tape on the back side of the Transmitter Pad, and press into place.
Suggested mounting areas
•
Cabinet door face or drawer face
•
Wall above switch plate
•
Inside unlocked cabinet door or drawer to be hidden
Remove release
paper from tape
StealthLock
®
, Keyless Invisible Security 8
Hide quick links:
Advertisement
Table of Contents
Need help?
Do you have a question about the StealthLock SL-100 and is the answer not in the manual?
Questions and answers
Receiver batteries are dead. Is there a way to access the receiver manually?
To manually access the COMPX StealthLock SL-100 receiver if the batteries are dead, insert a small flat-blade screwdriver into the battery tray slot and press in and down to release the battery tray. Replace the batteries to restore power and resume operation.
This answer is automatically generated
After pressing the learn button the latch is supposed to unlock and then start flashing once, then twice and finally three flashes. The two latches I’m working on now will go straight to 3 flashes without unlocking the latch first.
If the COMPX StealthLock SL-100 goes straight to three flashes without unlocking after pressing the learn button, it indicates that the Learn Disable mode has been set.
This answer is automatically generated
My keypad no longer works do I pair my current lock to my new keypad?
To pair a new keypad with the COMPX SL-100 lock:
1. Enter the current supervisor code on the Transmitter Pad and press the Unlock button.
2. Wait for the green light to turn off.
3. Enter the new supervisor code and press the Lock button.
4. Wait for the green light to turn off again.
5. Re-enter the new supervisor code and press the Lock button to confirm.
6. If successful, the green LED on the Receiver Latch will stay on for 3 seconds.
7. After the green LED turns off, the Receiver Latch exits learn mode, completing the pairing.
