SL-100 StealthLock
Contents
1 – RL-100
Receiver Latch
Screws Included
2.670
ACR0SS
REAR TABS
.437
3.375
1 – TP-100
.315
Transmitter Pad
CR2032 Battery Included
StealthLock
6.785
2.500
.350
1 – SP-600
Cabinet Strike Plate
Screws Included
1.250
1.500
1 – TL-600
Installation Tool
®
, Keyless Invisible Security 3
Battery Installation – Receiver Latch
The Receiver Latch uses 4 AAA batteries that
are expected to last 2 years in normal operation
(4 open/close cycles per day).
Batteries should be replaced on an annual basis
to insure continued reliability.
The LED will begin to blink after 5,500 operations
to warn that batteries need to be replaced
While gripping the rear
tabs, slide the battery
housing in and up as
shown
Slide the battery
housing back until it is
completely free of the
Receiver Latch
Install four AAA batteries in
the slots indicated on the back
of the battery housing.
StealthLock
®
, Keyless Invisible Security 4
Hide quick links:
Advertisement
Table of Contents
Need help?
Do you have a question about the StealthLock SL-100 and is the answer not in the manual?
Questions and answers
Receiver batteries are dead. Is there a way to access the receiver manually?
To manually access the COMPX StealthLock SL-100 receiver if the batteries are dead, insert a small flat-blade screwdriver into the battery tray slot and press in and down to release the battery tray. Replace the batteries to restore power and resume operation.
This answer is automatically generated
After pressing the learn button the latch is supposed to unlock and then start flashing once, then twice and finally three flashes. The two latches I’m working on now will go straight to 3 flashes without unlocking the latch first.
If the COMPX StealthLock SL-100 goes straight to three flashes without unlocking after pressing the learn button, it indicates that the Learn Disable mode has been set.
This answer is automatically generated
My keypad no longer works do I pair my current lock to my new keypad?
