- Page 1 880M Evolution Series Reference Mono Power Amplifier Owner’s Manual...
- Page 2 880M Evolution Series...
-
Page 3: Important Safety Instructions
Owner’s Manual Important Safety Instructions Read these instructions. receptacles, and the point where they exit from the apparatus. Unplug mains cord during Keep these instructions. transportation. Heed all warnings. 11. Only use attachments and accessories specified by Follow all instructions. the manufacturer. - Page 4 MOON 880M, immediately disconnect it from component. To completely disconnect this the AC mains and take it to your MOON dealer apparatus from the AC mains, disconnect the for a complete check-up. power supply cord plug from the AC receptacle.
-
Page 5: Table Of Contents
Owner’s Manual Table of Contents Introduction Unpacking Installation & Placement Rear Panel Connections Connecting the 880M Balanced Operation Operating the 880M Troubleshooting Remote Operation Specifications www.simaudio.com Simaudio Ltd., 1345 Newton Road Boucherville, Québec J4B 5H2 CANADA Date Code: 20150805... -
Page 6: Introduction
880M Evolution Series Introduction Thank you for selecting the MOON 880M Mono power Proprietary “Lynx” Technology which eliminates feedback. amplifier as a part of your hi-fi reproduction system. This The results are: Real-time amplification is achieved since power amplifier has been designed to offer state-of-the- interactions from the speaker back to the amplifier are virtually eliminated;... -
Page 7: Unpacking
The customized packaging is specially designed to protect the 880M from any potential damage during transit. Please write the serial number of your new MOON 880M in the space provided below for future reference. Serial Number Installation & Placement... -
Page 8: Rear Panel Connections
Series Rear Panel Connections Figure 1: Rear panel of MOON 880M The rear panel will look similar to Figure 1 (above). There is one balanced (differential) input on an XLR connector and one unbalanced (single-ended) input on a RCA connector. There is no switch to toggle from balanced mode to single-ended mode. -
Page 9: Connecting The 880M
Connect the input cables running from your MOON 880M directly into a dedicated AC outlet preamplifier’s outputs, whether balanced or single- and avoid using an extension cord. If you have the ended, to the amplifier’... -
Page 10: Operating The 880M
DC protection .......... LED blinks 2 times performance after powering it up again. Thermal Protection ........ LED blinks 3 times Turning on your MOON 880M for the first time Your MOON 880M is a “smart” power amplifier equipped with a self-diagnostic system that will... -
Page 11: Remote Operation
Owner’s Manual Remote Operation Figure 3: Remote Operation with 12V Trigger In figure 3 we have a 850P Preamplifier and a pair of 880M amplifiers connected together via their respective 12V triggers; The 12V trigger output on the 850P is connected to the 12V trigger input on the top 880M (using a 1/8” mini-jack cable). -
Page 12: Specifications
Class Of Operation A/AB Input Impedance 47,500Ω Input Sensitivity 2250mV Output Device Type MOON Bipolars – 32 800 Watts per channel Output Power at 8Ω Output Power at 4Ω 1600 Watts per channel Frequency Response 10Hz - 200kHz +0/-3dB Gain...
