IMPORTANT SPECIFICATIONS
Max. Pressure: 7.0 bar (98 PSI)
*Noise Level (LAeqT) WA101_78.7 dB (A) / WA101 R_62.8 dB (A)
WA200_81.2 dB (A) / WA200 WB_76.8 dB (A)
LPA200_76.9 dB (A)
*Measuring point: 1m backwards from gun, 1,6 m height

TECHNICAL SPECIFICATIONS

Model Nozzle Air cap Air pressure Air pressure
orifice set at gun inlet inside air cap output
mm (in)
High T.E.C. WA-101/101R Pressure feed
WA-101-082P 0.8 (0.031)
E2P
WA-101-102P 1.0 (0.039)
WA-101-132P 1.3 (0.051) H2
WA-101R-05P 0.5 (0.020) *Round
High T.E.C. WA-200 Pressure feed
WA-200-062 0.6 (0.024)
WA-200-084 0.8 (0.031)
LV2
WA-200-104 1.0 (0.039)
WA-200-124 1.2 (0.047)
WA-200-154 1.5 (0.059)
WA-200-082P 0.8 (0.031)
G2P
WA-200-102P 1.0 (0.039)
WA-200-122P ** 1.2 (0.047)
WA-200-152P 1.5 (0.059) K2
WA-200-202P 2.0 (0.079) R2
WA-200-251P 2.5 (0.098) W1
WA-200-066P FT 0.6 (0.024)
WA-200-086P FT 0.8 (0.031)
FT6
WA-200-106P FT 1.0 (0.039)
WA-200-126P FT 1.2 (0.047)
High T.E.C. WA-200 WB Pressure feed
WA-200WB-081P 0.8 (0.031)
WA-200WB-101P 1.0 (0.039)
WB1
WA-200WB-121P 1.2 (0.047)
WA-200WB-141P 1.4 (0.055)
WA-200WB-161P 1.6 (0.063)
High T.E.C. LPA-200 Pressure feed
LPA-200-122P 1.2 (0.047) G2
*The WA 101R air cap set is the purely round spray pattern with material flow control.
**0.8mm (0.031"), 1.0mm (0.039") nozzles are available.

SAFETY WARNINGS

FIRE OR EXPLOSION HAZARD
1. Sparks and open flames are strictly prohibited.
Paints can be highly flammable and can cause fire.
Avoid any ignition sources such as smoking, open flames, electrical goods, etc.
2. Never use the following HALGOGENATED HYDROCARBON SOLVENTS
which can cause cracks or dissolution on gun body (aluminium) by chemical reaction.
- Unsuitable solvents methyl chloride, dichloromethane, 1.2-dichloroethane,carbon
tetrachloride, trichloroethylene, 1.1.1-trichloroethane.
- Be sure that all fluids and solvents are compatible with gun parts.
We can supply a list of materials used to manufacture the product.
3. Securely ground spray gun. Use air hose with built-in ground wire or use grounded gun stay.
Ground resistence : Less than 1MΩ. Check the earth stability periodically.
If not, insufficient grounding can cause fire and explosion due to static electric sparking.
2
Max. Temperature:
Atmosphere 5 ~ 40 °C
Air and fluid 5 ~ 43 °C
Air connection: G 1/4"
Fluid connection: G 1/4" (WA 101/101R/WA200 WB)
Fluid connection: G 3/8" (WA200/LPA200)
Fluid Air
consumption
bar (PSI) bar (PSI) ml/min l/min (cfm)
- 150
270 (9.5)
- 200
3.0 (43)
- 250 260 (9.2)
- 20 40 (1.4)
-
-
2.0 (29) 255
- 270 (9.5)
-
-
-
500
- 530 (18.7)
-
3.0 (43)
- 270 330 (11.7)
- 400 360 (12.7)
- 500 360 (12.7)
0.14 - 80 170 (6.0)
0.16 - 100 185 (6.5)
0.18 - 120 200 (7.1)
0.20 - 140 220 (7.8)
- 200
- 250
1.6 (31) 340 (12.1)
-
300
-
-
2.0 (29) 0.7 (10) 500 500 (17.7)

SPARE PARTS LIST

Pattern Weight
width
mm (in) g
190 (7.5)
460
220 (8.7)
230 (9.1)
35 (1.4) 440
280 (11.0)
500
400 (15.7)
340 (13.4)
320 (12.6)
330 (13.0)
140 (5.5)
150 (5.9)
550
160 (6.3)
180 (7.0)
360 (14.2)
PARTS LIST
470
380 (14.9)
Ref.part Description
340 (13.4)
1 Air cap set
1R Air cap set (round)
2 Fluid nozzle + needle set
300 (11.8) 500
3 Body set
3-1 Air nipple
3-2 Fluid nipple
4 Pattern adjustment
4R Plug screw
5 Air valve seat
5-1 O ring
5-2 O ring
5-3 O ring
6-1 Piston packing
6-2 Piston
7 Needle spring
8 Piston spring
9 Fluid adj. set
9-1 Stop ring
9-2 Ball
9-3 Fluid adj. spring
10 Bolt set
11 Fluid needle packing set
12 Cover
13 Brush
14 Instruction manual
15 Half union for ø 6
16 Half union for ø 8
WA 101 WA 101R WA 200/WA 200WB LPA 200
MODEL
1 - 1 1
WA 101
- 1 - -
WA 101
1 1 1 1
1 1 1
WA 101R
2
1 1 1
WA 200
1 - 1 1
WA 200
- 1 - -
WA 200
1
WA 200
1
WA 200
1
WA 200
1
1
WA 200WB
1
WA 200WB
1
WA 200WB
1
WA 200WB
1
WA 200WB
1
1 LPA 200
1
2
1 Marked parts are wearable parts.
1
When ordering parts, specify gun's model,
1
part name with ref.No.and marked No. of
1 air cap set, fluid nozzle and fluid needle
1
set. When replacing fluid nozzle and/or fluid
1 needle please order fluid nozzle-needle set.
FLUID NOZZLE Fluid needle
Orifice Mark set
0.8 (0.031) W101/08 WA12
1.0 (0.039) W101/10 WA12
0.5 (0.020) W101/05 WA05
0.8 (0.031) W200/08 WA12
1.0 (0.039) W200/10 WA12
1.2 (0.047) W200/12 WA12
1.5 (0.059) W200/15 WA15
2.0 (0.079) W200/20 WA20
2.5 (0.098) W200/25 WA25
0.8 (0.031) 200WB/08 WA12
1.0 (0.039) 200WB/10 WA12
1.2 (0.047) 200WB/12 WA12
1.4 (0.055) 200WBS1/14 WA15
1.6 (0.063) 200WB/16 WA15
1.8 (0.071) L200/12 WA12
