INSTALLATION AND OPERATION MANUAL
for
VKC-12120F2810IR

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VKC-12120F2810IR and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Eneo VKC-12120F2810IR

  • Page 1 INSTALLATION AND OPERATION MANUAL VKC-12120F2810IR...
  • Page 2: Table Of Contents

    Table of contents 1. Safety Instructions and Notes…....................... 2. General Descriptions................……………………………... 3. Supplied Items..................……………………………... 4. Part names…………………………….…...........…………………………... 5. Installation Instructions..................……………………... 6. Setup Menu ……………................…………………………... 7. Specifications ………………………………………………..............8. Dimensional Drawings ……………………………………………............
  • Page 3: Power Source

    WARNING To prevent fire or shock hazard, do not expose the unit to rain or moisture. The symbol is intended to alert the user to the presence of important operating and maintenance(servicing) instructions in the literature accompanying the unit. The symbol is intended to alert the user to the presence of uninsulated "dangerous voltage"...
  • Page 4: Safety Instructions And Notes

    1. Safety Instructions and Notes • Please read this safety and operating instructions before putting the camera into operation. • Keep the manual in a safe place for later reference. • Pay attention to safety when laying the connection cable and observe that the cable is not subjected to heavy loads, kinks or damage and no moisture can get in.
  • Page 5: Supplied Items

    • UTC(Coaxitron Control Pelco D) • OSD menu and camera ID • Switches to B/W and able to accept the infrared spectrum at night mode • Very low noise and superior picture quality • Sensitivity of 0.0001Lux (F1.2@40IRE, DSSx4) • True Day/night by Automatically removable IR Cut Filter(ICR) •...
  • Page 6: Part Names

    4. Part Names 4.1 Front / Rear View ⓓ ⓔ ⓐ ⓕ ⓑ ⓖ ⓒ ⓗ ⓘ ⓙ ⓛ ⓚ ⓐ Front cover ⓔ Foot mount Hole(x4) ⓘ Hook for Easy Bracket ⓑ IR LED ⓕ Arm assembly ⓙ Cable Exits ⓒ...
  • Page 7: Installation Instructions

    4.2 Easy Bracket ⓜ ⓜ Peg for Easy Bracket Hook(ⓘ) ⓝ ⓝ Wall Mount hole(x4) ⓞ Bracket foot fixing hole(x4) ⓞ CAUTION - Easy Bracket can not be installed on the ceiling. When it is installed on the wall, ⓜPeg for Easy bracket Hook must be placed upwardly. 5.
  • Page 8 5.1. Mounting the camera on wall 5.1.1 Without using an Easy Bracket. 1) Drill the holes on wall or ceiling using a supplied template. 2) Insert the ②anchors to the drilled holes 3) Match ⓔFoot mount Hole(x4) to the drilled position 4) Fix the bracket by using ③Wall fixing screws 5.1.2 With using an Easy Bracket.
  • Page 9 2. Tilt limit Tilt is limited to 0°(2°) min ~ 90° max. for wall(ceiling) installation respectively with reference to the ceiling when the inclination of camera module is 0°, that is, the image is aligned horizontally. Installation on Wall Installation on Ceiling 3.
  • Page 10: Setup Menu

    5.2. Power Supply Connections Camera can work with either 24AC or 12VDC, dual voltage power. It is strongly required the polarity-matched connection for 12VDC supply, otherwise IR LEDs will not operate at night. Primary and secondary grounds are completely isolated to avoid the possible ground-loop problems. 6.
  • Page 11 6.2 MAIN menu MAIN Default Descriptions EXPOSURE Can set SHUTTER/AGC, WDR, FLICKERLESS and HLC/BLC. Selects the lens type, DC or MANUAL. Set to DC when DC auto-iris lens is equipped. Cameras with built-in DC LENS V/F lens must be set to DC. Set to MANUAL when a fixed iris or a manual iris lens is equipped.
  • Page 12 6.3 EXPOSURE menu EXPOSURE menu provides the parameters which control the light level and enhance the dynamic range of video. EXPOSURE Default Descriptions Can set to AUTO or MANUAL. AUTO - Video level is automatically controlled to follow the settings of EXPOSURE MODE, BRIGHTNESS, GAIN-UP SEQ and SENS-UP.
  • Page 13 6.3.1 SHUT/AGC AUTO menu To enter SHUT/AGC AUTO menu, press ● at MAIN>EXPOSURE>SHUTTER/AGC>AUTO. AUTO SETUP Default Descriptions OUTDOOR Selects OUTDOOR, INDOOR-W or INDOOR. (IR LED OUTDOOR – Optimized for the outdoor application with the dynamic version) range and the sharpness. Smear may occur at bright spot light. EXPOSURE INDOOR-W –...
  • Page 14 6.3.2 SHUT/AGC>MANUAL menu MANUAL Default Descriptions SETUP MODE SHUT Selects from SHUT, WDR+SHUT and DSS. SHUT and WDR+SHUT sets the manual shutter to 1/63(1/53),1/100 1/63 SHUT (1/120), 1/250,1/500,1/1000, 1/2000,1/4000 or 1/10000 sec. (1/53) DSS sets the fixed sens-up rate to 2x ~ 256x fields. Sets AGC gain in dB.
  • Page 15 WDR(ATR-EX) Default Descriptions Selects from FULL, OFF and LIGHT. FULL – Video outputs image processed from two images by dual shutter(long shutter and short shutter) in a field to provide the best dynamic range. Highlight area is compensated by the short shutter and dark area is compensated by the long shutter.
  • Page 16 HLC/BLC Default Descriptions HLC clips out the highlight area and masks it as a single color. OFF – Disables HLC function. AUTO – HLC switches ON/OFF according to the brightness of the overall image. ON – Video will be clipped out and masked for the area which exceeds CLIP LEVEL.
  • Page 17 6.4 LENS menu To enter LENS menu, press ● button at MAIN menu>LENS. AUTO IRIS Default Descriptions Fixed to DC ONLY. TYPE This camera does NOT support video type auto iris lens. Adjusts the iris control speed. SPEED The lower value is the slower speed. If the speed is too fast or slow, the iris may fluctuate or be out of control.
  • Page 18 6.6 DAY/NIGHT menu To enter DAY/NIGHT menu, press ● button at MAIN menu>DAY/NIGHT. AUTO mode in DAY/NIGHT is used only for a camera which does not have a light sensor. DAY or NIGHT is decided by the amount of the light through the lens only.
  • Page 19 CAUTION 1) DAY/NIGHT AUTO menu is strongly recommended to be adjusted for the actual object after completing all settings of lens for zoom and focus. 2) If the gap between DN(THRES) and ND(THRES) becomes too small, it is easy to repeat switching DAY from/to NIGHT.
  • Page 20 PICT ADJUST Default Descriptions Selects the white balance mode. ANTI CR – Anti-Color-Rolling can reduce the possible color rolling under the fluorescent light when WDR is OFF or LIGHT. When WDR mode is FULL, the color rolling can be reduced by setting WDR CR COMP.
  • Page 21 Default Descriptions Sets the AWB compensating speed. Lower value makes AWB faster. SPEED CAUTION Too fast AWB may make the color oscillation. Adjusts the AWB compensation period to next update of AWB. DELAY CNT The smaller value will update AWB more frequently (faster). Determines the ATW range with respect to the standard range.
  • Page 22 D-EFFECT Default Descriptions MIRROR defines the way which the image displays. OFF – Displays the regular image. MIRROR H-FLIP – Flips the image over left and right. V-FLIP – Flips the image over upside down HV-FLIP – Flips the image over left/right as well as upside down. DIS(Digital Image Stabilization) reduces and stabilizes the shaky image from a camera installed in the vibrated area.
  • Page 23 6.9.1 MOTION DET menu Up to 4 motion detection areas are available and each area is programmable in size and location. The motion is displayed by means of blocks when MAIN menu>SPECIAL>MOTION DET and BLOCK DISP are ON. MOTION DET Default Descriptions DETECT...
  • Page 24 PRIVACY Default Descriptions AREA SEL 1/15 Selects one of AREA1~AREA15 to be adjusted. MODE ON enables the privacy area masked with the selected color. POSITION sets the area in size and location after entering the area mode by pressing ● button at MAIN menu>SPECIAL>PRIVACY>POSITION.
  • Page 25 6.9.4 CAMERA ID menu Up to 10 characters can be input for camera ID. To enter CAMERA ID menu, press ● button at MAIN >SPECIAL>CAMERA ID. Use ▲,▼,◀,▶ buttons to move a block cursor in character table and press ● button to input the selected character.
  • Page 26 6.9.6 PIXEL COMP menu Usually the image sensors have some defective pixels from the born and they can be compensated digitally by the image signal processor. This menu provides the defective pixel corrections up to 64 white pixels. This menu detects the defective pixels at dark with lens closed and saves their data for compensation.
  • Page 27: Specifications

    . Specifications VKC-12120F2810IR High Density 1/3" Sony Double Scan CCD(960H) Image Device 976(H) X 582(V) Effective Pixels TV System 50Hz(V), 15.625Khz(H) Scan Freq. Synchronization Internal H. Resolution 700TVL Sensitivity 0.0001Lux (F1.2 at 40Ire, DSSx4) S/N Ratio More than 52dB with AGC OFF at 50IRE...
  • Page 28: Dimensional Drawings

    8. Dimensional Drawings (Unit: mm)
