Wintec G-Trender II WSG-2000 User Manual

Professional gps cycle computer
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
G-Trender II
User Manual
English
Pr of e s si o n a l GP S Cycl e Co m p u te r
WSG-2000

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the G-Trender II WSG-2000 and is the answer not in the manual?

Questions and answers

Related Manuals for Wintec G-Trender II WSG-2000

Summary of Contents for Wintec G-Trender II WSG-2000

  • Page 1 G-Trender II User Manual English Pr of e s si o n a l GP S Cycl e Co m p u te r WSG-2000...

  • Page 3: Table Of Contents

    WSG-2000 Professional GPS Cycle Computer Table of Content s Product Overview Attitude Calibration Altimeter Calibration Standard Package Illustration on how to install Micro SD card Navigation Setting Install the battery on Wheel Speed, Cadence Sensors Trip Computer Setting Charge the Battery by USB cable My Training Function Description Information...
  • Page 4 S A F E T Y N O T E S • The Global Positioning System (GPS) is a U.S. space-based global navigation satellite system. It provides reliable positioning, navigation, and timing services to worldwide users on a continuous basis in all weather, day and night, anywhere on or near the Earth.

  • Page 5: Product Overview

    Pr o duc t O ve r v iew Hot Key to Add Mark Point ESC / MENU Short Press：Exit Long Press：Return to the Main Page Hot Key for fast switch to favorite pages Central Button：Select the up, down, left and right function icons.

  • Page 6: Standard Package

    St an dar d Pa c ka ge • 1 x WSG-2000 Professional GPS Cycle Computer (built-in Micro-SD card interface ) • 1 x Micro-SD card • 1 x Rechargeable Li-ion battery • 1 x Mini USB cable • 1 x User Manual •...

  • Page 7: Illustration On How To Install Micro Sd Card

    I llus tration on how to in s t all th e Mic r o SD c ar d...

  • Page 8: Install The Battery On Wheel Speed, Cadence Sensors

    Install the battery on Wheel Speed, Charge the Battery by USB cable Cadence Sensors Remove the battery cover on the back sensor using a coin, or the • Place the battery into the battery slot on WSG-2000. equivalent tool. • Connect USB Cable to USB port on PC or the AC Adapter Insert new lithium batteries (CR2032) with the (+) sign upward and (Optional Accessories).

  • Page 9: Function Description

    Func tion De s c r iption GPS Information 08:11 06-Jan-36 Provide GPS-related information and settings. FIX Full GPS Information 1 Reset GPS A.GPS GPS Information 2 Coordinates Display Format GPS Information 3 Electronic compass / G-Sensor Function Electronic compass, Attitude information Attitude Compass / G-Sensor calibration...
  • Page 10 Func tion De s c r iption Barometer/UV Function Trip computer Function Provide altitude, pressure, temperature, Provide information of biking and ultraviolet radiation information and settings. related settings. Barometer/UV Trip Computer (Rotation) Altitude Chart Trip Computer 1 Altitude Trip Computer Pressure Chart Trip Computer 2 Calibration...
  • Page 11 My Training Function Setup Function Provide system and operation information Provide track, time, distance, altitude setting for training program and settings. User Info Setting My Training Setting (By Distance、 My Training Bike Info Setting Time、Altitude) Contrast、Backlight、 System Buzzer、 Zone Time、 My Favorite Track My Training Language、Unit、...

  • Page 12: Status Bar Description

    St atus Bar De s c r iption Logger Status. Enable or Disable Logger USB Status. Journey accumulated Status: This function is designed to record Key Lock. all related biking information along the ride when enabled. Wheel Speed Signal Reception Status. GPS Status Cadence Signal Reception Status.

  • Page 13: Pair The Wheel Speed, Cadence And Heart Rate Sensors

    Pair the Wheel Speed, Cadence, and Heart Rate Sensors Wheel Speed/Cadence Heart Rate Sensor Remove battery from Wheel Speed or Cadence.(Sensor Side) Remove the battery from Heart Rate Sensor. (Sensor Side) Put the battery in the sensor again and use a coin to twist the battery Go to search device page for pairing sensors.

  • Page 14: Install Mount Holders On The Bike

    Install Mount holders on the Bike Horizontal Mount Holder Horizontal Mount holder on the handle bar • Back side view Stick double-faced sticker on the concave surface of holder Slip provided straps trough their holes Tighten both straps on the handle bar Slide WSG-2000 downwards aligning with the holder’...
  • Page 15 Vertical Mount Holder Vertical Mount Holder on the Stem • Back side view Stick double-faced sticker on the concave surface of holder. Slip provided straps trough their holes Tighten both straps on the Stem S l i d e W S G -2 0 0 0 d o w n w a r d s aligning with the holder’...

  • Page 16: Accessories Installation

    Place the heart rate sensor near the area of the heart on the skin, and keep the “Wintec” logo side as the front side when wearing on the chest To avoid measurement errors, it is recommended to Attention moisten the electrode pads with water.
  • Page 17 Generally the wheel sensor is located on the rear frame near the magnet, please magnet by the “Wintec” logo note that it might be difficult to install and be connected if you install it on the front side because the different structures of types of bikes.

  • Page 18: Gps Setting

    GPS Setting WSG-2000 provide information about how to reset GPS, set coordination and display format etc. (Main Page->GPS->Press the “SET” key) GPS Restart: Hot start / Warm start / Cold start WSG-2000 with high-sensitive chipset can well receive and acquire the GPS signals generally when in normal and frequent use.

  • Page 19: Compass Calibration

    Compa ss Calibration Implement Calibration on page of “Compass Calibration” . (Main Page->Compass->Press the “SET” key). P1S WSG-2000 can auto-calibrate itselves or you can manually calibrate the Compass if it goes wrong. Normally, the accuracy of compass will be affected by magnetic things. You can try more times or move to different places and try again if manually calibration is not successful.

  • Page 20: Attitude Calibration

    At titude C alibration First, please position the mount properly on the handle bar or Stem on your bike and fix it. Slip WSG-2000 on the mount. Please locate your bike on horizontal plane (0°) . Start the attitude calibration (Main page->Compass->Press the “SET” key). Compass/G-Sensor Attitude Clibration Compass Calibration...

  • Page 21: Altimetercalibration

    Altimeter Calibration As the value of pressure and altimeter may be influenced by the environment, WSG-2000 provides three kinds of values interference to provide the most accurate information to the AltimeterCalibration users. (Main page-> Barometer / UV-> Press the “SET” key) By GPS Height GPS altitude: the value is acquiring from that of GPS.

  • Page 22: Navigation Setting

    Nav igation Se t tin g Track back Navigation Setting Mark Navigation Setting • • (Main Page->Navigation->Track Navigator->Press the “SET” key) (Main Page->Navigation->Mark Navigator->Press the “SET” key) My Favorite Track: To select your favorite track for navigation or you Mark List: Select the location Mark you can delete them from this page.

  • Page 23: Trip Computer Setting

    Trip Computer Setting (Main Page->Trip Computer-> Press the “SET” key) User can choose 22 information you need and set Full them on the pages of ‘Trip Computer’ 1~4 as well My Favorite as enable or disable the pages. Trip Computer <<...

  • Page 24: My Training

    My Trainin g My Training Setting (Distance / Time / Altitude) Track Training Setting • • (Main Page->Track Training->Press the “SET” key) (Main page->My Training->Press the “SET” key) My Favorite Track: Select your favorite track for In this function, user can set distance, time and workouts.

  • Page 25: Information

    I nfor m ation Odometer Setting History Info　 (To build up my Favorites Track.) • • (Main page->Info->Odometer->Press the “SET” key) (Main Page->Info->History Info->Last page of History Info) W S G -2 0 0 0 p r ov i d e s o d o m e t e r 3 b i ke s c a l c u l a t i o n If you want to save the track about your ride, you can separately, you can create and name on your own bikes.

  • Page 26: Setup

    Setup System User • Bike • Information: (Main Page->Setup->System->User) (Main Page->Setup->System->Bike) You can create your personal profile here; it You can set up 3 customized bikes information. For the can automatically calculate your maximum detailed size of wheel, please refer to the following table. hear t rate, hear t rate zones and calories consumptions.
  • Page 27 Wheel size Wheel size Wheel size L (mm) L (mm) L (mm) 12 x 1175 26 x 7/8 1920 27 x 1-1/4 2161 14 x 115 1020 26 x 1(59) 1913 27 x 1-3/8 2169 14 x 1175 1055 26 x 1(65) 1952 650 x 35A 2090...
  • Page 28 Setup Change the Backlight and Interval Time Zone • • (Main Page->Setup->System->Backlight) (Main Page->Setup->System-> Time Zone) Here you can set the selections on the setting of backlight About the time zone setting, the system will inter val. As the setting indicated in the figure for example, automatically convert to local time according to the backlight stays on 10 seconds after 1 minute interval in the GPS time.
  • Page 29 Hot Key Selection Power Saving Mode • • (Main Page ->Setup->System->Button Shortcuts) (Main Page ->Setup->Power Save) The hot key selec tions are designed to quickly When enable the power-saving mode, the system will switch on the function pages selected on the list. automatically turn off the screen to save the power (The middle key on the right side of WSG-2000 units) consumption if paused after 1 minute, but the unit is still...
  • Page 30 Setup • Alerts Setting Log Mode • (Main Page ->Setup->Set Alert) (Main page ->Setup->System->Log Mode) You can set the value on alerts regarding WSG-2000 provides 4 modes to Log function. over- speed setting and UV measurement a . User Mode: Set the log mode you need by WSG-Tool. and heartbeat rates if beyond the settings of b .
  • Page 31 Run WSG -Tool on PC • WSG-Tool is the software for looking up the track files, displaying it on map, making the training reports, Geo-Tagging the JPEG photos according to Logger data, or exporting /importing my favorite tracks. It can also convert the files into different formats as well as advanced settings on the system.
  • Page 32 Run WSG -Tool on PC The easily operating application software, WSG-Tool • You can set and easily perform the GPS parameters, transfer the format of tracks or geo-tag the photos by W SG_Tool stored and built-in the Micro-SD card of WSG-2000...
  • Page 33 How to Execute WSG-Tool Turn-On WSG-2000 and connected it to PC side with USB cable. The Screen of WSG-2000 will show the page as below. PC will auto run WSG-Tool while you select “open WSG-Tool” item. Note: It may take longer to wait for running WSG-Tool in the first time. Please be patient in waiting. When the WSG-Tool is running, the computer screen will appear the following window.
  • Page 34 Run WSG -Tool on PC The WSG-Tool will auto-read the last recorded track from Micro-SD card as Google Maps format and display it by browser connection.
  • Page 35 At same time, the WSG_Tool icon is hidden on the below system bar. Click WSG-Tool icon to open the WSG-Tool main page. For detailed operation on WSG-Tool, Note please refer to [Help \ WSG_Tool User Manual]...

  • Page 36: Usb Com Port Driver Installation

    USB Com Por t Dr i ve r I n s t allation Follow below steps for installing the USB Com Port driver. Connect WSG-2000 with USB cable to PC side and run “WSG-Tool” . The WSG-Tool will copy USB Com Port driver to the path of “My documents \ WSG2000”...
  • Page 37 Tick items as below picture and press “Browse” . Choose the location of “… \ My documents \ WSG2000” , and press “OK” .
  • Page 38 USB Com Por t Dr i ve r I n s t allation • When back the Found New Hardware Wizard, please press “Next” Click “Finish” to complete it. button to install USB Com Port driver. • Select “Continue Anyway” to continue install USB Com Port driver.
  • Page 39 You can check com por t number in ‘Device Manager ’ and make sure the USB driver is successfully installed (WSG-2000 device must connect with PC via USB cable). Then you can define the com port for WSG-2000 (the following picture shows the COM4) as the communications interface.
  • Page 40 Fir mwar e Up gra de Go to Firmware Upgrade function page. This is the instruction on how to update firmware forWSG-2000. (Main Page->Setup->System->Firmware Upgrade) Connect WSG-2000 to PC via USB cable. If you haven’ t install USB Com port driver before, please refer to the part of installing on USB Com Port Driver.
  • Page 41 WSG-2000 will enter update mode. User also can Execute the WSG2000_Firmware_Update_Tool. cancel it by pressing the “ESC” key on the WSG- (Step1)Select firmware file (G-TrenderII_v1.0.0.0.wfw)。 pgrade) 2000. (Step2)Select USB Com port number and then press “Connect” Button. (Step3)Press “Update Firmware” button to start upgrade firmware. When the process of update is finished, WSG-2000 will reboot it selves automatically.

  • Page 42: Specification

    Sp e c if ic ation s Standard Lithium Battery BL-5C NOKIA Model Number G-TRENDER II / WSG-2000 3D electronic compass + 3D Accelerometer Descriptions Professional GPS Cycle Computer High accurate pressure altimeter GPS Frequency L1, 1575.42 MHz High resolution 4 gray-scale LCD H240xW160 Operation Time more than 15 hours 32 Channel for acquisition Channels...
  • Page 43 Acquisition Reacquisition <1 sec. Hot start <3.5 sec Warm start 33 sec Cold start 34 sec Power Battery Source 1100mA Battery Charger DC 5V 4 Hours (Device is working) Battery Charging Time 3 Hours (Power off the device) 13 Hours (Normal mode with back-light) Operation Time 14 Hours (Normal mode w/o back-light) 17 Hours (Power saving mode w/o back-light)
  • Page 44 Track record (Logger) Max1 record points 33500000 points per 1GB Micro SD card Disable LOG • By angle change • By Speed • LOG Mode By Time interval • By Distance • Mix mode ( Distance/ Time/ Speed/ Angle) • Push-to-LOG •...
