- Page 1 FOGHET EVO water INSTALLATION, USE AND MAINTENANCE MANUAL To be kept by the purchaser FOGHET EVO Wood operated water fireplace...
- Page 2 Dear Customer, thank you for having chosen to heat and save with a Jolly Mec product. Please carefully read and keep this sheet before using the equipment. This sheet provides necessary information and suggestions on how to correctly install, use, clean and maintain the product.
-
Page 3: Table Of Contents
TABLE OF CONTENTS CHAP.01 PREMISES........................... 4 01.1 WARNINGS ..............................4 01.2 SYMBOLOGY ............................... 5 01.3 APPLIED STANDARDS ..........................5 01.4 USE AND STORING OF THE INSTALLATION AND MAINTENANCE MANUAL ........6 01.5 MANIFACTURER LIABILITY AND WARRANTY CONDITIONS ..............6 CHAP.02 ACCIDENT PREVENTION / SAFETY REGULATIONS .............. 7 02.1 GENERAL CONSIDERATIONS ........................ -
Page 4: Chap.01 Premises
CHAP.01 PREMISES 01.1 WARNINGS • Familiarity and compliance with the instructions given in this manual will ensure quick installation and correct use of the appliance. • Read the manual attentively before commencing installation, and be certain to follow the directions it contains, otherwise the war- ranty could be invalidated and the performance and safety of the appliance jeopardized. • The installation manual is an integral part of the product and must be given to the user. • It must be kept in a safe place and consulted carefully, as all of the warnings provide important information on safety during instal- lation, use and maintenance. • Incorrect installation of the appliance could cause damage and injury to people or animals, for which the manufacture cannot not be held liable. • Installation shall be performed by qualified operators in accordance with the regulations in force in the Country of installation. • The manufacturer declines any contractual or non-contractual liability for damages caused by errors in installation or use of the appliance or failure to follow the instructions contained in this manual. • All rights on the reproduction of this technical manual are owned by Jolly Mec Caminetti S.p.A. The descriptions and illustrations provided in the following publication are not binding. • reserves the right to make any modifications that may be deemed appropriate. • Jolly Mec Caminetti S.p.A This manual cannot be given to third parties for perusal without the written permission of • Jolly Mec Caminetti S.p.A • The technical directions for installation contained in this manual should be considered as basic requirements. Regulations in some countries may be more restrictive; in this instance, comply fully with the regulations prevailing in the country of installation (all laws and local bylaws must be observed when installing and using the appliance, including those referring to national and European standards). -
Page 5: Symbology
This point is particularly important. An important point regarding behaviour for preventing injury and damage to DANGER materials is expressed. 01.3 APPLIED STANDARDS All JOLLY MEC products are constructed according to the following directives: European construction products regulation. • EU 305/2011 Machines. •... -
Page 6: Use And Storing Of The Installation And Maintenance Manual
01.5 MANIFACTURER LIABILITY AND WARRANTY CONDITIONS Upon the delivery of this manual, Jolly Mec S.p.A. cannot be held liable, whether civil or criminal, for accidents due to partial or total non-compliance with the specifications herein contained. The manufacturer is especially held harmless from any liability in the following cases: •... -
Page 7: Chap.02 Accident Prevention / Safety Regulations
CHAP.02 ACCIDENT PREVENTION / SAFETY REGULATIONS 02.1 GENERAL CONSIDERATIONS • The manual refers to essential aspects of the directives, regulations and dispositions on using the machine, summarising its most significant points. • General legal regulations and mandatory rules regarding injury prevention and environmental protection must be observed. -
Page 8: Safety Regulations For Extraordinary Maintenance And Installation
• In alarm status for failed start up, do not try to restart the stove until the firebox has been thoroughly cleaned • The appliance must always be started up with the firebox empty, without pellets and without unburned fuel from previous use. -
Page 9: Equipment For Operators And Maintenance Personnel
RESIDUAL RISKS Though JOLLY MEC CAMINETTI S.p.A. does everything within its power to produce its systems with the greatest competence regarding safety and consulting all the directives, laws, and regulations available, there are still, if minor, some residual risks during the phases of: •... -
Page 10: Chap.03 Handling And Transport
CHAP.03 HANDLING AND TRANSPORT 03.1 RECEIVING GOODS The machine is delivered on a pallet, packed in a wooden cage with a cellophane hood. when receiving merchandise, check that: • all packaging is intact • all of the merchandise indicated on the delivery bill has actually been delivered •... -
Page 11: Chap.04 Ecological Regulations
CHAP.04 ECOLOGICAL REGULATIONS 04.1 WASTE MATERIALS AND THEIR DISPOSAL Spare parts replaced during the machine’s product life are to be considered waste and must be taken to special collection centres or entrusted to authorised disposal centres. Ashes must be placed in a metal container with a sealed lid. The closed container must be placed on a non-combustible base and kept away from combustible materials until all the embers have been extinguished. -
Page 12: Chap.05 Description
European standard EN 13229, operating with wood (ALTERNATIVE AND RENEWABLE ENERGY). Foghet Evo is a monobloc consisting of a double-wall heat exchanger in special steel whose particular construction allows maximum exploitation of the combustion heat, obtaining high efficiencies of up to 90%, making it one of the best in the category for efficiency and emissions. -
Page 13: Product Identification
Stove performance values measured during inspection tests according to the indicated reference and EC markings are also included on the plate. FOGHET EVO Acqua Via San Giuseppe, 2 - 24060 Telgate - BG - * EN 13229 Tel. -
Page 14: Chap.06 Technical Data
CHAP.06 TECHNICAL DATA 06.1 HOMOLOGATION Technical specifications resulting from laboratory tests conducted according to EN 13229 test methods at the CERTIFICATION institute. Description Nominal value Burned power (by wood) 18,91 Consumption at max power (by wood) kg/h Max power give to the environment (by wood) 5,85 Thermal rated output (by wood) 15,89... -
Page 15: Recommended Fuels
06.2 RECOMMENDED FUELS WARNING WOOD QUALITY IS VERY IMPORTANT; PLEASE READ THIS SECTION CAREFULLY WOOD COMBUSTION Wood clean burning is a process that reflects the natural decomposition itself; this means that CO (carbon dioxide) released does not increase or damage the CO original contents in the atmosphere. -
Page 16: Components
06.3 COMPONENTS The fireplace is supplied preassembled and tested, in wooden crate on pallets, packed with a cellophane hood, polystyrene and with the following parts: • Assembly, use and maintenance manual • Boiler body complete with tested hydraulic kit • Control panel with electronic controller •... -
Page 17: Chap.07 Positioning And Connections For The Installer
CHAP.07 POSITIONING AND CONNECTIONS FOR THE INSTALLER 07.1 FLUE OR FUME EXHAUST SYSTEM The flue or fume exhaust system is a fundamental element for the proper functioning of the stove and must comply with the following general standards: UNI EN 1856-1 Fireplaces - Requirements for metal fireplaces - Products for fireplace systems UNI EN 1856-2 Fireplaces - Requirements for metal fireplaces - Internal ducts and metal exhaust pipes... -
Page 18: Installation Room Ventilation
Once the flue got insert in the foreseen connection fill the gap with the sealing in outfit (F . 3). The Foghet Evo fume exhaust has a diameter of 179 mm. A 150 mm diameter flue can be inserted directly inside. Use a suitable union if you need to use a larger sized flue. -
Page 19: Prearrangement For Connections And Air Inlets Of The Stove Positioned In Acorner
07.3 PREARRANGEMENT FOR CONNECTIONS AND AIR INLETS OF THE STOVE POSITIONED IN A CORNER WARNING Electrical connections must be carried out by skilled personnel according to the regulations in force (CE 2006/95 and 2004/108). Mains water inflow for thermal discharge 3/4” Pressure relief valve discharge 3/4”... -
Page 20: Prearrangement For Electrical Connections And Air Inlets With Wall Installation
07.4 PREARRANGEMENT FOR ELECTRICAL CONNECTIONS AND AIR INLETS WITH WALL INSTALLA- TION WARNING Electrical connections must be carried out by skilled personnel according to the regulations in force (CE 2006/95 and 2004/108). Mains water inflow for thermal discharge 3/4” Pressure relief valve discharge 3/4” (If the safety valve is opened, be very careful as very hot water may be expelled) Heating flow 3/4”... - Page 21 Installation distances from flammable materials • Straight Distance from flammable side walls: A=100 mm • Straight Distance from flammable rear walls: B=100 mm • Insulation Thickness for side/ rear walls: C=80 mm • Straight Distance from flammable floors: D=400 mm • Floor Insulation Thickness (Silicate Calcium High Temperature proof ASTM C 533 TYPE II): E=40 mm •...
-
Page 22: Example Of Installed And Clad Fireplace
07.5 EXAMPLE OF INSTALLED AND CLAD FIREPLACE Fume exhaust Hood front circulation grille 40x10 cm upper edge 10 cm from ceiling Control panel Smoke baffle Boiler Door Ash pan Door handle Ducting of wood combustion air 10. Power supply 220 V-50 Hz 11. -
Page 23: Control Unit Electrical Wiring Diagram
07.6 CONTROL UNIT ELECTRICAL WIRING DIAGRAM WARNING Electrical connections must be carried out by skilled personnel according to the regulations in force (2006/95/EC and 2004/108/EC). Terminal INLETS correspondence A common to I1 - I2 Probes of B-C Terminal Blocks B Fireplace Water Probe C I2* Probe D common for I3 Probe E I3 Probe, Water Pressure Probe... -
Page 24: Hydraulic Kit
07.7 HYDRAULIC KIT Foghet Evo comes with a standard closed tank hydraulic kit already assembled and tested, but can also be supplied with a basic hydraulic kit fitted with safety devices only. • Basic Hydraulic kit The basic hydraulic kit consists of the following components:... - Page 25 Cold water inlet for cooling serpentine (mandatory connection) Discharge pipe safety devices (mandatory connection) Hot water delivery to the system (mandatory connection Circulation pump 11. Thermal discharge valve (mandatory connection) 12. Expansiona tank 13. Boiler drain 14. Hot water return flow from the system (mandatory connection) 15.
-
Page 26: Chap.08 Use And Maintenance For The User
CHAP.08 USE AND MAINTENANCE FOR THE USER 08.1 CONTROL UNIT The display built-in ECU (Electronic Command Unit) consents to give drive inputs to the fireplace and to get information about its operating status. • COMPONENTS The device comes packaged in a cardboard box containing the following components: Code Description Values... - Page 27 • KEY FUNCTIONS Pulsante Descrizione Modalità Azione Turns on EsEt WORK Turns off ALARM Resets the alarm MENU Returns to the previous level Decrease EDIT VALUE Decreases the selected menu and/or setting value Increase EDIT VALUE Increases the selected menu and/or setting value Opens the menu ntER WORK...
-
Page 28: Wood Functioning
08.2 WOOD FUNCTIONING • MAXIMUM FUEL QUANTITIES Wood: 3 blocks of approx. 1 kg each, max length 35 cm and width approx. 6 cm per side (use of pieces of chopped wood is recommended) Pressed wood logs (in pieces): 3 pieces of approx. 1 kg each, max. length 35 cm. The stove output performance also depends on the flue draught. - Page 29 • INSTALLATION AND USE OF SMOKE DAMPER Step 1: Fit the damper, with the rod and regulating unit. The fume damper must be assembled so that when the damper is in vertical Shutter (completely open), the dial is horizontal (with the index on the right) and also the position indicator (IIII position) and it can be easily removed to clean the flue by extracting the rod (see F .
-
Page 30: Tips And Warnings For The User
08.3 TIPS AND WARNINGS FOR THE USER WARNING IT IS IMPORTANT THAT THERE IS ALWAYS WATER IN THE BOILER AT A PRESSURE OF 1 to 1.2 BAR WHEN COLD, AND THAT THE MAINS CONNECTION FOR THE WATER REQUIRED TO COOL THE FIREPLACE IS NEVER OBSTRUCTED. -
Page 31: Ordinary Maintenance (By The Costumer)
08.4 ORDINARY MAINTENANCE (by the costumer) WARNING Before starting any type of cleaning, switch off the main switch and make sure that the appliance is cold. Never restart the stove before completing these operations and correctly reassembling all components. Cleaning tools supplied Flue brush Small brush Poker... - Page 32 Cleaning of the fume deflector Every 20 days, or even more frequently according to the type of fuel used, the flue chimney draught and the weather conditions, it is compulsory to remove the upper diffuser and clean it to prevent the fume outlet from clogging, causing the fumes to flow back into the room.
- Page 33 Cleaning the fireplace body Remove the cast iron grate and the firebox. Open the deflector to remove any deposited ash. Remove it to access and clean the upper part of the fireplace. Use a brush to shake the turboclean in the flue. To remove the turboclean, lift it slightly, rotate it by 90 degrees and slide it out;...
-
Page 34: Special Maintenance
08.5 SPECIAL MAINTENANCE WARNING EACH YEAR YOU SHOULD CLEAN ANY DEPOSITS IN THE BOILER. THIS CLEANING SHOULD BE DONE ONLY IF YOU HAVE THE ABILITY AND COMPETENCE TO BE ABLE TO PERFORM, OR CONTACT A QUALIFIED TECHNICIAN. Carefully follow the sequences: •... -
Page 35: Chap.09 Fault Diagnosis And Troubleshooting
09.1 PROBLEMS WARNING In accordance with the laws in force on safety for electrical appliances, a Jolly Mec Technical Assistance Centre or qualified personnel must obligatorily be contacted for all installation, maintenance or interventions that require access to electrical parts. -
Page 36: Alarm Messages
09.2 ALARM MESSAGES Following is an overview on appliance alarms linked to the probable causes and some potential solutions. If an alarm occurs with a certain frequency, contact the Jolly Mec Technical Assistance Centre . Alarm code Alarm text Alarm causes Main solutions •... - Page 37 NOTES...
- Page 40 Via S.Giuseppe 2 - 24060 Telgate (Bg) Italy Tel. +39 035.83.59.211 Fax +39 035.83.59.203 www.jolly-mec.it - info@jolly-mec.it...
