Welcome. . .
Thank you for buying an
IBM xSeries server.
Installation Guide
This server
contains information for setting
up and configuring your server.
For detailed information
about your server, view the
User's Reference
Documentation CD.
You can also find the most
current information about your
server on the IBM Web site at:
http://www.ibm.com/pc/support
®
(Type 8479)
(Type 8481)
on the
Install options:
• Drives
• Microprocessors
• Adapters
• Memory
Install the server in
the rack, if required
Cable the server
and options
Start the server
No
Did the server
start correctly?
Yes
Use ServerGuide™
to set up and
configure hardware
No
Did configuration
complete?
Yes
Use
No
ServerGuide to
install operating
system?
Yes
Use ServerGuide to
install applications,
such as IBM systems
management software
and IBM ServeRAID
programs
System is ready to use.
Go to the Server Support
flow chart to register
and profile your server.
Go to the Server Support
flow chart
Go to the Web for instructions,
http://www.ibm.com/pc/support
Advertisement
Table of Contents
Related Manuals for IBM eServer 200VL xSeries
Summary of Contents for IBM eServer 200VL xSeries
-
Page 1: Installation Guide
User's Reference on the Documentation CD. Did configuration You can also find the most complete? current information about your server on the IBM Web site at: http://www.ibm.com/pc/support ServerGuide to Go to the Web for instructions, install operating http://www.ibm.com/pc/support system? Use ServerGuide to... -
Page 2: Server Support
Register and profile your server properly? After you register and profile, you will be able to: • Diagnose problems using the IBM Online Assistant • Participate in the IBM discussion forum • Receive e-mail notifications of technical updates related to your profiled products... - Page 3 IBM xSeries 200 and xSeries 200VL Installation Guide SC32-P041-70...
- Page 4 39 and Appendix B, “Notices,” on page 49. Second Edition (September 2001) © Copyright International Business Machines Corporation 2001. All rights reserved. US Government Users Restricted Rights – Use, duplication or disclosure restricted by GSA ADP Schedule Contract with IBM Corp.
-
Page 5: Table Of Contents
Purchasing additional services ......... 37 © Copyright IBM Corp. 2001... - Page 6 Index ............55 IBM xSeries 200 and xSeries 200VL: Installation Guide...
-
Page 7: Safety
Vor der Installation dieses Produkts die Sicherheitshinweise lesen. Prima di installare questo prodotto, leggere le Informazioni sulla Sicurezza Les sikkerhetsinformasjonen (Safety Information) før du installerer dette produktet. Antes de instalar este produto, leia as Informações sobre Segurança. © Copyright IBM Corp. 2001... - Page 8 Antes de instalar este producto lea la información de seguridad. Läs säkerhetsinformationen innan du installerar den här produkten. IBM xSeries 200 and xSeries 200VL: Installation Guide...
- Page 9 Statement 2 CAUTION: When replacing the lithium battery, use only IBM Part Number 33F8354 or an equivalent type battery recommended by the manufacturer. If your system has a module containing a lithium battery, replace it only with the same module type made by the same manufacturer.
- Page 10 Statement 4 ≥ 18 kg (39.7 lb) ≥ 32 kg (70.5 lb) ≥ 55 kg (121.2 lb) CAUTION: Use safe practices when lifting. viii IBM xSeries 200 and xSeries 200VL: Installation Guide...
- Page 11 Statement 5 CAUTION: The power control button on the device and the power switch on the power supply do not turn off the electrical current supplied to the device. The device also might have more than one power cord. To remove all electrical current from the device, ensure that all power cords are disconnected from the power source.
- Page 12 IBM xSeries 200 and xSeries 200VL: Installation Guide...
-
Page 13: Chapter 1.Introduction
Also included is an IBM xSeries Documentation CD, which provides detailed information about your server. Your server comes with a limited warranty and IBM Server Start Up Support. If you have access to the World Wide Web, you can obtain up-to-date information about your server and other IBM server products at the following World Wide Web address: http://www.ibm.com/eserver/xseries. -
Page 14: Features And Specifications
— Minimum: 0.095 kVA extender board • Sound power, idling: 5.1 bel — Maximum: 0.470 kVA maximum AGP slot: • Sound power, operating: 5.3 bel maximum Accelerated graphics port (AGP) (contains the video adapter) IBM xSeries 200 and xSeries 200VL: Installation Guide... -
Page 15: Notices And Statements Used In This Book
Notices and statements used in this book The caution and danger statements also appear in the multilingual safety book provided on the IBM xSeries Documentation CD. Each statement is numbered for easy reference to the corresponding statement in the safety book. -
Page 16: Major Components Of The Xseries 200 And Xseries 200Vl
Note: The illustrations in this document might differ slightly from your hardware. Intrusion switch Adapter retaining EMC shield bracket Memory modules Filler panel Microprocessor Drive cage Front door Adapter support bracket Support bracket assembly Cover IBM xSeries 200 and xSeries 200VL: Installation Guide... -
Page 17: System Board Internal Cable Connectors
System board internal cable connectors The following illustration identifies system and extender board connectors for internal cables. System fan 2 Microprocessor (SYSFA2) fan sink Main power (CPUFA1) (JWR1) Front panel connector (J1) Secondary IDE (IDE2) Primary IDE (IDE1) Diskette drive (FDD1) CD audio (JCD1) - Page 18 IBM xSeries 200 and xSeries 200VL: Installation Guide...
-
Page 19: Chapter 2.Installing Options
This section is for all users, but is written with the experienced user in mind. If you need more detailed installation information for options, refer to the User’s Reference on the IBM xSeries Documentation CD. Moving the stabilizing feet The four feet on the bottom of the server provide additional stability when the feet are placed in the stabilizing position. - Page 20 If you do so, make sure the feet are in the horizontal position (see the previous steps). Otherwise, the feet might break off the server because of the weight of the server. IBM xSeries 200 and xSeries 200VL: Installation Guide...
-
Page 21: Removing The Side Cover
Removing the side cover The following information describes how to remove the side cover. Note: The illustrations in this document might differ slightly from your hardware. Cover-release latch Key lock Complete the following steps to remove the side cover of the server. 1. -
Page 22: Removing The Support-Bracket Assembly
152.4 mm (6 in.). 5. Pull the front end of the support-bracket assembly away from the server and place the assembly aside. To reinstall the support-bracket assembly, reverse these steps. IBM xSeries 200 and xSeries 200VL: Installation Guide... -
Page 23: Working With Adapters
Working with adapters Your server comes with adapter connectors, called slots. The AGP video adapter is installed in the AGP slot and some server models come with a SCSI adapter installed in PCI expansion slot 2. You can install up to five PCI adapters in PCI expansion slots 1 through 5. -
Page 24: Installing An Adapter
4. If you are installing a full-length adapter, rotate the front adapter support bracket to the open (unlocked) position. 5. Rotate the rear adapter retaining bracket to the open (unlocked) position, and then remove it from the server. IBM xSeries 200 and xSeries 200VL: Installation Guide... - Page 25 6. Remove the PCI expansion-slot cover. From the rear of the server, press in on the slot cover. Grasp it and pull it out of the slot. Store it in a safe place for future use. Attention: PCI expansion-slot covers must be installed on all vacant slots. This maintains the electronic emissions characteristics of the server and ensures proper cooling of server components.
-
Page 26: Installing A Scsi Or Serveraid Adapter
7. If you have other options to install, do so now. 8. Reinstall the side cover. See “Installing the cover” on page 22 for details. 9. Reconnect the external cables and power cords; then, turn on the peripheral devices and the server. IBM xSeries 200 and xSeries 200VL: Installation Guide... -
Page 27: Installing Internal Drives
Installing internal drives Your server comes with an IDE CD-ROM drive installed in bay 1, and a 3.5-in., 1.44 MB diskette drive in bay 3. Some sever models have a hard disk drive installed in bay Bay 1 Bay 2 Bay 3 Bay 4 Bay 5... -
Page 28: Installing A Drive In Bay 2 Or 4
4. Use a screwdriver to gently pry the filler panel and EMC shield away from the server. Note: If you are installing a drive that is a laser product, observe the following safety precaution. IBM xSeries 200 and xSeries 200VL: Installation Guide... - Page 29 Statement 3 CAUTION: When laser products (such as CD-ROMs, DVD drives, fiber optic devices, or transmitters) are installed, note the following: • Do not remove the covers. Removing the covers of the laser product could result in exposure to hazardous laser radiation. There are no serviceable parts inside the device.
-
Page 30: Installing A Hard Disk Drive In Bay 5, 6, Or 7
If your server has hard disk drives installed in the drive cage, disconnect the power and signal cables from the rear of the drives. b. Rotate the drive cage out of the server until it locks into place over the drive cage retention tab. IBM xSeries 200 and xSeries 200VL: Installation Guide... -
Page 31: Installing Memory Modules
Your server supports 128 MB, 256 MB, and 512 MB DIMMs. Your server supports a minimum of 128 MB and a maximum of 1.5 GB of system memory. See the ServerProven list at http://www.ibm.com/pc/compat for a list of memory modules for use with your server. - Page 32 Insert the DIMM into the connector by aligning the DIMM edges with the slots at each end of the DIMM connector. Firmly press the DIMM straight down into the connector by applying pressure on both ends of the DIMM simultaneously. IBM xSeries 200 and xSeries 200VL: Installation Guide...
-
Page 33: Installing A Security U-Bolt
Be sure that the retaining clips snap into the locked position when the DIMM is firmly seated in the connector. If a gap exists between the DIMM and the retaining clips, the DIMM has not been properly installed. In this case, open the retaining clips and remove the DIMM;... -
Page 34: Installing The Cover
1. The illustrations in this document might differ slightly from your hardware. 2. If you removed the support-bracket assembly after you removed the cover, reinstall it before you install the cover. See “Removing the support-bracket assembly” on page 10 for details. IBM xSeries 200 and xSeries 200VL: Installation Guide... -
Page 35: Cabling The Server
Complete the following steps to install the server cover. 1. Clear any cables that might impede the reinstallation of the cover. 2. Install the side cover: Note: The cover-release latch must be in the unlocked (opened) position before reinstalling the cover on the sever. a. - Page 36 IBM xSeries 200 and xSeries 200VL: Installation Guide...
-
Page 37: Chapter 3.Server Power, Controls, And Indicators
You can disconnect the server power cords from the electrical outlets to shut off all power to the server. Note: After disconnecting the power cords, wait approximately 15 seconds for your system to stop running. © Copyright IBM Corp. 2001... -
Page 38: Server Controls And Indicators
Hard disk drive activity light: When this light is on, the hard disk drive is in use. Power-on light: This status indicator lights when you turn on your server. Power-control button: Press this button to manually turn the server on or off. IBM xSeries 200 and xSeries 200VL: Installation Guide... -
Page 39: Chapter 4.Configuring Your Server
ServerGuide™ CDs The ServerGuide CDs include software setup and installation tools that are specifically designed for IBM xSeries servers. You can use these CDs during the initial installation of your server to configure the server hardware and to simplify your NOS installation. The ServerGuide CDs also contain a collection of application programs, which you can install after your server is up and running. -
Page 40: Starting The Utility Programs
Press the F5 key to switch between color and monochrome modes (if your monitor permits). 5. Follow the instructions on the screen to change the settings of the selected items; then, press Enter. IBM xSeries 200 and xSeries 200VL: Installation Guide... -
Page 41: Using The Pxe Boot Agent Utility Program
Using the PXE boot agent utility program The PXE boot agent is a built-in, menu-driven configuration utility program that you can use to: • Select whether to display setup prompt • Set menu wait time • Select legacy operating-system wake-up support Attention: The network startup protocols and startup order are not supported on this product. - Page 42 IBM xSeries 200 and xSeries 200VL: Installation Guide...
-
Page 43: Chapter 5.Solving Problems
If you cannot locate and correct the problem using the information in this section, refer to the "Solving problems" section in the User’s Reference on the IBM xSeries Documentation CD. Diagnostic tools overview... -
Page 44: Serverguide Startup Problems
Note: Refer to the “Solving Problems" section in the User’s Reference on the IBM xSeries Documentation CD for more detailed information about the POST beep codes. ServerGuide startup problems Look for the symptom in the left column of the chart. Probable solutions to the problem are in the right column. -
Page 45: Troubleshooting Chart
Troubleshooting chart Notes: 1. See the "Solving Problems" section in the User’s Reference on the IBM xSeries Documentation CD for more detailed troubleshooting charts. 2. If you cannot find the problem in the troubleshooting charts, run the diagnostic programs. If you have run the diagnostic test programs, or if running the tests does not reveal the problem, call for service. - Page 46 The last option in each SCSI chain, or the end of the SCSI cable, is terminated correctly. External SCSI options are turned on. You must turn on an external SCSI options before turning on the server. For more information, see your SCSI and expansion enclosure documentation. IBM xSeries 200 and xSeries 200VL: Installation Guide...
-
Page 47: Chapter 6.Getting Information, Help, And Service
Canada, you can receive, by fax, marketing and technical information on many topics, including hardware, operating systems, and local area networks (LANs). You can call the IBM Automated Fax System 24 hours a day, 7 days a week. Follow the recorded instructions, and the requested information will be sent to your fax machine. -
Page 48: Calling For Service
README files and online help, that comes with the operating system or application program. Most IBM server products come with a set of diagnostic programs that you can use to help you identify hardware problems. See the troubleshooting information in your IBM documentation for instructions on using the diagnostic programs. -
Page 49: Telephone Numbers
01475-555 055 U.S.A. and Puerto Rico U.S.A. and Puerto Rico 1-800-772-2227 In all other countries or regions, contact your IBM reseller or IBM marketing representative. Purchasing additional services During and after the warranty period, you can purchase additional services, such as support for IBM and non-IBM hardware, operating systems, and application programs;... - Page 50 IBM xSeries 200 and xSeries 200VL: Installation Guide...
-
Page 51: Appendix A. Warranty Information
Parts - 3 years, labor - 3 years Warranty service and support With the original purchase of an IBM server product, you have access to extensive support. During the IBM Machine warranty period, you may call IBM or your reseller for problem-determination assistance under the terms of the IBM Statement of Limited Warranty. -
Page 52: Before You Call For Service
If you do not register your server with IBM, you might be required to present proof of purchase to obtain warranty service. Before you call for service You can solve many problems without outside assistance by following the troubleshooting procedures that IBM provides in the online help or in the publications that are provided with your server and software. - Page 53 WITHOUT WARRANTIES OF ANY KIND. Warranty Service To obtain warranty service for a Machine, contact IBM or your reseller. If you do not register your Machine with IBM, you may be required to present proof of purchase.
- Page 54 IBM or your reseller of changes in a Machine’s location. IBM is responsible for loss of, or damage to, your Machine while it is 1) in IBM’s possession or 2) in transit in those cases where IBM is responsible for the transportation charges.
-
Page 55: Part 2 - Country-Unique Terms
Governing Law Both you and IBM consent to the application of the laws of the country in which you acquired the Machine to govern, interpret, and enforce all of your and IBM’s rights, duties, and obligations arising from, or relating in any manner to, the subject matter of this Agreement, without regard to conflict of law principles. - Page 56 2. as to any other actual damage arising in any situation involving nonperformance by IBM pursuant to, or in any way related to the subject of this Statement of Limited Warranty, IBM’s liability will be limited to the charge paid by you for the individual Machine that is the subject of the claim.
- Page 57 PEOPLE’S REPUBLIC OF CHINA (PRC) Governing Law: The following replaces this Section: Both you and IBM consent to the application of the laws of the State of New York (except when local law requires otherwise) to govern, interpret, and enforce all your and IBM’s rights, duties, and obligations arising from, or relating in any manner to, the...
- Page 58 The minimum warranty period for Machines is six months. In case IBM or your reseller is unable to repair an IBM Machine, you can alternatively ask for a partial refund as far as justified by the reduced value of the unrepaired Machine or ask for a cancellation of the respective agreement for such Machine and get your money refunded.
- Page 59 Limitation of Liability: The following replaces item 2 in this Section: as to any other actual direct damages, IBM's liability will be limited to the total amount you paid for the Machine that is the subject of the claim. For purposes of this item, the term "Machine"...
- Page 60 The following item is added to this paragraph: 3. breach of IBM’s obligations implied by Section 12 of the Sale of Goods Act 1979 or Section 2 of the Supply of Goods and Services Act 1982.
-
Page 61: Appendix B. Notices
Web sites. The materials at those Web sites are not part of the materials for this IBM product, and use of those Web sites is at your own risk. -
Page 62: Trademarks
GB stands for approximately 1000000000 bytes. When referring to hard disk drive capacity or communications volume, MB stands for 1000000 bytes, and GB stands for 1000000000 bytes. Total user-accessible capacity may vary depending on operating environments. IBM xSeries 200 and xSeries 200VL: Installation Guide... -
Page 63: Electronic Emission Notices
Unless otherwise stated, IBM makes no representations or warranties with respect to non-IBM products. Support (if any) for the non-IBM products is provided by the third party, not IBM. Some software may differ from its retail version (if available), and may not include user manuals or all program functionality. -
Page 64: Australia And New Zealand Class A Statement
This product is in conformity with the protection requirements of EU Council Directive 89/336/EEC on the approximation of the laws of the Member States relating to electromagnetic compatibility. IBM cannot accept responsibility for any failure to satisfy the protection requirements resulting from a nonrecommended modification of the product, including the fitting of non-IBM option cards. -
Page 65: Power Cords
Power cords For your safety, IBM provides a power cord with a grounded attachment plug to use with this IBM product. To avoid electrical shock, always use the power cord and plug with a properly grounded outlet. IBM power cords used in the United States and Canada are listed by Underwriter’s Laboratories (UL) and certified by the Canadian Standards Association (CSA). - Page 66 Islands, Colombia, Costa Rica, Dominican Republic, Ecuador, El Salvador, Guatemala, Guyana, Haiti, Honduras, Jamaica, Japan, Korea (South), Liberia, Mexico, Netherlands Antilles, Nicaragua, Panama, Peru, Philippines, Saudi Arabia, Suriname, Taiwan, Trinidad (West Indies), United States of America, Venezuela IBM xSeries 200 and xSeries 200VL: Installation Guide...
-
Page 67: Index
2 major components 4 installing 15 memory documentation CD 1 configuration changes 19 drive specifications 2 bay filler panel 16 memory module drives installing 19 installing 15 order of installation 19 specifications 2 supported 19 © Copyright IBM Corp. 2001... - Page 68 SCSISelect Utility program 27 SCSISelect utility program starting 28 server configuring 27 model number 1 serial number 1 turning off 25 turning on 25 server keys request replacement 1 ServerGuide startup problems 32 IBM xSeries 200 and xSeries 200VL: Installation Guide...
- Page 70 Part Number: 32P0417 Printed in the United States of America 32P 417...
