xSeries 225
Type 8647

Installation Guide

Welcome. . .
Thank you for buying an
IBM xSeries server.
This server
Installation Guide
contains information for setting
up and configuring your server.
For detailed information
about your server, view the
User's Guide
on the
Documentation CD.
You can also find the most
current information about your
server on the IBM Web site at:
http://www.ibm.com/pc/support
Install options:
• Drives
• Microprocessors
• Adapters
• Memory
Install the server in
the rack, if required
Cable the server
and options
Start the server
No
Did the server
start correctly?
Yes
Use ServerGuide™
to setup and
configure hardware
No
Did configuration
complete?
Yes
Use
No
ServerGuide to
install operating
system?
Yes
Use ServerGuide to
install applications,
such as IBM systems
management software
and IBM ServeRAID
programs
System is ready to use.
Go to the Server Support
flow chart to register
and profile your server.
Go to the Server Support
flow chart
Go to the Web for Instructions,
http://www.ibm.com/pc/support/

Advertisement

Table of Contents
loading
