In-Hom® Display Status Information; Reminders - Smart Start IN-HOM User Instructions

®
IN-HOM D S
ISPLAY TATUS
DISPLAY MESSAGE
INITIALIZING
BLOW
TEST
ANALYZING
PASS
WARN
FAIL
VIOL
MISSED TEST
WAIT mm:ss
LOCK mm:22
LOCKOUT SRVC
ViolLck ## hr
LOCKOUT VIOL
RECALL: 5 XX
RECALL: 5 00h
APPT MM/DD
BLOW HARDER
BLOW SOFTER
DON'T INHALE
CELL CALL-IN
PLEASE RETRY
R
EMINDERS
You must drink water prior to every breath test. This will ensure a clean mouth.
•
It is a violation of your IN-HOM
•
Do not use a breath freshening agent before taking a test as most of these contain alcohol.
•
Once the device begins asking for a test, be sure to take the test; NOT doing so will result in a VIOLATION.
•
Place the device where you can see the display and hear the beep tones. If a test is requested and you are in a loud environment, you may not hear
•
the beeping sound from the unit.
Do not place the IN-HOM
•
Also, do not expose the unit to moisture from liquids. You are responsible for damages to the device.
Your picture is being taken and viewed. Dress appropriately at all times.
•
Remember to leave the IN-HOM
•
to transport the device.
®
If your IN-HOM unit locks out or is not operating properly, please call Smart Start at 1-800-880-3394 for assistance. We may ask you to bring the
unit to the nearest location for service.
SS440-0009-00
I
NFORMATION
DESCRIPTION
The unit is preparing for a breath test.
The unit is ready to accept a breath test.
The unit is accepting the test.
The unit is processing the breath sample.
Test is complete and the alcohol content of the sample was below the Fail level.
Test is complete and the alcohol was detected. But, the sample was below the Fail level.
Test is complete and the alcohol content of the sample was above the Fail level. Continue to take tests until have PASS or unit
returns to the idle state (display = BLOW)
Test is complete and the alcohol content of the sample was above the Violation level. Continue to take tests until have PASS or
unit returns to the idle state (display = BLOW)
A test with the result of "PASS" was not provided during a "test window" or "re-test window"
Device is in a WAIT state following a FAIL or VIOLATION. The minutes and seconds will countdown showing the WAIT time
Device is in a temporary LOCK state following a FAIL or VIOLATION in a test window. The minutes and seconds will
countdown showing the LOCK time
A service lockout is indicated by the display of "LOCKOUT SRVC". The device is in lockout due to missing your service date or
cellular reception reasons. You are not able to take a test and all skipped test windows are considered violations. You are required
to call your service provider for further instructions on servicing your unit. See above message regarding the service lockout grace
period timer.
This message indicates that you have exceeded the number of violations allowed and the unit will go into violation lockout within
"##" number of hours. Once in lockout, you will not be able to take a test and all skipped test windows are considered violations.
DO NOT IGNORE THE VIOLATION LOCKOUT WARNING grace period.
A violation lockout is indicated by the display of "LOCKOUT VIOL". A violation is caused by a HIGH LEVEL breath failure
OR by missing a test. The device is in lockout due to violations. You are not able to take a test and all skipped test windows are
considered violations. You are required to call your service provider for further instructions on servicing your unit. See above
message regarding the violation lockout grace period timer.
A reminder, where XX is the number of days or hours remaining before the device locks out due to poor cellular reception.
A modem recall lockout is indicated by the display of "LOCKOUT SRVC". Before completely locking out, the display will show
"RECALL:5 XX, where XX is the number of days or hours remaining before the device locks out due to poor cellular reception.
When unit shows "RECALL: 5 00h", this means the unit cannot get cellular service and will go into lockout in less than 60 minutes.
Once the grace period time expires, you will not be able to take a test and are required to call your service provider for further
instructions on servicing your unit
A reminder that the unit cannot get cellular service and will go into lockout in less than 60 minutes.
A reminder, your appointment date is approaching. Starts flashing 5 days before your appointment date.
User did not blow long enough to finish the test – retest is required. Wait for the unit to display BLOW and take another test. This
time, blow longer and slightly harder
User blowing too hard – retest is required. Wait for the unit to display BLOW and take another test. This time, blow longer and
softer (not as hard).
Unit detected the user inhaling during test – retest is required. Wait for the unit to display BLOW and take another test. This
time, do not inhale.
Unit is in cellular mode uploading test results. DO NOT UNPLUG device at this time. Unit will continue in cellular mode until
data upload is complete.
Unit did not complete successful test – retest is required. Wait for the unit to display BLOW and take another test.
®
program to have another person take a test on your device.
®
unit on the floor, around extreme temperatures, where it is prone to damage, or where you cannot see it or hear it.
®
unit connected to power; not doing so may result in a missed test. The power may be removed if you plan
SMART START IN-HOM
User Instructions
Rev. 02-04/2014
®
