Owner's Guide
Product image shown may vary from actual product. See features for comparisons.
Freedom HFS Inverter/Chargers
Model Product Numbers
807-1055
807-1055-02
807-2055
807-2055-01
807-2055-02

Advertisement

Table of Contents
loading

Summary of Contents for Xantrex 807-1055

  • Page 1 Owner’s Guide Product image shown may vary from actual product. See features for comparisons. Freedom HFS Inverter/Chargers Model Product Numbers 807-1055 807-1055-02 807-2055 807-2055-01 807-2055-02...
  • Page 3: Contact Information

    To view, download, or print the latest revision, visit the website shown under Contact Freedom HFS 1055 (1000-watt) Models: Information. 807-1055 (Freedom HFS 1055 120VAC Standard Model) 807-1055-02 (Freedom HFS 1055 120VAC EMS Model) Freedom HFS 2055 (2000-watt) Models: 807-2055 (Freedom HFS 2055 120VAC Standard Model)
  • Page 4 Purpose Related Information The purpose of this Owner’s Guide is to provide explanations and You can find more information about Xantrex products and services at procedures for operating, maintaining, and troubleshooting a Freedom HFS www.xantrex.com. Sine Wave Inverter/Charger for Recreational, Fleet Vehicle, or Marine installations.
  • Page 5: Important Safety Instructions

    Important Safety Instructions IMPORTANT: R ’ EAD AND SAVE THIS WNER UIDE FOR FUTURE REFERENCE DANGER indicates an imminently hazardous situation, which, if not avoided, will result in death or serious injury. This guide contains important safety instructions for the Freedom HFS Sine Wave Inverter/Charger that must be followed during operation and troubleshooting.
  • Page 6: Safety Information

    Safety Information Do not expose this unit to rain, snow, or liquids of any type. This Before using the inverter/charger, read all instructions and cautionary markings on the unit, the batteries, and all appropriate product is designed for indoor use only. Damp environments will significantly shorten the life of this product and corrosion caused by sections of this manual.
  • Page 7 HAZARD OF ELECTRIC SHOCK, EXPLOSION, OR ARC EXPLOSION HAZARD FLASH • Charge only properly rated (such as 12 volts) lead-acid (GEL, AGM, Flooded, or lead-calcium) rechargeable batteries because other • Apply appropriate personal protective equipment (PPE) and follow battery types may explode. safe electrical work practices.
  • Page 8: Precautions When Working With Batteries

    Precautions When Working With Batteries IMPORTANT: Battery work and maintenance must be done by qualified PHYSICAL INJURY HAZARD personnel knowledgeable about batteries to ensure compliance with battery This Freedom HFS Sine Wave Inverter/Charger is not intended for use by handling and maintenance safety precautions. persons (including children) with reduced physical, sensory, or mental capabilities or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a...
  • Page 9 Precautions When Preparing to Charge If battery acid contacts skin or clothing, wash immediately with soap and water. If acid enters your eye, immediately flood it with running cold water for at least twenty minutes and get medical attention immediately. EXPOSURE TO CHEMICALS AND GASES HAZARD Use extra caution to reduce the risk of dropping a metal tool on the battery.
  • Page 10 Precautions When Placing the Inverter/Charger Regulatory The Freedom HFS Sine Wave Inverter/Charger is certified to appropriate US and Canadian standards. For more information see “Regulatory Approvals” on page 41. FIRE AND BURN HAZARDS The Freedom HFS Sine Wave Inverter/Charger is intended to be used for Do not install the inverter/charger or any part of its supplied wiring in mobile or commercial applications.
  • Page 11 FCC Information to the User This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 13: Table Of Contents

    Contents Important Safety Instructions ..................iii Introduction .
  • Page 15: Introduction

    • one display panel mounting bezel (not shown) • one set of lock washers and nuts (not shown) NOTE: If any of the items are missing, contact Xantrex or any authorized Xantrex dealer for replacement. See “Contact AC compartment communications...
  • Page 16: Key Features

    If so, the Freedom HFS automatically shuts down when the maximum operating limit is exceeded. a.Freedom HFS 1055 120VAC (PN: 807-1055) and Freedom HFS 1055 120VAC EMS (PN: 807-1055-02). b.,Freedom HFS 2055 120VAC (PN: 807-2055), Freedom HFS 2055 120VAC Truck (PN: 807-2055-01), and Freedom HFS 2055 120VAC EMS (PN: 807- c.Assuming the inverter/charger is connected to a battery source with an adequate...
  • Page 17 However, some batteries which have been left uncharged for days can become severely damaged thus, recharging is futile. b.Available on the Freedom HFS 1055 120VAC EMS model (PN: 807-1055-02) and Freedom HFS 2055 120VAC EMS model (PN: 807-2055-02). The inverter/charger features a 20-amp fused and switched output voltage supplied from the inverter/char- ger's positive terminal.
  • Page 18: Features

    Features Front Panel (Standard Models) Table 1 lists the default settings for the Freedom HFS system. You may record your settings in the right-hand column after you have configured the Freedom HFS. Table 1 Freedom HFS Default Values Item Default Setting Your Setting Alarm* ON (...
  • Page 19 Features Front Panel (Truck Model) Front Panel (EMS Models) Ignition FREEDOM HFS Power Enable Cont rol FREEDOM HFS FREEDOM HFS Rem ote STATUS Utility Select Battery FREEDOM HFS 1800 EMS Fault Feature Description Display panel displays inverter status and battery status information on the screen.
  • Page 20 Features Rear Panel (EMS Models) Rear Panel (All Other Models) Freedom HFS 1055 shown Feature Description Feature Description Negative DC cabling terminal that is pre-connected to an 18-inch (0.45m) Negative DC cabling terminal connects to the negative terminal of the battery cable with an Anderson connector.
  • Page 21 Remote jack is used for connecting the Display panel that ships with the inverter mode ON or OFF. See page 16 for additional information. Freedom HFS 1055 120VAC EMS (PN: 807-1055-02) and Freedom HFS 2055 120VAC EMS (PN: 807-2055-02). Each shipment comes with a 25-foot Three-digit LED display screen shows status information and fault codes.
  • Page 22 Features Side Panel (All Models) Feature Description 20 A supplementary protector provides overload protection for the GFCI receptacles. In a hard wired installation, the supplementary protector does not protect output wiring. However, for the EMS models, the hard-wired AC output connector is protected by both the 20 A supplementary protector and the GFCI.
  • Page 23: Freedom Inverter/Charger Configuration

    Freedom Inverter/Charger Configuration Setting Battery Types on the Main Unit Viewing Inverter/Charger Information You can attach different types of lead-acid batteries to the Freedom The LED screen displays inverter/charger information as well as HFS. Before installing batteries make sure that you configure the feature settings in coordination with the LED lights underneath the unit to optimize the charging process.
  • Page 24 Freedom Inverter/Charger Configuration Info and Setting LED Screen Info and Settings LED ,1 or ,1 or Inverter Mode none Setting D/ or $/ Alarm Setting none Low Voltage Setting VG/ or VG0 none or VG+ Battery Type Setting )/G or J(/ or none $* or ), . to ....
  • Page 25 Freedom Inverter/Charger Configuration Adjusting Feature Settings The Power and Select buttons can be used to: To cycle through the various feature settings: • change the charging current setting Press and hold the Inverter Power button for five seconds to enter the feature settings mode. •...
  • Page 26 Freedom Inverter/Charger Configuration To change the charger’s charging current setting: To change the inverter mode setting: By default the charging current is set to $. By default the inverter mode is set to ON (“,Q”). Press and hold the Inverter Power button for five seconds. Press and hold the Inverter Power button for five seconds.
  • Page 27 Freedom Inverter/Charger Configuration To adjust the alarm setting: NOTE: Inverter mode ON (“,Q”) will put the inverter on standby with By default the alarm is set to ON (“$/”).. the power save feature. Inverter mode ON (“,Q”) will put the inverter Press and hold the Inverter Power button for five seconds.
  • Page 28 Freedom Inverter/Charger Configuration To adjust the low battery shutdown setting: To adjust the battery type setting: By default the low battery shutdown voltage setting is set to By default the battery type setting is set to Flooded (“)/G”). Low (“VG/”). Press and hold the Inverter Power button for five seconds.
  • Page 29 Freedom Inverter/Charger Configuration To adjust the fixed voltage setting: To return all feature settings to factory default settings: NOTE: This setting is possible only when the Battery Type setting Press and hold the Inverter Power button for five seconds. is set to ),. See “To adjust the battery type setting:” on page 14. Press the Inverter Power button until the LED screen flashes By default the fixed voltage setting is set to 13.5 volts (“.”).
  • Page 30: Freedom Inverter/Charger Operation

    Freedom Inverter/Charger Operation Display Panel Operation Feature Description The Freedom HFS features a display panel with three-digit LED Three-digit LED display screen shows status information and detected fault codes. Upon startup, the screen shows the display to show inverter, AC source, and battery status information. display board (8.) and main board (U.) firmware versions.
  • Page 31 Freedom Inverter/Charger Operation Feature Description Select button • During inverter operation, press the button to choose what appears in the three-digit LED display: Battery Voltage, Battery Current, or Output Power. See “To change the inverter mode setting:” on page 12. NOTE: A corresponding LED lights up for each of the three items.
  • Page 32: Operating In Shore Power Mode

    Operating in Shore Power Mode The Freedom HFS operates in shore power mode when an AC source (a generator or utility power) is present at the AC input terminals. When the AC source is within operating range, the Freedom HFS unit bypasses inverter mode and powers the appliances connected to the unit.
  • Page 33: Operating In Inverter Mode

    Operating in Inverter Mode The Freedom HFS is in inverter operation (operating in inverter mode) when all the following conditions exist: ELECTRICAL SHOCK HAZARD • inverter power button is ON Turning the Inverter mode setting to OFF and/or turning the Inverter Power button off does not disconnect DC battery power from the Freedom HFS.
  • Page 34 Operating in Inverter Mode Status LED During Inverter Operation Table 2 Status LED during Inverter Operation The following summarizes the behavior of the Status LED during Status Display Inverter operation. Screen Condition Solid RED ( through Fault condition detected and AC output Table 2 Status LED during Inverter Operation power is not available.
  • Page 35: Checking Output Power

    Operating in Inverter Mode Checking Battery Status Turning the Audible Alarm ON or OFF During inverter operation, you can check the battery status by The Freedom HFS’s audible alarm can be turned ON or OFF. See pressing the Select button until the Battery Voltage LED (or Battery “To adjust the alarm setting:”...
  • Page 36: Operating During Transition Between Shore Power And Inverter Mode

    Operating During Transition Between Shore Power and Inverter Mode Transitioning from Shore Power to Inverter The Freedom HFS’s advanced power management is capable of transitioning power from an AC source to DC source within a Mode fraction of a second and vice-versa. When the unit is operating in shore power mode and shore power is The Freedom HFS automatically detects when shore power is lost, the Freedom HFS has less than 40 milliseconds to switch to...
  • Page 37: Operating Limits

    Operating During Transition Between Shore Power and Inverter Mode Operating Limits Power Output Input Voltage The Freedom HFS can deliver up to 1000 watts or 2000 watts of The allowable Freedom HFS input battery voltage ranges are shown continuous utility grade sine wave AC power. The wattage rating in the following table: applies to resistive loads such as incandescent lights.
  • Page 38: High Surge Loads

    Operating During Transition Between Shore Power and Inverter Mode Overload Conditions Over-temperature Conditions There are two kinds of overload conditions: During inverter operation, when the Freedom HFS’s internal temperature starts to approach its preset shutdown limit, the alarm • an overload warning will beep every two seconds and the display will show fault code •...
  • Page 39: Battery Charging

    Battery Charging Battery charging is possible only when shore power is present and the Freedom HFS unit is connected to a battery (or battery bank). NOTE: Voltage If an external DC load is The frequency of battery charging is determined by how much Bulk Absorption Float...
  • Page 40 Battery Charging Table 3 illustrates the battery charging status as shown on the Status Table 4 illustrates the battery charging voltage and current settings LED and display screen. for all the models. Table 3 Battery Charging Status LED Table 4 Battery Charging Voltage and Current Settings Absorption to Status LED Display Screen...
  • Page 41: Routine Maintenance

    Battery Charging Routine Maintenance Freedom HFS Unit Minimal maintenance is required to keep your Freedom HFS operating properly. Periodically you should: • Clean the exterior of the unit with a damp cloth to prevent the accumulation of dust and dirt. •...
  • Page 42: Invert Power Derating Vs. Ambient Temperature

    Invert Power Derating vs. Ambient Temperature If the unit is in inverter mode and in elevated ambient temperature above 25 °C, you will have to reduce power draw according to the following chart to avoid over-temperature shutdown. watts watts Freedom HF 2055 Freedom HFS 1055 30°C @12.5 volts...
  • Page 43: Troubleshooting

    Troubleshooting • Recent sequence of events • Any known unusual AC shore power factors such as low voltage, unstable generator output, etc. ELECTRICAL SHOCK AND ENERGY HAZARD • Whether any extreme ambient conditions existed at the Do not disassemble the Freedom HFS. It does not contain any user- time (temperature, vibrations, moisture, etc.) serviceable parts.
  • Page 44: Warning Messages

    Warning Messages Warning messages in the form of audible alarms and error codes The error codes are listed in Table 5 below. The text in the Error that appear on the display panel screen to alert you to an impending Code column appears on the display screen of the display panel.
  • Page 45 • Confirm that the external charging source is not the cause. The error may be caused by the internal battery charger system. Call Xantrex for support. Battery is bad or external DC AC shore power •...
  • Page 46 Warning Messages For error code (: • the display screen and the alarm will turn off after 30 seconds • after a five-minute shutdown delay, the unit will immediately stop inverting For error codes ( to (: • the unit will stop inverting For error codes (: •...
  • Page 47: Troubleshooting Reference

    Troubleshooting Reference ELECTRICAL SHOCK AND ENERGY HAZARD Do not disassemble the Freedom HFS. It does not contain any user-serviceable parts. Attempting to service the unit yourself could result in an electrical shock or burn. Failure to follow these instructions can result in death or serious injury.
  • Page 48 Troubleshooting Reference Table 6 Troubleshooting Reference Problem Possible Cause Solution No output voltage. The status LED is red. AC shore power is not available or out of operating range and the inverter has shut down with the display screen showing one of the following error codes: Low input voltage (fault code () •...
  • Page 49 Troubleshooting Reference Table 6 Troubleshooting Reference Problem Possible Cause Solution No output voltage. The Status LED is green GFCI has tripped or supplementary Check load and reset the GFCI or supplementary breaker. or yellow. breaker has tripped. Circuit breaker on the AC load panel or Reset the circuit breaker or check the AC output disconnect AC output disconnect has tripped.
  • Page 50 Troubleshooting Reference Table 6 Troubleshooting Reference Problem Possible Cause Solution No output voltage. The status LED is not The jumper wire on the power module Ensure the jumper wire is installed if the ignition control feature lighting up. panel connecting the “Ignition Control” is not in use.
  • Page 51: Inverter Applications

    Inverter Applications Motor Loads The Freedom HFS performs differently depending on the AC loads connected to it. If you are having problems with any of your loads, read this section. Induction motors (that is, motors without brushes) require two to six times their running current on start up.
  • Page 53: Specifications

    Specifications NOTE: Specifications are subject to change without prior notice. Physical Specifications Freedom HFS 1055 models Freedom HFS 2055 models L × W × H 19.2” (487mm) × 9.4” (240mm)× 4.7” (120mm) 19.2” (487mm) × 9.4” (240mm)× 4.7” (120mm) Net Weight 11 lbs (5 kg) 14.4 lbs (6.5 kg) Environmental Specifications...
  • Page 54 Specifications NOTE: These are inverter specifications. DC Input Freedom HFS 1055 models Freedom HFS 2055 models Operating voltage range for all models 10.5–16.5 VDC (low limit) 10.5–16.5 VDC (low limit) 11.8–16.5 VDC (mid limit) 11.8–16.5 VDC (mid limit) 12.1–16.5 VDC (high limit) 12.1–16.5 VDC (high limit) Safe non-operating voltage range 0–24 VDC...
  • Page 55 Specifications NOTE: These are charger specifications. AC Input All models Operating voltage range 90–140 VAC Safe non-operating voltage range up to 240 VAC Full load maximum current 16 Arms Nominal frequency 60 Hz DC Output All models Nominal voltage 12.0 VDC Min battery voltage for charging 0.0 VDC Max output voltage...
