TV8IB6-8VF650LP
License Plate Bullet Camera
FEATURES
•
HD TVI - 1920 x 1080 @ 30fps
•
1/2.8" Sony CMOS, 1.3 Megapixel
•
6.0~50mm Auto Iris Lens
•
6 High Power IR LED; IR distance 250ft / 80m
•
0.02 Lux (F1.2 , AGC ON) / 0 Lux IR on
•
Dual Power 12V DC / 24V AC
12V DC: 8.64W / 720mA
24V AC: 7W / 490mA
•
IP67 Rating
Please read Manual before attempting to use this product.
Specifications and appearance are subject to change without notice.
Copyright © 2015. All Rights Reserved.
HD TVI 1080P ICR OSD
USER MANUAL
TVI-23
R201503-V02
Advertisement
Table of Contents
Related Manuals for Okina TV8IB6-8VF650LP
Summary of Contents for Okina TV8IB6-8VF650LP
-
Page 1: User Manual
TV8IB6-8VF650LP HD TVI 1080P ICR OSD License Plate Bullet Camera USER MANUAL FEATURES • HD TVI - 1920 x 1080 @ 30fps • 1/2.8" Sony CMOS, 1.3 Megapixel • 6.0~50mm Auto Iris Lens • 6 High Power IR LED; IR distance 250ft / 80m •... -
Page 2: Limited Warranty
When the video product exhibits a distinct change in performance. LIMITED WARRANTY OKINA USA products are covered under warranty for one (1) year from the date of purchase. The warranty will automatically be voided if any of the following occurs: 1. -
Page 3: Package Contents
PACKAGE CONTENTS One (1) HD TVI IR License Plate Bullet Camera Four (4) Wall Mounting Screws Four (4) Wall Anchors One (1) Rubber Washer One (1) Sticker Mounting Template One (1) User Manual * For any returns, please include all components listed above with original packaging in Resalable Condition. Absolutely No Returns will be accepted if any component is missing/damaged. - Page 4 FUNCTIONS The camera includes auto white balance mode (AWB) auto capture and color temperature. The range is 2400°K~9600°K. SENSOR：Auto Cell Device Sensor, the IR LED would on when night comes to make up lightness. IR LED would not on in the day, to reduce power consumption. VIDEO, POWER AND DATA OUTPUT JACK F(BNC) JACK is for video output.
- Page 5 Remove the focus/zoom knob cover to access adjustment knobs. ↲ MAIN MENU 1. LENS 2. EXPOSURE 3. BACKLIGHT ↲ 4. WHITE BAL ↲ 5. DAY&NIGHT COLOR ↲ 6. NR ↲ 7. SPECIAL ↲ 8. ADJUST 9. RESET 10. EXIT LENS Default LENS MANUAL...
- Page 6 D-WDR OFF / ON (OFF) DEFOG OFF (Default) POS / SIZE SIZE,RET,AGAIN GRADATION OFF / LOW / MIDDLE / HIGH (LOW) DEFAULT RETURN RET / END RETURN RET / END SHUTTER AES (auto electronic shutter) - the camera automatically sets the optimum shutter speed. FL - flicker less mode avoids interference from light sources (recommended for video-iris or DC-iris lenses only).
- Page 7 WHITE BAL WHITE BAL ATW (Default) AWC --> SET INDOOR OUTDOOR MANUAL BLUE 0~100 (47) 0~100 (44) RETURN RET / END DAY&NIGHT DAY&NIGHT EXT (Default) AUTO DELAY 0~60 (5) D-N (AGC) 0~100 (60) N-D (AGC) 0~100 (30) RETURN RET / END COLOR BURST ON,OFF (OFF)
- Page 8 x4.0 ~ x62.0 (x2.0) D-ZOOM ←, ↑, →, ↓ PAN & TILT DEFAULT RETURN RET / END SMART OFF (default) D-ZOOM SELECT AREA1, AREA2 DISPLAY ON (default) POSITION ←, ↑, →, ↓ SENSITIVITY 0~60 (30) D-ZOOM x1.0, x1.1, x1.2, x1.3, x1.4, x1.5, x1.6, x1.7, x1.8, x1.9, x2.0, x2.1, x2.2, x2.3, x2.4, x2.5, x2.6, x2.7, x2.8, x2.9, x3.0, x3.1, x3.2, x3.3,...
- Page 9 ADJUST ADJUST SHARPNESS SHARPNESS 0~15 (10) MONITOR LCD (default) GAMMA USER+Y,0.45,0.50,0.55,0.60,0.65,0.70 ,0.75,0.80,0.85.0.90,0.95,1.00,AUTO, USER (USER+Y) ADAPT LEVEL 0~100 (50) BLUE GAIN 0~100 (55) RED GAIN 0~100 (55) RETURN RET / END BALCK LEVEL -30~0~+30 (+0) BLUE GAIN -50~0~+50 (+0) RED GAIN -50~0~+50 (+0) RETURN RET / END...
-
Page 10: Recommended Camera Keyboard Controller
2. Focusing and Shutter Speed Focusing is the most important thing. It is recommended that the focusing should be done on the license plate of a parked vehicle. It will take time to focus. An example of shutter speed is shown below: Before After ※... - Page 11 Enter LENS then Under MAIN MENU, configure the BRIGHTNESS value until you can see the License Plate. After BRIGHTNESS configuration please have vehicle drive by to see Front and Rear License Plate, it may have an little blurring when vehicle is moving, please adjust Automatic gain control (AGC) value when during the vehicle driving.
-
Page 12: Specifications
SPECIFICATIONS Model TV8IB6-8VF650LP Image Sensor 1/2.8” Sony CMOS : 1.3 Megapixel Resolution 1920(H) x 1080(V) @ 25/30 FPS Synchronizing System Internal Scanning System 2:1 Interlace Video Output HD TVI Electronic Shutter Auto 1/60 (1/50) ~ 1/50,000 sec / Flk Minimum Illumination 0.02Lux (F1.2 , AGC ON)
