- Page 1 KOBE Range Hoods Brillia Series Model No. ISX2136SQB-1 (36”) ISX2142SQB-1 (42”) INSTALLATION INSTRUCTIONS AND OPERATION MANUAL...
- Page 2 1. DO NOT INSTALL THE UNIT AND KEEP ALL ORIGINAL PACKAGING MATERIAL. 2. Have your original invoice as proof of purchase and product serial number ready. 3. Call 1-877-BUY-KOBE (289-5623); or e-mail to info@koberangehoods.com to report the problem. NO RETURN, NO REFUND, NO EXCHANGE IF: 1.
-
Page 3: Table Of Contents
- READ AND SAVE THESE INSTRUCTIONS - CONTENTS IMPORTANT SAFETY INSTRUCTIONS ..............3 COMPONENTS OF PACKAGE ................5 INSTALLATION ......................6 OPERATION INSTRUCTIONS ................10 MAINTENANCE ..................... 11 SPECIFICATIONS ....................12 MEASUREMENTS & DIAGRAMS ................13 PARTS LIST ......................14 TROUBLE SHOOTING .................. -
Page 4: Important Safety Instructions
KOBE RANGE HOODS authorized agents will automatically void the warranty. - KOBE RANGE HOODS will not be held responsible for any damages to personal property or real estate or any bodily injuries whether caused directly or indirectly by the range hood. - Page 5 What to Do In The Event Of a Range Top Grease Fire • SMOTHER FLAMES with a tight fitting lid, cookie sheet, or metal tray, and then turn off the burner. KEEP FLAMMABLE OR COMBUSTIBLE MATERIAL AWAY FROM FLAMES. If the flames do not go out immediately, EVACUATE THE AREA AND CALL THE FIRE DEPARTMENT or 911.
-
Page 6: Components Of Package
{G} Screws Package {C} Baffle Filters – 3 {D} Instruction Manual (WEBSITE) 4 x 8mm (14PCS) For the operation manual, please refer to our website: KOBERangehoods.com www.KOBERangeHoods.com - FOR MORE INFORMATION, PLEASE VISIT OUR WEBSITE CONTACT KOBE RANGE HOODS AT (626) 775-8880. -
Page 7: Installation
INSTALLATION PLEASE READ ENTIRE INSTRUCTIONS BEFORE PROCEEDING Calculation before Installation To calculate installation, please refer to TABLE 1. (All calculation in inches.) TABLE 1 A = Height of Floor to Ceiling B = Height of Floor to Counter Top (Standard: 36”) C = Preferred Height of Counter Top to Hood Bottom (Recommended 30”... - Page 8 Preparation before Installation Figure 1 NOTE: TO AVOID DAMAGE TO YOUR HOOD, PREVENT DEBRIS FROM ENTERING THE VENT OPENING. • Decide the location of the venting pipe from the hood to the outside (Figure 1). • A straight, short vent run will allow the hood to perform more efficiently.
- Page 9 Figure 4 Telescopic Stack Installation 6. Adjust the telescopic stack with the screws provided to the desired height. Refer to Table 1 and Figure 4. (Lower screws must be drilled into the metal motor housing). 7. Place only the inner duct cover over the top of the telescopic stack prior to mounting to the ceiling and let it rest on the bottom flanges.
- Page 10 Figure 6 Hood Installation 15. Align the hood with the telescopic stack so that the motor harness is on the same side as the control unit harness. Refer to Figure 6. 16. Fasten the hood body to the telescopic stack using 8 screws (provided).
-
Page 11: Operation Instructions
OPERATION INSTRUCTIONS Note: For best results, turn fan on prior to any preparation or cooking and keep fans running while cooking. Adjust speed as needed. To operate the fan function • Press button to choose from speed. Q = QuietMode speed L = Low speed H = High speed... -
Page 12: Maintenance
MAINTENANCE For optimal performance, clean the range hood surface and baffles regularly. To Clean Hood Surface CAUTION: NEVER USE ABRASIVE CLEANERS, PADS, OR CLOTHS. *** Regular care will help preserve its fine appearance. 1. Use only mild soap or detergent solutions. Dry surfaces using soft cloth. 2. -
Page 13: Specifications
Top – 6" Round CONTROLS Mechanical Push Button HOOD DIMENSION (ISX2136SQB-1) - 35-3/4" x 23-11/16" x 2-3/8" (W x D x H) (ISX2142SQB-1) - 41-3/4" x 23-11/16" x 2-3/8" Duct Cover Two-Piece Adjustable Duct Cover (W x D x H) 11-3/16”... -
Page 14: Measurements & Diagrams
MEASUREMENTS & DIAGRAMS ***All measurements in ( ) are millimeters. ***All inch measurements are converted from millimeters. Inch measurements are estimated. FRONT OF HOOD... -
Page 15: Parts List
PARTS LIST MODEL NO.: ISX2136SQB-1 (36”) ISX2142SQB-1 (42”) BOX 1of 2 DESCRIPTION MODEL /SIZE PART NO. 6” Round Plastic Exhaust L1-0505-0002 L1-0403-0301 LED Light (3W) Control Unit L1-0405-0301 LED Light Driver L1-0402-D001 L1-0401-0120-24 Capacitor (24uf/250V) Light Panel L1-0201-2136 Baffle Filter... - Page 17 PARTS LIST MODEL NO.: ISX2136SQB-1 (36”) ISX2142SQB-1 (42”)
-
Page 18: Trouble Shooting
TROUBLE SHOOTING Issue Possible Cause Solution The power is not on. After Make sure the circuit breaker and the unit's Installation, power is ON. Use a voltage meter to check the both motors power supply. and lights are The wire connection is not secure. Check and tighten wire connection. -
Page 19: Warranty
WARRANTY WARRANTY CERTIFICATE KOBE Range Hoods (referred to herein as “we” or “us”) warrants to the original purchaser (referred to herein as “you” or “your”) all products manufactured or supplied by us to be free from defect in workmanship and materials as follows:... - Page 20 3. Have the model number 4. Have the serial number 5. Have a description of the nature of any defect in the product or part TO REQUEST WARRANTY SERVICE, PLEASE CONTACT THE KOBE RANGE HOODS SERVICE CENTER: KOBE SERVICE CENTER (USA ONLY)
-
Page 21: Warranty Information Form
1. Date of purchase 2. Model No. 3. Serial No. For warranty service or spare parts purchase contact: KOBE Service Center (USA ONLY) Toll Free: 1-855-800-KOBE (5623) Email: kobe@adcoservice.com For service in Canada and to report a problem, please contact:... - Page 22 Arcadia, CA 91006 USA www.KOBERangeHoods.com This KOBE hood is made for use in the USA and CANADA only. We do not recommend using this hood overseas as the power supply may not be compatible and may violate the electrical code of that country. Using a KOBE hood overseas is at your own risk and will void your warranty.
