Caraudio-Systems c.LOGiC C1-RNSE Manual

For navigation systems audi navi plus rns-e
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
c.LOGiC-Interface
C1-RNSE
For navigation systems
Audi Navi Plus RNS-E
Only for vehicles WITHOUT factory rear-view camera
Product features
• full plug and play multimedia interface
• 1 AV-input with separate IR-control channel
• control of after-market devices, e.g. DVB-T tuner, DVD-player, DVD-changer, ...
• after-market rear-view camera input
• automatic switching to rear-view camera input (optional coding necessary to switch from
OEM-modes)
• rear-view camera power (+12V max. 1A)
• rear-seat-entertainment AV-output
• power on remote out trigger signal (+12V ma.x 1A) to switch on connected devices
Version 24.02.2012
C1-RNSE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the c.LOGiC C1-RNSE and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Caraudio-Systems c.LOGiC C1-RNSE

Summary of Contents for Caraudio-Systems c.LOGiC C1-RNSE

  • Page 1 c.LOGiC-Interface C1-RNSE For navigation systems Audi Navi Plus RNS-E Only for vehicles WITHOUT factory rear-view camera Product features • full plug and play multimedia interface • 1 AV-input with separate IR-control channel • control of after-market devices, e.g. DVB-T tuner, DVD-player, DVD-changer, … •...

  • Page 2: Table Of Contents

    Contents 1. Prior to Installation 1.1. Delivery contents 1.2. Check compatibility of vehicle and accessories 2. Connection schema 3. Installation 3.1. Interconnecting Interface-box and harness 3.2. Connections to head-unit 3.3. Connecting peripheral devices 3.3.1. AV-source 3.3.2. Installing AV-source’s IR-sensor additionally 3.3.3.

  • Page 3: Prior To Installation

    Legal Information By law, watching moving pictures while driving is prohibited, the driver must not be distracted. We do not accept any liability for material damage or personal injury resulting, directly or indirectly, from installation or operation of this product. This product should only be used while standing or to display fixed menus or rear-view-camera video when the vehicle is moving, for example the MP3 menu for DVD upgrades.

  • Page 4: Check Compatibility Of Vehicle And Accessories

    1.2. Check compatibility of vehicle and accessories Requirements Vehicle Audi A3 (8L, 8P & 8P Sport), A4 (Cabrio 8H/B7/8E, B6/8E), A6 (4B), TT (8J), Lamborghini Navigation Audi Navi Plus RNS-E all-in-one navigation 16:9 Limitations Factory-TV-tuner Must NOT be installed. After-market rear-view Only compatible with NTSC-cameras.

  • Page 5: Installation

    3. Installation Switch off ignition and disconnect the vehicle’s battery! If according to factory rules disconnecting the battery has to be avoided, it is usually sufficient to put the vehicle in sleep-mode. In case the sleep-mode does not show success, disconnect the battery with a resistor lead.

  • Page 6: Connecting Peripheral Devices

    3.3. Connecting peripheral devices It is possible to connect one after-market AV-source and an after-market rear-view camera to the c.LOGiC Interface. Before final installation of the peripheral devices, we recommend to test-run the c.LOGiC functions to detect incompatibility of vehicle, navigation, factory accessories or peripheral devices as soon as possible.

  • Page 7: Installing Av-Source's Ir-Sensor Additionally

    3.3.2. Installing AV-source’s IR-sensor additionally Additionally to the control via OEM navigation, it is possible to install the original IR-sensor of a connected device. By using the respective Y-adapter (e.g. STA-Y35MM or STA-RJ12) for the IR-Port of the connected device, the controls of navigation AND device’s IR-sensor can be connected and used simultaneously.

  • Page 8: Operation

    4. Operation 4.1. Selecting the c.LOGiC as current AV-source Push the CD/TV button of the head-unit to choose the c.LOGiC as current AV-source. 4.2. Assigning device control After selecting the c.LOGiC as current AV source, longpress key SETUP. The FIS will display “TV 1”...

  • Page 9: Picture Settings

    Button assignment table c.LOGiC Audi Navi Plus RNS-E Head- DVB-T USB-LiNK DVD-player DVD- iPod®-control Analog-tuner unit changer button CH - TRACK - TRACK - TRACK - TRACK - CH - 1 long POWER SHUFFLE CH + TRACK + TRACK + TRACK + TRACK + CH +...

  • Page 10: Specifications

    Power consumption Temperature range -30°C to +80°C Weight Measurements (box only) B x H x T 106 x 30 x 71 mm 6. Technical Support Caraudio-Systems Vertriebs GmbH NavLinkz GmbH manufacturer/distribution corporate sales/tech dealer-support Rheinhorststr. 22 Eurotec-Ring 45 D-67071 Ludwigshafen am Rhein...
