Source Audio soundblox 2 User Manual page 9

Press button to
select option
• DELAY/FREQUENCY (Green LED):
effects are selected the DELAY knob adjusts the delay time
between the dry and modulating signals. Because of the
similarity between flangers and choruses, a flanger can easily
be adjusted to resemble a chorus and vice-versa. As a rule of
thumb, short delay times create flange effects while long delays
produce chorus effects. Set the DELAY knob between 7 and
11 o'clock for flange effects and between 3 and 5 o'clock for
chorus.
When phaser effects are selected, this knob adjusts the
frequency center point of the phase modulation. Turn the
FREQUENCY knob clock-wise to modulate the phaser over
higher frequencies and give the effect a brighter sound.
• FEEDBACK (Red LED):
of wet signal fed back into the effect. Much like the harmonic
feedback created between a guitar pick-up and an amplifier,
increasing the FEEDBACK on the Orbital Modulator creates
a more resonant and ringing response, giving the effect more
prominence.
-
Continued
OPTION
SELECT
(HOLD)
DEFAULT
When Flanger or Chorus
The FEEDBACK knob controls the amount
DELAY/FREQ
FEEDBACK
VOLUME
TREMOLO
MIX
Controls: Knobs | 9
