EXTERNAL CONTROL

One of the Core Features of the Soundblox 2 line of effects is the MULTI-
FUNCTION Input (A). The MULTI-FUNCTION input is an intelligent control
input that accepts both digital and analog control signals. It replaces the
SENSOR input on previous Soundblox pedals. The MULTI-FUNCTION
input connects to wired or wireless Hot Hand accessories, the Source
Audio Expression Pedal, or a future Source Audio MIDI interface that will
enable full MIDI I/O access to the pedal.
A
GUITAR IN GUITAR OUT
MULTI- MULTI-
FUNCTION FUNCTION
9V DC
IN OUT
20 | External Control
