Source Audio Hot Hand SA116 User Manual

Wireless midi controller
Hide thumbs
1
2
3
4
5
6
7
8
9

Advertisement

Table of Contents

User's Guide
CHARGE.
CONNECT.
CONTROL.
CUSTOMIZE.
Welcome
Thank you for purchasing a Hot Hand USB Wireless MIDI Controller. Hot Hand USB is the
latest innovation in music motion control from Source Audio. Hot Hand USB consists of a
small wireless 3-axis motion and tilt-sensing Ring and a USB Receiver. The Receiver
installs without drivers and appears as a MIDI device to your Windows or Mac PC. The
MIDI output from the Receiver can be assigned to control an infinite number of
parameters in your DAW (digital audio workstation) or live performance audio software
to help you bring dynamic motion control to your music.
Demo Projects
As a starting point, we have created sample projects and songs for a variety of software
packages using Hot Hand to control various parameters. The project files can be
downloaded from the Hot Hand USB product page:
http://www.sourceaudio.net/products/hothand/hothand_usb.php
Getting
Started
Charging
To get started using Hot Hand, first you need to charge your
Hot Hand Ring. The Ring can be charged by connecting the
included AC adapter power supply to the charging jack on
the back of the Ring. The Ring features a fast-charging and
high performance Li-ion battery. When the charger is
connected, the blue LED on the Ring will blink quickly.
When the charge is complete, the LED will turn off.
Charging time is around 1.5 hours. On a full charge, the
Ring can be used for around 6 hours.
SA116
Status LED
Charging Port

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Hot Hand SA116 and is the answer not in the manual?

Questions and answers

Related Manuals for Source Audio Hot Hand SA116

Summary of Contents for Source Audio Hot Hand SA116

  • Page 1 Thank you for purchasing a Hot Hand USB Wireless MIDI Controller. Hot Hand USB is the latest innovation in music motion control from Source Audio. Hot Hand USB consists of a small wireless 3-axis motion and tilt-sensing Ring and a USB Receiver. The Receiver installs without drivers and appears as a MIDI device to your Windows or Mac PC.
  • Page 2 Connections and Wireless Linking Connect the Hot Hand USB Receiver to any open USB port on your Windows or Mac PC. Drivers will install automatically. The Hot Hand USB uses built-in drivers on your computer for MIDI and requires no custom driver installation. Once the Receiver is installed on your computer, the blue status LED on the Receiver will begin to blink slowly.
  • Page 3 To understand the basics of Hot Hand motion control, it’s helpful to know how to move or position the Ring to get the most reliable signal output. The following photos illustrate the direction of motion and hand positions for each sensor axis of the Hot Hand Ring: Motion map: X motion Y motion...
  • Page 4 Controlling continued… The motion data from the Ring is sent to the Receiver where it is processed and converted into MIDI signals. MIDI is a very common means of sending control information from audio hardware to audio software or vice versa. MIDI is even used for a number of non-music purposes since it is very simple to use and implement.
  • Page 5 When you first start the software editor it will connect automatically to the USB Receiver and load a 3-axis basic preset that matches the default configuration which was preloaded on the USB Receiver. You can use the application to edit, save, load, and burn presets to the USB Receiver.
  • Page 6 The MIDI modules take the output from the Solo Output processor modules and converts it into a Output ON/OFF MIDI message. The MIDI modules can also be used to edit MIDI parameters, limit values or set up trigger events based on the input signal.

  • Page 7: Additional Software Features

    Software Additional Features Toolbar Controls: Reload – refreshes the current settings from the Editor to the USB Receiver. This function will NOT burn settings to the flash memory. Monitor ON/OFF – Enables or disables the monitor graph for each module. The graphical updates require a small amount of CPU cycles so you might want to turn them off in some cases.
  • Page 8 Advanced Features - MIDI Control In addition to creating MIDI output, the Hot Hand USB Receiver can also receive MIDI messages from the computer. These incoming MIDI messages can be used to automate settings for a performance by enabling or disabling any of the 10 MIDI output modules or by recalling an entirely different preset from the onboard flash memory.

  • Page 9: Specifications

    Source Audio. Source Audio reserves the right to update any unit returned for repair and to change or to improve the design of the product at any time without notice. Source Audio reserves the right to use reconditioned parts and assemblies as warranty replacements for authorized repairs.
