Kwikset Signature Series Installation And User Manual

68242-001
Rev 01
Z-Wave Plus
Signature Series Deadbolt
with Home Connect
Installation and User Guide
Required tools
Ruler Phillips head screwdriver
Additional Tools (depending on application)
Hammer Wood block
1

Prepare the door and check dimensions

If drilling a new door, use the supplied template and the complete
door drilling instructions available at www.kwikset.com/doorprep.
A Measure to confirm that the hole in
the door is either 2-1/8" (54 mm) or
1-1/2" (38 mm).
2-1/8"
54 mm
or
1-1/2"
38 mm
Note: Additional door preparation may be
required for doors with 1-1/2" (38 mm) holes.
Consult the deadbolt drilling instructions at
www.kwikset.com/doorprep.
2

Install the latch and strike

A
Is the door edge chiseled?
YES
or
chiseled
Use latch "A". If the
latch bolt is not already
extended, extend the
latch bolt as shown.
A
Kwikset
1-866-863-6584
www.kwikset.com
B Measure to confirm that the backset is
either 2-3/8" or 2-3/4" (60 or 70 mm).
b a
2-3/8" or 2-3/4"
60 or 70 mm
B
Hold the latch in front of the door hole, with the latch
face flush against the door edge.
NO
not
chiseled
Use latch "B" (not
included). If the latch
bolt is not already
extended, extend the
latch bolt as shown.
B
C
Are the latch holes centered in the door hole?
No adjustment is required.
Proceed to next step.
Parts in the box
Latch
A
B
"B" is not included. If needed,
please contact Kwikset to order
a drive-in latch for your lock.
Mounting Batteries
Plate
C
Y
Strike Cylinder
D E
C
Measure to confirm that the hole in
the door edge is 1" (25 mm).
c k
s e
t
actual
size
R
S
A
B
YES NO
or
Rotate latch face as
shown to extend latch.
A
B
1 / 4
Interior Assembly Exterior Assembly
Traditional Contemporary Traditional
L
M
F F
Fasteners
G G
R
H H
S
V
Keys SmartKey
tool
J
K
D Measure to confirm that the door is
between 1-3/8" and 1-3/4"* (35 mm
and 44 mm*) thick.
1"
25 mm
*Service kits for 2-1/4" (57 mm) thick doors
are available through Kwikset.
T
U
D
Which latch are you installing?
Latch "A"
or
A
R or S
(2x)
E
Install strike on the door frame.
Make sure the hole in the door frame is drilled a
minimum of 1" (25 mm) deep.
Longer screws
install closest to
the door jamb.
U (2x)
T (2x)
Contemporary
P
N
Q
T
U
X
W
1-3/8" – 1-3/4"*
35 – 44 mm*
Latch "B"
B
wood
block
D
door frame
