Summary of Contents for elmeg C300
- Page 1 Short reference elmeg C300 - CS300...
-
Page 2: Table Of Contents
Table of contents Description ..... . . 1 Safety instructions ......1 Contents of package . -
Page 3: Description
PABX to determine whether these typical system performance features are provided with the various elmeg telephones. The typical system performance features described in these operating instructions apply only to the elmeg CS 300 ISDN telephone, and not to the elmeg C300 ISDN telephone. Safety instructions Unauthorized opening of the system telephone and improper repairs may •... -
Page 4: Contents Of Package
• tors or in rooms with excessive humidity. The ambient temperature must not be lower than 5° or above 40°C. Contents of package ISDN system telephone elmeg C300 or • ISDN system telephone elmeg CS300 handset with handset connecting cord •... -
Page 5: User Interface Of Your Telephone
User interface of your telephone 01.04.00\10:34\\\\\\\\\} tbook quiet PQRS WXYZ 1 Speaker 10 Escape 2 Label panel for VIP keys and 11 Acknowledgement function keys 12 Arrow buttons »left« / »right« 3 7 direct dialing/ function keys 13 Open listening/ hands-free with LED 14 Disconnect 4 Shift button with LED... -
Page 6: Display, Buttons, Leds, Pictographs And Signals
Display, Buttons, LEDs, Pictographs and signals 1.6.1 Display Date Time 24 chars 1st line 01.04.00\10:34\\\\\\\\\} 2nd line tbook\ vip \\quiet S S S S Text assignment to softkey 4 softkeys Arrow: further menu items accessible with arrow buttons Fig. 2: Display of your telephone After you connect the system to the ISDN connection, ˆ01.04.00 10:34 the date and time are shown on the top line of the dis-... - Page 7 Escape button: Pressing the Esc button ˆ Functions during programming returns the tele- ˆaudib adjust prog config phone to its idle status. OK key: Pressing this button stores a setting in the telephone. You then hear the acknowledgement signal. C-button: Press this button to move back one menu step in the menu. If you are currently in the input mode, this button can be used to delete individual characters.
- Page 8 Now enter the new letters for the new ˆChange tbook data input name (in the example the surname ˆname>TINA PETERS_ » «). PETERS 1.6.3 Entering figures and numbers The following buttons are configured for the entry of figures and numbers (e.g. telephone directory, vip memory): Button 1.press...
- Page 9 1.6.4 Pictographs The pictographs (symbols) described in the following have been used in these operating instructions to illustrate some procedures for setting and using the telephone. Lift up the handset, activate hands free calling, or start initializing selec- tion. Hang up the handset and end hands free calling. The telephone is idle.
-
Page 10: Installation Of The Telephone
Installation of the telephone Connection of the handset connecting cord Connect the handset cord as shown in Figure 3. Lay the handset cord in the cord groove and lock it below the two cord retainers. ISDN telephone seen from the bottom Handset Jack for connecting the handset... -
Page 11: Connection Of The Telephone To The Pc
Connection of the telephone to the PC Connect the cable RS232(V.24) as shown in figure 5. Plug the RJ12 connector into the RJ12 jack on the back of the telephone and the 9-pin D-SUB connector onto the corre- sponding connecting jack of your PC. Only use the RS232(V.24) cable delivered with the system, as this is not a standard serial cable. -
Page 12: Settings
PABX manual. You can define and set a name, a specific melody and its volume for each MSN that you enter. If, for example, you assign the name »elmeg« to a number, » « will appear in elmeg the display instead of »... -
Page 13: Volume Settings (Cd-Rom)
3.1.2 Other settings for each MSN (extension number) Begin as follows: config msn-1 You can now make other settings for the ˆ MSN-1 program selected MSN. ˆtnumb sound volume x-fer » « Setting the call signaling melody sound » « Setting the volume of the call signaling melody. -
Page 14: Call Forwarding (Call Rerouting)
Call forwarding (call rerouting) With this telephone you can be reached, even if you are not in the vicinity of your phone. This is made possible by automatic forwarding of calls to any other number. Call rerouting can be configured separately for any of the entered numbers (MSNs). You must have configured at least one number in order to utilize the call rerouting function. -
Page 15: Call Waiting
Call forwarding has been configured. You ˆMSN-1 see this display for about 10 seconds. ˆ Direct call forwarding! ˆ call forwarding ˆ off delayed busy fixed 3.3.2 Deactivating call forwarding Begin as follows: adjust forward msn1 Call waiting If, during an ongoing call, a second call comes in for you, the second call is signaled when “Call waiting on”... -
Page 16: Other Settings (Cd-Rom)
TELEDATA-UPDATE Gesellschaft für Telefon-Tarifdaten-Management mbH using a dial-in number preset in your telephone. ELMEG GmbH & Kommunikationstechnik cannot warrant that this tariff data is up-to-date, complete and correct and declines any liability resulting from the use of such... -
Page 17: Programming The Phone Directory
Begin as follows: prog tbook Enter the name. ˆ Input telephone book In this example: » «. ELMEG HOTLINE ˆname>ELMEG HOTLINE Confirm your entry by pressing OK. Enter the telephone number. ˆ Input telephone book In this example: » «. - Page 18 ˆname>ELM_ Confirm your entry by pressing ok. Delete the existing characters by pressing ˆChange tbook data input the C button. ˆname>ELMEG HOTLINE Enter the new letters. ˆChange tbook data input In this example: » «. ˆname>ELMEG MARKETING ELMEG MARKETING Confirm your entry by pressing ok.
-
Page 19: Programming Vip Numbers
Programming VIP numbers You can program VIP numbers for each of the ten buttons including a name (20 characters max.) and a telephone number (26 digits max.). 3.7.1 Programming VIP entries The following example describes how to program a VIP entry for destination » «. -
Page 20: Programming Direct Dialing Numbers
Pressing the shift button is indicated by » « on the top line in the display. With the elmeg CS300 telephone you can also program other typical system functions for the direct dialing buttons in addition to the ones described here. 3.8.1 Programming dtmf or keypad sequences The following example describes how to program the direct dialing button 5. - Page 21 If you wish to change a programmed key, proceed as described for programming of the key. 3.8.2 Programming a function You can program the following function for the direct dialing keys of your phone: • MSN assignment (transmitting of a defined MSN to the party you are calling) •...
-
Page 22: Additional Information In The Display
24 buttons. You can program numbers, DTMF or keypad sequences (see Page 18) and functions) for these buttons. If you are using the elmeg CS300 with certain elmeg PABX systems, you can also pro- gram the typical system functions. -
Page 23: Settings At A Pabx (Cd-Rom)
• (elmeg CS300 only) If you are using your telephone with certain elmeg PABX systems you can program the existing direct dialing keys with functions that are typical for your system. With some elmeg PABX systems there is also a special menu available containing further... -
Page 24: Operation
Operation Starting a call 5.1.1 Dial number - no correction possible Dial number 5.1.2 Dial number - correction possible Dial number To change the number or to correct a wrong entry, select the wrong figure with the arrow buttons and press to delete it. - Page 25 Dialing from the telephone directory <> and / or Select tbook Enter first letter entry Dialing from the short dialing memory <> Select speed Select speed dialing number dialing number Dialing from the direct dialing memory Press the direct dialing key 5.1.4 Initiating a Initiating a call using a set number (MSN) You can conduct an internal or external call such that a defined number (MSN) is trans-...
-
Page 26: Accepting A Call
Accepting a call In its initial state the telephone will accept all calls, regardless of the service or the se- lected MSN. If two calls are signaled simultaneously the first one is accepted when you lift the handset. The second call is then no longer signaled or indicated in the display. The second caller will then hear the busy signal. -
Page 27: Redialing
Redialing The previously dialed telephone number is stored in the redial memory. If the connection between the ISDN system telephone and the ISDN network is in- terrupted, the redial memory is deleted. 5.4.1 Expanded redialing In the expanded redialing function the 20 previous calls, connections and dialed tele- phone numbers are stored. -
Page 28: Caller And Memo List
After around 10 seconds the hands-free calling function of your phone is activated and the number is dialed automatically. This is repeated for up to around 2 minutes. Up to 20 call attempts are made if the subscriber can still not be reached. If you hear the busy signal you can cancel automatic redialing by pressing the redial button. - Page 29 Caller list Calls that you do not accept, or that you specifically refuse, are stored in the caller list. Entries in the caller list are indicated by the flashing LED of the Shift button. A maximum of 20 calls are stored. Further calls will then overwrite the oldest entries. If a call is set up with a party in the caller list (You call them or they call you), that entry is de- leted automatically from the caller list and stored in the redial memory.
- Page 30 When you view the caller/memo list again, entries that you have already viewed but not deleted are no longer marked by » « in the bottom line of the display, but rather by » «. You can view other entries using the arrow ˆMemo yesterday 15:42 {} buttons.
-
Page 31: Call Waiting, Enquiry Call, Broker`s Call, Three-Party Conference, Call Transfer, Call-Back On Busy(Ccbs)
If you have configured connection and line keys (elmeg CS300 only) you can also carry out Broker’s calls between different callers using these keys. Additional information about the corresponding connections is displayed when you press the shift key and the softkeys below»... - Page 32 Three-party conference If you have an active connection and a connection on hold at your system telephone, you can initiate a conference call with these two parties. All three parties can speak to one another. Conference calls are not possible with more than two (2) connections at your phone. >...
-
Page 33: Other Functions (Cd-Rom)
Operator's Manual on the enclosed CD. Read out firmware version and other information via the telephone • Setting the telephone using the programs on the elmeg WIN-Tools CD: • Configuration Manager, Phone Directory Manager, Download Manager and LCR Manager Download of new firmware via the RS232(V.24) interface, or the ISDN... -
Page 34: Declaration Of Conformity
Declaration of conformity... -
Page 35: Index
Automatic redialing..25 deactivate ... 26 elmeg keyboard extension T300 programming..20 elmeg T300 Broker's call . - Page 36 Starting a call ... 22 placing ... . . 2 Telephone number (MSN) ..10 no number transmission (CLIR) .
-
Page 37: Brief Description Of Functions
Brief Description of Functions Enquiry call Dial number Broker`s call > conn1 Dial number conn4 Three-party conference call Dial number conf Call transfer with prior notice Dial number Dial number x-fer Parking > Enter parking park code Unparking > Enter par- unpark king code Malicious call identification... - Page 38 Expanded redialing <> Search num- Search number Automatic redialing Subscriber Dial number auto busy Deactivate automatic redialing auto Call-back on busy Dial number Number busy clbckbusy Selection of outgoing numbers (MSNs) msn1 Dial number msn10 Activate call forwarding delayed msn1 adjust forward busy...
-
Page 39: Warranty Declaration
5. It is at the discretion of elmeg to replace the device with an identical one instead of performing re- pairs. Further claims for damage are not permissible. Any data stored in the device will be lost after repair work or replacement of the device. - Page 40 This device meets the requirements stipulated by the EC guidelines: 1999/5/EG R & TTE The elmeg ISDN-telephone has therefore been given the CE mark. ELMEG GmbH & Co.KG Kommunikationstechnik Vöhrumer Str. 30 D-31228 Peine http://www.elmeg.com elmeg C300 - CS300...
