Clearance Chart - Jøtul F 100 Nordic Installation And Operating Instructions Manual

139678-R01 F 100 May, 2015
Jøtul F 100 Clearance Chart
All clearances established with included stove rear heat shield installed.
Stove
Clearances
Single-wall Connector
Single-wall Connector
with Connector Shields
or Double-wall Connector*
Chimney Connector
Vertical Installation
Single-wall Connector
Single-wall Connector
with Connector Shields
or Double-wall Connector*
Chimney Connector
Horizontal Installation
Single-wall Connector
Double-wall Connector*
* Double Wall Connector must be installed with Flue Collar Heat Shield Kit 154996.
12
Unprotected Surface
Installation
Side Rear
A B
15" 11"
381 mm 280 mm
E F
17" 8"
432 mm 203 mm
Unprotected Surface
11" (280 mm)
8" (203 mm)
Unprotected Surface
18" (457 mm)
Manufacturer's Listing
Figure 12
Mantel and Trim Clearances
Top and Side Trim is 1" thick or less
Maximum Mantel depth 12"
Protected Surface
per NFPA211 or CAN/CSA -B365-M93
Corner* Side
J C
10" 10"
254 mm 254 mm
L G
10" 10"
254 mm 254 mm
Protected Surface
per NFPA211 or CAN/CSA-B365-M93
6" (153 mm)
5" (127 mm)
Protected Surface
per NFPA211 or CAN/CSA-B365-M93
12" (305 mm)
Manufacturer's Listing
Unprotected Surfaces
A. Mantel 22" (560 mm)
B: Top Trim 17" (430 mm)
C: Side Trim 14" (355 mm)
Rear Corner*
D K
5" 7"
127 mm 178 mm
H M
5" 7"
127 mm 178 mm
Protected Surfaces
9" (230 mm)
8" (200 mm)
7" (430 mm)
