Specification - Danfoss RX1 Installation Instructions Manual

GB - Specifi cation
ENGLISH
Radio Controlled Room Thermostat Receiver Module for: see list page 3
Supply Voltage
Construction
Maximum Ambient Temperature
Switch Type
Switch Rating
IP Rating
Control Pollution Situation
Max. Range
Operating Frequency
Software Classifi cation
Rated Impulse Voltage
Ball Pressure Test

SPECIFICATION

230 Vac ± 15%, 50Hz
BS EN 60730-2-1, EN 300-220-1
45°C
RX1 - 1 x SPDT, type 1B
RX2 - 1 x SPDT, 1 x SPST, type 1B
RX3 - 1 x SPDT, 2 x SPST, type 1B
264 Vac, 3 (1) A (Total current)
IP 40
Degree 2
30 metres
433.92 MHz
Class A
2.5kV
75°C
GB
9
