Summary of Contents for Danfoss MP20 Series

  • Page 1 User Manual Remote Control MP20V Receiver www.danfoss.com...
  • Page 2 User Manual MP20V Receiver Revision history Table of revisions Date Changed January 2019 Rebranded to Danfoss Power Solutions 0101 © Danfoss | January 2019 BC292570533618en-000101...
  • Page 3: Table Of Contents

    Safety instructions General safety....................................4 Safety warnings....................................4 Technical description Dimensions......................................6 Hardware description..................................7 Installation Receiver installation..................................8 Input and output configuration..............................9 Digital outputs..................................... 9 Analog outputs..................................11 Pinout......................................12 Troubleshooting Receiver icon troubleshooting..............................13 © Danfoss | January 2019 BC292570533618en-000101 | 3...
  • Page 4: Safety Instructions

    • Avoid knocking or dropping the product. • Do not use the product if a failure is detected. Changes or modifications not approved by Danfoss can void the user's authority to operate this product. © Danfoss | January 2019 BC292570533618en-000101...
  • Page 5 User Manual MP20V Receiver Safety instructions Quick reference precautions © Danfoss | January 2019 BC292570533618en-000101 | 5...
  • Page 6: Technical Description

    User Manual MP20V Receiver Technical description MP20 dimensions Dimensions in mm R 2.60 248.91 82.37 R 2.60 R 2.60 R 2.60 81.55 216.00 232.00 © Danfoss | January 2019 BC292570533618en-000101...
  • Page 7: Hardware Description

    External antenna A60 (433) or A70 (870) External EEPROM LCD connection TR800-CE MCX radio CAN connection CAN power supply BUS termination CAN Signaling intern LEDs DEUTSCH connector pinout Switches to control voltage options © Danfoss | January 2019 BC292570533618en-000101 | 7...
  • Page 8: Installation

    4. Check if the electrical installation and verify if there's an option to connect the neutral or the ground cable. In that case, don't forget to connect the ground cable. The use of fireproof or flame retardant cables are recommended for the connection. © Danfoss | January 2019 BC292570533618en-000101...
  • Page 9: Input And Output Configuration

    45 (stop) for powering up this group of outputs. Maximum 2A per output. As an alternative, the K5-K12 output group can be connected directly to the external general power supply in order to provide a higher capacity of current. © Danfoss | January 2019 BC292570533618en-000101 | 9...
  • Page 10 User Manual MP20V Receiver Installation 10 | © Danfoss | January 2019 BC292570533618en-000101...
  • Page 11: Analog Outputs

    Maximum 20mA per output. The MP20V allows to choose the control voltage in order to set the output power with the selection of 2 switches. Control voltage options: 0-5V, 0-10V, 0-Vcc. © Danfoss | January 2019 BC292570533618en-000101 | 11...
  • Page 12: Pinout

    ABV; K1-4 K5-K12 Vdc8 Vdc7 Vdc6 Vdc5 Vdc4 Vdc3 Vdc2 Err8 Vdc1 Err7 Err6 +RRC Err5 +12/24V Err4 IN-3 Err3 IN-2 Err2 IN-1 Err1 GND-8 GND-7 GND-6 GND-5 GND-4 GND-3 GND-2 SA-8 GND-1 12 | © Danfoss | January 2019 BC292570533618en-000101...
  • Page 13: Troubleshooting

    In case of no signal, check if the transmitter is turned on Incorrect ID In case of interference, change frequency channel RF signal detected In case of interference, change frequency channel Mask error Contact your distributor © Danfoss | January 2019 BC292570533618en-000101 | 13...
  • Page 14 User Manual MP20V Receiver 14 | © Danfoss | January 2019 BC292570533618en-000101...
  • Page 15 User Manual MP20V Receiver © Danfoss | January 2019 BC292570533618en-000101 | 15...
  • Page 16 Phone: +86 21 3418 5200 Danfoss can accept no responsibility for possible errors in catalogues, brochures and other printed material. Danfoss reserves the right to alter its products without notice. This also applies to products already on order provided that such alterations can be made without subsequent changes being necessary in specifications already agreed.
