Danfoss RX1 Installation Instructions Manual page 6

RX2
Note: for mains voltage applications link terminals L and 2.
ELECTRONICS
A B C 1 2 3 4
N L
ATTENTION: If replacing a previous version of the RX2 receiver please
use the new backplate supplied and wire as illustrated above.
RX2C
ELECTRONICS
A B C 1 2 3 4 5 6
N L COM
ZONE 1
6
5 6
COM ZONE ZONE ZONE
1 ON 1 OFF 2 ON
COM ZONE 1 ZONE 1 ZONE 1 ZONE 2 ZONE 2
ZONE 2 ON ON OFF ON OFF
