Summary of Contents for Danfoss R13 B

  • Page 1 User Manual Remote Control R13 B Receiver www.danfoss.com...
  • Page 2 User Manual R13 B Receiver Revision history Table of revisions Date Changed January 2019 Rebranded to Danfoss Power Solutions 0101 © Danfoss | January 2019 BC292365780571en-000101...
  • Page 3: Table Of Contents

    User Manual R13 B Receiver Contents Safety instructions General safety....................................4 Safety warnings....................................4 Technical description Dimensions......................................6 Hardware description..................................7 Installation Receiver installation..................................8 Troubleshooting Receiver troubleshooting................................9 © Danfoss | January 2019 BC292365780571en-000101 | 3...
  • Page 4: Safety Instructions

    • Avoid knocking or dropping the product. • Do not use the product if a failure is detected. Changes or modifications not approved by Danfoss can void the user's authority to operate this product. © Danfoss | January 2019 BC292365780571en-000101...
  • Page 5 User Manual R13 B Receiver Safety instructions Quick reference precautions © Danfoss | January 2019 BC292365780571en-000101 | 5...
  • Page 6: Technical Description

    User Manual R13 B Receiver Technical description R13 x dimensions Dimensions in mm 232.00 84.87 216.00 R 2.60 R 2.60 R 2.60 R 2.60 R 2.60 R 2.60 R 2.60 R 2.60 81.55 60.69 219.73 37.50 248.93 Fixing slots (fixed assembly or anti-vibration) M32 cable gland ©...
  • Page 7: Hardware Description

    User Manual R13 B Receiver Technical description R13 B hardware Multiband antenna RS232/RS485 socket Power supply LR13 logic board Data logger connector INXX card socket External EEPROM Signal LEDs TR800-CE MCX radio Wiring connection © Danfoss | January 2019 BC292365780571en-000101 | 7...
  • Page 8: Installation

    User Manual R13 B Receiver Installation R13 B receiver installation The below information describes hazards to be aware of during installation and steps to locate the receiver. Risk of shock Completely shut down the machine when installing the receiver. Check the power supply and shut off the main switch to disconnect the interface cable between the receiver and the machine's electrical box.
  • Page 9: Troubleshooting

    No radio signal detected LED on + transmitter switched Radio channel occupied Change transmitter's frequency channel LED on + DATA switched off Radio channel occupied by non Danfoss system Change transmitter's frequency channel DATA LED off + SINGAL LED on Radio error Replace radio Green;...
  • Page 10 User Manual R13 B Receiver 10 | © Danfoss | January 2019 BC292365780571en-000101...
  • Page 11 User Manual R13 B Receiver © Danfoss | January 2019 BC292365780571en-000101 | 11...
  • Page 12 Phone: +86 21 3418 5200 Danfoss can accept no responsibility for possible errors in catalogues, brochures and other printed material. Danfoss reserves the right to alter its products without notice. This also applies to products already on order provided that such alterations can be made without subsequent changes being necessary in specifications already agreed.
