Specifications - Phanteks eclipse p400 User Manual

1. SPECIFICATIONS

CASE SPECIFICATIONS
Dimension
Form Factor
Material(s)
Motherboard support
Front I/O
Side window
EXPANSION & DRIVE BAYS
Expansion slots
Internal 3.5"
Internal 2.5" (dedicated)
COOLING (FANS)
Front
Top
Rear
210 mm x 465 mm x 470 mm (W x H x D)
8.3 in x 18.3 in x 18.5 in
Mid Tower
Steel chassis, steel exterior, ABS
ATX, Micro ATX, Mini ITX
E-ATX *(up to 272mm wide, unable to use
rubber grommets)
2x USB 3.0, Mic, Headphone, Reset,
LED Color Control, *3-Speed Fan
controller (*Eclipse P400S models only)
Yes, Eclipse P400 (PH-EC416P)
Yes, Eclipse P400S (PH-EC416PSW)
No, Eclipse P400S closed panel (PH-EC416PSC)
7
6 (2x included)
2 (2x included)
120 mm 140 mm
3x 2x
(1x included)
2x 2x
1x -
(1x included)
LIQUID COOLING
120 mm (Radiator)
Front Up to 360*
Top -
Rear
120
CLEARANCE
Graphic card
395 mm (15.2 in)
280 mm (11.0 in) Optional HDD brackets installed
CPU cooler
160 mm (6.3 in)
Cable Management 25 mm (1.0 in)
PSU (including cable) 270 mm (10.6 in)
Warranty 5 Years*
140 mm (Radiator)
Up to 280
-
-
* 360 radiator requires the removal of the midplate cover
5
