MHG Heating ProCon 16 Installation And Operating Manual page 52

#
H555
Setting flags
H558
Setting flags
Running time of actuator in heating circuit 2
H596
LPB device number of LMU
H605
(HM or Master Boiler 2 then Slave units 3...12)
LPB segment number of LMU
H606
H614
Program input LMU basis
Function programmable output K2 LMU
H615
H618
Progr input on clip-in function module
H619
Function output1 clip-in function module
H620
Function output2 clip-in function module
H621
Function output3 clip-in function module
Maximum value of heat demand with
H622
external predefined temperature setpoint
H630
Setting flags of maintenance alarms
H636
Months (interval) since last service visit
H700
1st Historical Fault – Number of Occurrences.
H701
1st Historical Fault – Operating Phase.
H702
1st Historical Fault – Operating Error Code
H703
2nd Historical Fault – Number of Occurrences.
