Level Two Engineer Parameters
#
H90
Reduced Temperature for DHW
DHW Production Control
H91
H93
DHW Production Control 0=Non Eco 1=Eco
DHW Secondary Pump Control
H94
(0= As H91. 1= As HWS Time Switch)
Minimum boiler setpoint temperature
H503
Maximum boiler setpoint temperature
H504
H505
Boiler setpoint at design outside temperature
Minimum flow setpoint temperature
H506
Maximum flow setpoint temperature
H507
Summer / winter changeover temperature
H516
(30 °C: S / W changeover deactivated)
H532
Heating curve slope heating circuit 1
H533
Heating curve slope heating circuit 2
Maximum speed at maximum output in heating
H536
mode
Maximum degree of modulation in heating
H541
mode
Minimum boiler output in kW
H542
Maximum boiler output in kW
H543
Overrun time of pumps, max. 210 min
H544
(setting 255: continuous operation of Q1)
Minimum burner pause time
H545
(heat demand-dependent switching hysteresis)
Constant for quick setback without room
H551
influence
H552
Hydraulic system adjustment
Setting flags: status code open-circuit sensor
554
for ANx channel suppressed / not suppressed
