Summary of Contents for Marey POWER TAK
-
Page 2: Table Of Contents
ELECTRICAL REQUIREMENTS Please carefully read all instructions and warnings. Should you have any WIRING DIAGRAM questions, please visit www.marey.com for installation videos and FAQ. INSTALLATION OPTIONS Please keep this manual for future reference and technical information. INTERNAL COMPONENTS... -
Page 3: Warning
If your water heater requires a reset, be sure to TURN OFF THE BREAKERS prior to resetting the unit. Resetting your unit without turning off the breakers can result in personal injury and damage to your water heater. WARNING! There is water contained in the coils of your water heater at all times. If your water heater is exposed to freezing temperatures, the water in the coils could freeze, causing a break in the heat exchanger of the unit, or the supply and return lines. - Page 4 The wire gauge necessary will vary based on amperage and distance to the breaker, Power Selector Minimum Breaker but 8 gauge wire is generally sufficient for most installations. If the distance is very Position 1 and 2 20 Amperes short, sometimes smaller gauge wire may be used. If you aren't sure which gauge of wire should be used, contact an electrician.
-
Page 5: Safety
DO NOT operate the appliance if water ceases to flow during use, if the outer case or cover is loose or if the unit is not working properly. If the unit leaks or does not heat properly, disconnect the unit. ISOLATE the electrical and water supplies before removing the cover and before proceeding with installation or servicing. - Page 6 PLUMBING 7. Use stainless steel flexible hose or copper tubing of ½" on the inlet and outlet pipes (right side water inlet, hot water outlet, left). WATER INLET RIGHT SIDE WATER OUTLET LEFT SIDE 2. The unit must be mounted on a flat surface in a vertical position with the incoming and outgoing water pipes facing down.
-
Page 7: Temperature Control
Hotter IIII (40A) Max. Hot Water Your Marey Power Pak Plus should give you trouble free operation, however should Temperature a problem or fault occur, the table below will assist in identifying the most common faults. Diagnosis and fault finding should be carried out by a qualified individual, skilled in electrical/plumbing. -
Page 8: Spare Parts
Do not replace the pressure relief device with any other screw. DO NOT REPLACE WITH PARTS NOT RECOMMENDED BY MAREY, AS THIS WILLINVALIDATE YOUR WARRANTY AND MAYRENDER THE INSTALLATION The unit is built of fireproof material. -
Page 9: Customer Service
Marey proudly manufactures water heaters and accessories for use in almost At Marey, we pride ourselves on the excellence of our customer service and support any application. Please visit our website to learn more about other Marey team. products. Please feel free to contact us if you have any questions about our products, warranty service, or if you need assistance installing a unit.
