Innovative Hearth Products
RETAIN THESE INSTRUCTIONS
FOR FUTURE REFERENCE
A French manual is available upon request. Order Form Number
850,035CF.
Ce manuel d'installation est disponible en francais, simplement en
faire la demande. Numéro de la pièce 850,035CF.
INSTALLATION AND OPERATING
INSTRUCTIONS
27" Electric Fireplace
506009-09
MODELS
MPE-27-2,ERT3027,Capella 27
This manual will enable you to obtain a safe, efficient and dependable
installation of your electric fireplace. Please read and understand these
instructions before beginning your installation.
Do not alter or modify the fireplace or its components under any
circumstances. Any modification or alteration of the fireplace system,
including but not limited to the fireplace and accessories, may void the
warranty, listings and approvals of this system and could result in an
unsafe and potentially dangerous installation.
INSTALLER: DO NOT DISCARD THIS MANUAL
DO NOT STORE OR USE GASOLINE OR OTHER FLAM-
MABLE VAPORS AND LIQUIDS IN THE VICINITY OF THIS
OR ANY OTHER APPLIANCE
ELECTRIC FIREPLACES ARE DESIGNED FOR USE AS
A DECORATIVE APPLIANCE AND/OR AS A SUPPLEMENTAL
HEATER. THEY ARE NOT INTENDED FOR CONTINUOUS USE
A PRIMARY HEAT SOURCE.
C
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
PLEASE LEAVE FOR THE HOMEOWNER
FOR YOUR SAFETY
®
CSA Report No. 46-M198
US
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MPE-27-2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for IHP MPE-27-2

Summary of Contents for IHP MPE-27-2

  • Page 1 Innovative Hearth Products 27" Electric Fireplace 506009-09 MODELS MPE-27-2,ERT3027,Capella 27 This manual will enable you to obtain a safe, efficient and dependable installation of your electric fireplace. Please read and understand these instructions before beginning your installation. Do not alter or modify the fireplace or its components under any circumstances.

  • Page 2: Table Of Contents

    CAUTION: Extreme caution is necessary when CONGRATULATIONS! any heater is used by or near children or electric fireplace, you have chosen the invalids and whenever the heater is left oper- In selecting this ating and unattended. finest and most dependable fireplace found anywhere. A beautiful and prestigious addition to the finest homes.

  • Page 3: Locating Fireplace

    NEVER LOCATE THIS APPLIANCE WHERE IT LOCATING YOUR MERIT PLUS ELECTRIC TOOLS AND BUILDING SUPPLIES COULD FALL INTO A BATHTUB OR OTHER NORMALLY REQUIRED FIREPLACE WATER CONTAINER. No tools are required for setup of the fireplace. Your new fireplace may be installed into existing DO NOT RUN ELECTRICAL WIRING OR POWER framing or built into a wall ( see Figure 1 ), or CORD (OPTIONAL) UNDER CARPETING.

  • Page 4: Framing Specifications

    FRAMING SPECIFICATIONS 22 ¹⁄₂" Electrical (572 mm) Junction 32" (833 mm) 25" (635 mm) Electrical 51 ¹⁄₄" 2 x 4 Junction (1302 mm) (On Right Side) 25" 31 ¹⁄₄" 31 ¹⁄₄" (635 mm) (794 mm) (794 mm) Corner View 4" (102 mm) 11"...

  • Page 5: Clearances

    Materials such as brick and tile can be extended TION, THE APPLIANCE MUST NOT down to the top of the fireplace. Do not extend Model: MPE-27-2,ERT3027,Capella 27 down, covering the outlet or glass enclosure Description: Merit Plus Electric Fireplace - 27”...

  • Page 6: Operating Instructions

    NEW CONSTRUCTION OR RENOVATION Flame Control 1. Select a location that is not prone to mois- Button ture and is located at least 3 feet (or 0.9m) ON/OFF Power away from combustible materials such as cur- Button tains or drapes, furniture, bedding, paper, etc. 2.

  • Page 7: Back Glass

    Catalog Number Weight Cabinet Surround Kit, Mantel process in the next section. - Painted White H3431 SK-27W MPE-27-2 27ELEC 78 lbs. - Honey Oak H3432 SK-27O 2. To remove fingerprints or other marks, the glass can be cleaned with a damp cloth using a good quality household glass cleaner.

  • Page 8: Troubleshooting Diagram

    TROUBLESHOOTING DIAGRAM SYMPTOM POSSIBLE WHO PERFORMS CORRECTIVE ACTION CAUSES CORRECTIVE ACTION 1. Fireplace turns off and The appliance is protected with a safety device to Fireplace has overheated. Homeowner will not turn on and an prevent it from overheating. If the fireplace should audible beeping noise overheat, a thermal switch will disconnect power can be heard.

  • Page 9: Replacement Parts

    REPLACEMENT PARTS Item MPE27-2,ERT3027,Capella 27 DESCRIPTION Catalog No. Qty. PCB LED H20 H9120 Circuit Board and Remote Control Sensor H3863 Glass Mirror H3864 Blower, Heating Element, and Access Panel Assembly H3865 Fuse Plate Assembly (5 each) H5043 Flame Cylinder Assembly LED 27 H9121 Flame Motor H3867...
  • Page 10 The manufacturer reserves the right to make changes at any time, without notice, in design, materials, specifications, prices and also to discontinue colors, styles and products. Consult your local distributor for fireplace code information. Innovative Hearth Products 1508 Elm Hill Pike Suite 108 Printed in U.S.A.
