BLACK DOG 42 XT GRILL & SMOKER
FOR SAFE OPERATION, PLEASE READ THIS ENTIRE
!
INSTRUCTION MANUAL BEFORE USE.
READ FIRST!
!
RULES FOR SAFE OPERATION
• THE BLACK DOG IS FOR OUTDOOR USE ONLY!
• KEEP THE BLACK DOG AWAY FROM BUILDINGS,
FLAMMABLE ITEMS AND VEHICLES.
• DO NOT USE THE BLACK DOG UNDER A COVER
OR AWNING.
• THE BLACK DOG IS FOR ADULT USE ONLY.
• KEEP CHILDREN AND PETS AWAY WHILE IT IS
BEING USED.
• MITTENS OR GLOVES WILL BE NEEDED TO OPEN
THE LID AND DOORS AS SURFACES WILL BE HOT.
• DO NOT MOVE THE BLACK DOG WHILE IT IS
BEING USED.
• KEEP THE CASTERS LOCKED DURING USE.
• DO NOT LEAVE UNATTENDED AT ANY TIME
WHILE IN USE.
• DO NOT USE IN WINDY CONDITIONS.
• NEVER USE KEROSENE, GASOLINE OR ANY
OTHER FUELS AS A STARTING AGENT.
• USE CAUTION WHEN OPENING THE LID, AS HOT
STEAM OR A FLARE UP COULD CAUSE BURNS.
• BEFORE EACH USE, MAKE SURE THE BLACK
DOG IS IN GOOD WORKING CONDITION.
• USE CAUTION AFTER THE FIRE HAS BEEN
EXTINGUISHED- SURFACES WILL REMAIN HOT
FOR SOME TIME.
• BE SURE ALL COALS ARE COLD BEFORE
EMPTYING. DISPOSE OF COALS PROPERLY.
!
FOOD SAFETY
• RAW POULTRY AND MEAT SHOULD BE KEPT
SEPARATE FROM READY TO EAT FOOD.
• USE CLEAN PLATTERS AND UTENSILS FOR
HANDLING COOKED FOODS.
• COOK POULTRY AND MEATS THOROUGHLY TO
KILL BACTERIA.
• USE INSTANT-READ THERMOMETER TO ENSURE
PROPER INTERNAL FOOD TEMPERATURES.
• KEEP PREPARED FOOD AND LEFTOVERS
REFRIGERATED.
• WASH HANDS, UTENSILS AND SURFACES WITH
SOAP AND HOT WATER PRIOR TO AND AFTER
HANDLING RAW POULTRY AND MEATS.
• FOR MORE INFORMATION CALL USDA MEAT AND
POULTRY HOTLINE: 1-800-535-4555 IN
WASHINGTON, DC.
™
MODEL 590135
ASSEMBLY AND OPERATING INSTRUCTIONS
SMOKER CHAMBER
MODEL 590135
Congratulations on your purchase of the Black Dog 42 XT Grill &
Smoker! At Landmann USA, our goal is to provide products that are
easy to assemble and fun to use. Should you have questions,
issues, a defective part or if you have any questions concerning its
use, please contact us at: grills@landmann-usa.com
-OR-
1-877-3GRILLS (1-877-347-4557) M-F 8-5 Eastern Time
Proof of purchase may be required.
Landmann USA
Cartersville, GA 30120
www.landmann-usa.com
Made in China
© 2009 Landmann USA
®
AND GRILL
Page 1
VER. 4, 10/1/09
OFFSET
FIREBOX
Advertisement
Related Manuals for Landmann BLACK DOG 42 XT
Summary of Contents for Landmann BLACK DOG 42 XT
- Page 1 REFRIGERATED. • WASH HANDS, UTENSILS AND SURFACES WITH Congratulations on your purchase of the Black Dog 42 XT Grill & SOAP AND HOT WATER PRIOR TO AND AFTER Smoker! At Landmann USA, our goal is to provide products that are HANDLING RAW POULTRY AND MEATS.
- Page 2 ® Page 2 BLACK DOG 42 XT GRILL & SMOKER ™ MODEL 590135 EXPLODED VIEW OF SMOKER CHAMBER PARTS NOTE: Some parts are not shown in PRE-ASSEMBLED VENT PLATE (ACTS AS A BLOCKING PLATE ONLY) scale for clarity. AC BL...
- Page 3 ® Page 3 BLACK DOG 42 XT GRILL & SMOKER ™ MODEL 590135 EXPLODED VIEW OF FIREBOX PARTS NOTE: Some parts are not shown in scale for clarity. CR CQ...
-
Page 4: Part Listing
® Page 4 BLACK DOG 42 XT GRILL & SMOKER ™ MODEL 590135 PART LISTING LIMITED WARRANTY PARTS Landmann USA (“Landmann”) warrants that this product shall be free of defects in material and SMOKER CHAMBER LID ............1 workmanship to the original purchaser for 90 days. - Page 5 ® Page 5 BLACK DOG 42 XT GRILL & SMOKER ™ MODEL 590135 HARDWARE FULL SIZE Parts are shown here at full-size. x 68 x 10 (2) 60MM (6) 40MM (68) 12MM (4) 12MM (10) 8MM (4) 8MM BOLT BOLT...
-
Page 6: Part Listings
® Page 6 BLACK DOG 42 XT GRILL & SMOKER ™ MODEL 590135 PART LISTINGS (1) SMOKER CHAMBER (1) WHEEL AXLE LEG (1) CASTER LEG (1) MAIN TOP FRAME (1) FRONT LEG (1) DOOR FRAME PANEL CONNECTOR (1) BACK LEG... - Page 7 ® Page 7 BLACK DOG 42 XT GRILL & SMOKER ™ MODEL 590135 PART LISTINGS (1) BOTTOM PANEL (1) CHARCOAL GRATE FRAME (2) LEFT LID HINGE (1) ASH TRAY (2) RIGHT LID HINGE (2) LEG CASTER (2) AIR VENT (1) FIREBOX DOOR...
- Page 8 ® Page 8 BLACK DOG 42 XT GRILL & SMOKER ™ MODEL 590135 PART LISTINGS (1) WHEEL AXLE (2) CHARCOAL GRATE 13.6" x 14.6" (1) ADJUSTMENT ROD (3) COOKING GRATE 14.6" x 16.5" (2) ADJUSTMENT WIRE AND COLLAR (1) FIREBOX...
- Page 9 ® Page 9 BLACK DOG 42 XT GRILL & SMOKER ™ MODEL 590135 PART LISTINGS (1) FIREBOX (1) FIREBOX LID INSIDE PANEL (1) FIREBOX TOP (1) FIREBOX DOOR FRAME (1) FIREBOX DOOR HEADER PANEL (1) FIREBOX FRONT PANEL (1) FIREBOX BOTTOM...
- Page 10 BLACK DOG 42 XT GRILL & SMOKER ™ MODEL 590135 ASSEMBLY INSTRUCTIONS The additional tools needed to assemble the Black Dog 42 XT are an adjustable wrench, Phillips screwdriver and a slotted screwdriver. PART F HAS A TOTAL OF 8 THREADED INSERTS...
- Page 11 ® Page 11 BLACK DOG 42 XT GRILL & SMOKER ™ MODEL 590135 ASSEMBLY INSTRUCTIONS STEP 4: ASSEMBLE DOOR FRAME PANEL Align the door frame panel [ G ] with the threaded inserts on the legs. Assemble the door frame panel [ G ] to the legs using (4) 12MM bolts [ AG ].
- Page 12 ® Page 12 BLACK DOG 42 XT GRILL & SMOKER ™ MODEL 590135 ASSEMBLY INSTRUCTIONS STEP 7: ASSEMBLE WHEEL AXLE, WHEELS & CASTERS Insert the wheel axle [ U ] into the holes in leg [ C ]. Slip the wheels [ T ] onto the wheel axle [ U ] as shown and assemble with (1) wheel axle locknut [ AD ] on each side.
- Page 13 ® Page 13 BLACK DOG 42 XT GRILL & SMOKER ™ MODEL 590135 ASSEMBLY INSTRUCTIONS STEP 9: ASSEMBLE FIREBOX INSIDE PANEL Place a piece of cardboard or foam on the ground. Carefully turn the grill assembly onto its side as shown.
- Page 14 ® Page 14 BLACK DOG 42 XT GRILL & SMOKER ™ MODEL 590135 ASSEMBLY INSTRUCTIONS STEP STEP STEP 12: ASSEMBLE FIREBOX TOP FRAME STEP 13: ASSEMBLE FIREBOX DOOR HEADER Assemble the firebox top frame [ CH ] to firebox Slide the firebox door header panel [ CG ] on panels [ CD, CE ] panels [ CD, CE, CJ ] using (9) 12MM bolts [ AG ].
- Page 15 ® Page 15 BLACK DOG 42 XT GRILL & SMOKER ™ MODEL 590135 ASSEMBLY INSTRUCTIONS PINS ASSEMBLED FIREBOX DOOR VENT TAB STEP 15: ASSEMBLE FIREBOX DOOR & FIREBOX VENT Assemble the firebox door [ CK ] into the firebox back panel [ CE ] tubes. Assemble in TUBES the position as shown for the easiest results.
- Page 16 ® Page 16 BLACK DOG 42 XT GRILL & SMOKER ™ MODEL 590135 ASSEMBLY INSTRUCTIONS STEP STEP 17: ASSEMBLE CHARCOAL GRATE ADJUSTMENT HANDLE & WIRE EYE HOOKS Pull the adjustment rod [ BF ] out to gain access and hold. Slide the charcoal grate adjustment handle rod [ BC ] onto the end and align it with the indention in the rod.
-
Page 17: Back Side
® Page 17 BLACK DOG 42 XT GRILL & SMOKER ™ MODEL 590135 ASSEMBLY INSTRUCTIONS STEP 19: ASSEMBLE LID HANDLES, VENTS & TEMPERATURE GAUGES Check temperature gauges for accuracy by comparing the reading to the current air temperature. If the needle is not displaying the... - Page 18 ® Page 18 BLACK DOG 42 XT GRILL & SMOKER ™ MODEL 590135 ASSEMBLY INSTRUCTIONS STEP STEP 21: ASSEMBLE CHARCOAL GRATE FRAME & CONNECT WIRES SIDE Place the charcoal grate frame [ BA ] inside the HOOK smoker chamber making sure the front hooks are at the front.
- Page 19 ® Page 19 BLACK DOG 42 XT GRILL & SMOKER ™ MODEL 590135 IMPORTANT! CURE PROCESS APPLY HERE APPLY VEGETABLE OIL TO INTERIOR AREAS ONLY APPLY HERE ALL INTERIOR SURFACES SMOKER CHAMBER APPLY HERE OR GRILL ALL INTERIOR SURFACES OFFSET...
- Page 20 ® Page 20 BLACK DOG 42 XT GRILL & SMOKER ™ MODEL 590135 OPERATING INSTRUCTIONS Please read all steps before cooking. SMOKER GRILL CHAMBER FIREBOX COOK HERE COOK HERE OPTIONAL: FIRE COOK HERE HERE FIRE HERE OFFSET FIREBOX CAUTION!! This grill becomes very hot, including the handles. Use caution working around the grill. Use mittens or oven gloves when opening the lid, doors, ash tray or adjusting the vents during use.
- Page 21 6. Fill in shipping address if needed. 7. Make a photocopy of this form for your records. 8. Mail or fax the completed form to: Landmann USA Attn: Accessories Dept. MODEL 101 Old Mill Rd Building 300 590326 Cartersville, GA 30120...
- Page 22 ® BLACK DOG 42 XT GRILL & SMOKER ™ MODEL 590135...
