- Page 1 Assembly and operating manual 12791 GB ersion #035-2012 eVision 06/11 Ut dition...
- Page 2 Please read before assembling and using! Failure to observe these instructions can affect or damage the device and other objects and lead to personal injury. We therefore recommend that you read the relevant chapter of these instruc- tions prior to assembly and before each use.
- Page 5 DIN EN 498 (Oktober 2009) 18.10.2011...
-
Page 6: Table Of Contents
Table of contents Delivery specifications ..........................6 Operational Elements ..........................6 Gas connection elements ......................... 6 Function ..............................7 Utilisation ..............................7 Correct usage ................................ 7 Incorrect usage ..............................7 Guarantee claims and warranty ......................7 Safety instructions ............................ 7 Definition of instructions used .......................... -
Page 7: Delivery Specifications
Delivery specifications Controls Pos. * Qty. Designation Pos. * Designation Function Warming rack Electronic Ignites the gas that pulse igniter flows into the burner Hotplate when the flame regula- Cooking grill tor (B or C) is open. Flame tamer Flame regu- Feeds gas into the burner lator for the on the grill unit (press,... -
Page 8: Function
Function Guarantee claims and warranty When the cylinder valve (G1) and flame regulators (B Your Landmann barbecue left the factory in a techni- or C) are open, the gas flows through the gas hose cally flawless condition. (G7) into the burner assigned to the the flame regu- In addition to your statutory warranty claims, Land- lator. -
Page 9: General Safety Precautions
• Never use the barbecue despite obvious damage. Possible consequences: • Never modify the barbecue's technology. Use only original spare parts from LANDMANN. • Severe burns from touching parts near the burners. • Use only accessories that are expressly authorised for this barbecue (see the "Accessories"... - Page 10 Danger: Gas is highly flammable Danger: Gas displaces oxygen Liquid gas is highly flammable and explosive. Liquid gas is heavier than oxygen. Therefore it settles on the ground and displaces the oxygen Possible consequences: at that level. • Serious injury to persons or damage to prop- Possible consequences: erty if escaping or accumulated gas ignites in an uncontrolled manner.
-
Page 11: Assembly
The following parts are included in delivery. They er be turned. comply with the standards applicable in the country to which they have been supplied by Landmann. • Always fit all connecting elements (screws, nuts, bolts, etc.) as shown in the illustrations. If you... -
Page 12: Connecting The Gas Cylinder
any naked flames, do not smoke or switch on Connecting the gas cylinder electric appliances (devices, lights, door bells), etc When performing the next step, make sure that the (spark-over possible). gas hose is not kinked or under tension. 8. Open the cylinder valve (turn G1 anti-clockwise) 1. -
Page 13: Operation
Operation Igniting the burners Starting up the barbecue 1. Check to ensure that ..Danger: Gas deflagration on ignition – there are not, and will not be, any flammable If unburned gas accumulates, deflagration can materials or substances nearby. Minimum dis- occur when igniting. -
Page 14: Switching Off The Barbecue
lators have been set to "OFF". Switching off the barbecue 1. Close the cylinder valve on the gas cylinder (turn G1 clockwise). 2. Press and turn all flame regulators (B, C) clockwise to "OFF". Igniting the side burner 3. Wait until all of the parts have cooled down and then clean any soiled components (see chapter "Cleaning"). -
Page 15: Cleaning
Cleaning • Check to ensure that all parts of the barbecue are present and assembled (visual check). • Check to ensure that all connections are present Barbecue and securely fastened. Tighten if necessary. Gas system Danger: Risk of burning when cleaning The gas system needs to be checked every time a gas the hot barbecue cylinder is connected (see chapter "Connecting and... -
Page 16: Troubleshooting
Troubleshooting If there is a fault despite due care, this chapter may help you to resolve the malfunction. Malfunction Potential causes Remedy There is a smell of gas Leak in the gas system 1. Close the cylinder valve imme- diately (turn G1 clockwise). 2. -
Page 17: Specifications
• ensures a dry storage location • Material: polyester/PVC Rotisserie set 13051 • For cooking chicken and roll roast. • Incl. motor and holder If you are interested, please contact our customer service or visit our website on www.landmann.com 12791... - Page 18 8 x ST M4 x 12 mm 12791...
- Page 19 4 x ST M4 x 12 mm 180˚ 6 x ST M4 x 12 mm 12791...
- Page 20 12791...
- Page 21 12791...
- Page 22 5 mm 12791...
- Page 23 4 x ST M4 x 12 mm 12791...
- Page 24 5 mm 12791...
- Page 25 4 x ST M4 x 12 mm 12791...
- Page 26 12791...
- Page 27 & 12791...
- Page 28 12791...
- Page 29 12791...
- Page 30 12791...
- Page 31 12791...
- Page 32 Landmann GmbH & Co. Handels-KG Am Binnenfeld 3 - 5 D-27711 Osterholz–Scharmbeck E-mail: ohz@landmann.de Internet: www.landmann.com Hotline Mon - Thu 8.00 a.m. to 4:45 p.m. Fri 8 a.m. to 3:30 p.m. Tel: +49 (0) 4791 308-59 or 16 Fax: +49 (0) 4791 308-36...
